Chapter 4: operation
introduction
This chapter describes the basic operation of the de-
vice.
power supply
psu 1
psu 2
The device does not provide a power switch. Connect-
ing a working power supply to the device will power up
the device immediately.
© 2014 DirectOut GmbH
®
hirose socket
Connect the power supply here (9 V - 24 V).
hirose socket
Connect the power supply here (9 V - 24 V).
EXBOX.BLDS Manual Version 1.1
Chapter 4: Operation
page 23 of 56
