Chapter 4: Operation
leD sYnC
(MADi)
page 26 of 56
This leD indicates the use of the
MADi input and its signal status.
LED OFF = no signal
LED ON = valid MADI signal, but not
in sync with internal reference
LED blink slow (steady period) =
in sync, MADI input selected as
audio and clock source
LED blink fast (steady period) = in sync,
MADI input selected, valid BLDS present
LED blink slow / off / blink slow =
in sync, MADI input not selected
as audio and clock source
LED blink fast / off / blink fast = in sync,
valid BLDS present, MADI input not selected
The input signal status is also monitored at the front
panel by four LEDS - see „Examples" on page 41.
EXBOX.BLDS Manual Version 1.1
DirectOut Technologies
© 2014 DirectOut GmbH
®
