2.4 - 10GbE Networking Port LEDs

2.5 - USB Ports

There are 4 USB 3.2 Gen 1 Type A ports on the Axial AC101 Edge Server.
Two ports are on the front of the system. Two ports are on the rear of the system.
All USB ports also support USB 2.0 connectivity.

2.6 - DisplayPort Video

There is one full-size DisplayPort (1.4a) located on the back of the Axial AC101 Edge Server.

2.7 - HDMI Video

There is one full-size DisplayPort (1.4a) located on the back of the Axial AC101 Edge Server.

2.8 - VGA Video

There is one full-size DisplayPort (1.4a) located on the back of the Axial AC101 Edge Server.
LED Color State
- Off
On
Link
Green
Blinking
- Off
Speed Yellow On
Green On
Condition
No Link
Link established
Data activity
100 Mb/s data
rate or no link
1Gbps data rate
10Gbps data
rate
