2 - I/O Definitions

2.1 - Networking

The Axial AC101 features the following onboard Ethernet ports:
Port
1GbE Mgmt
1GbE Port 1
1GbE Port 2
10GbE Port 3
10GbE Port 4
Chipset
Dedicated BMC Management port.
Port is only used for system management
Realtek
functions such as IPMI, RedFish, Remote
RTL8211F
(Attached to Management, etc.
ASPEED
AST2600)
This port is not usable as an Ethernet port by the
operating system.
1GbE Port
This port may be configured to operate in a
Shared NIC mode, enabling access to the BMC
Intel® I210
network connection and supporting the system
management functions such as IPMI, RedFish,
Remote Management, etc.
Intel® I210 1GbE Port
10GbE Port
This port may be configured to operate in a
Shared NIC mode, enabling access to the BMC
network connection and supporting the system
management functions such as IPMI, RedFish,
Remote Management, etc.
Intel® X710
10GbE Port
Capabilities
