H3C SR6608 Routers Installation Quick Start-5PW101 H3C SR6608路由器 快速安装指南-5PW101 BOM: 3104A0S3 Installation tools 工具参考 Wear an ESD Wrist strap, and make sure the wrist strap makes good skin contact and is reliably Grounded. 操作者需佩戴防静电腕带,确保防静电腕带与皮肤良好接触,并确认防静电腕带已经良 No installation tools are provided with the router. Prepare them yourself as required.
Page 2
Installing MPUs/switching fabric modules/service modules 安装主控板/网板/业务板 Connecting the grounding cable 连接保护地线 The router supports hot swapping of MPUs, switching fabric modules, and service modules. 主控板、网板、业务板支持热插拔。 Correctly connecting the grounding cable is crucial to lightning protection and EMI protection. To guarantee the grounding effect, use the grounding cable provided with Installing an MPU carrier 安装主控板托板...
Page 3
Installing an MPU 安装主控板 The router is provided with only one SFE-L2 switching fabric module. As a best practice, install the switching fabric module in the right half of slot 2. To use more switching fabric modules or carriers, order them separately. 设备仅随机附带一个SFE-L2网板,建议优先安装在slot2的右侧槽位,如需增加网板或...
Page 4
Obtaining documentation 资料获取方式 在连接电源线前,需保证设备已正确接地。 To avoid bodily injury, connect the power cord to the router first and then to the power source. To access the most up-to-date H3C product documentation on the H3C website at 在连接电源线时,先完成电源线与设备侧的连接,再进行电源线与机房供电系统的连 www.h3c.com.hk: 接,以免造成人身伤害。 1. Go to http://www.h3c.com.hk/Technical_Documents.
