H3C SR6600/SR6600-X Routers
FAQ
Copyright © 2017 New H3C Technologies Co., Ltd. All rights reserved.
No part of this manual may be reproduced or transmitted in any form or by
any means without prior written consent of Hangzhou H3C Technologies Co.,
Ltd.
The information in this document is subject to change without notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SR6600 Series and is the answer not in the manual?

Questions and answers

Related Manuals for H3C SR6600 Series

Summary of Contents for H3C SR6600 Series

  • Page 1 H3C SR6600/SR6600-X Routers Copyright © 2017 New H3C Technologies Co., Ltd. All rights reserved. No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Hangzhou H3C Technologies Co., Ltd.
  • Page 2 Are all H3C SR6600 routers IRF capable? ················································································· 7 Do all SR6600 service modules support IRF? ············································································· 7 Can an H3C SR6600 router form an IRF fabric with any devices in the same series? ························· 7 How many chassis can an H3C SR6600 IRF fabric have? ····························································· 8 What topologies does an H3C SR6600 IRF fabric support? ···························································...
  • Page 3 Why doesn't the running configuration on a reunified IRF fabric include the configuration that I made on one chassis after an IRF split? ······································································································ 10 Network security and attack prevention ··············································· 10 What attack prevention types does the router support? ······························································· 10 Does the router support local authentication before RADIUS authentication? ··································...
  • Page 4 OpenFlow ····················································································· 17 Which cards do not support OpenFlow? ·················································································· 17 Which OpenFlow version does the router support? ···································································· 17 Does OpenFlow support controlling Layer 2 forwarded packets? ·················································· 17 Does OpenFlow support controlling MPLS forwarded packets? ···················································· 17 Does the OpenFlow forwarding process depend on the normal forwarding process? ························ 17 Does OpenFlow support VLAN interfaces?···············································································...
  • Page 5 H3C SR6600/SR6600-X Routers FAQ Hardware This section contains the most frequently asked questions about the router hardware. Q. What models does H3C SR6600 Router Series include? A. H3C SR6600 Router Series includes the following models: • SR6600 models: SR6604, SR6608, and SR6616.
  • Page 6 Q. What power modules are available for the router? A. The following power modules are available for the router: Model Voltage range Quantity • AC input: 100 VAC to 240 VAC LSWM1AC300 • SR6602-X1: 1 to 2 • High-voltage DC •...
  • Page 7 Q. How do I identify the card serial number or manufacture information? A. Use the display device manuinfo command on the router. The following is a sample command output. <H3C>display device manuinfo Chassis self: The operation is not supported on the specified chassis.
  • Page 8 Q. What cards and interface modules are available for the router? A. See H3C SR6600/SR6600-X Routers Interface Module Guide. Q. What transceiver modules available for the router? A. See H3C SR6600/SR6600-X Routers Interface Module Guide.

  • Page 9: System Management And Maintenance

    Q. How can I empty the recycle bin? A. Use the reset recycle-bin command. If a file in the recycle bin is corrupt, use the reset recycle-bin command with the /force option to delete the file. Q. Is software hotfix supported? A.
  • Page 10 • Flow control—None • Parity—None • Stop bits—1 • Data bits—8 • Terminal display type—VT100 If you are running the terminal software SecureCRT, you must deselect the DTR/DSR option and RTS/CTS option for flow control. By default, the RTS/CTS option is selected for flow control. Q.
  • Page 11 Q. Do all SR6600 service modules support IRF? A. Yes. Q. Can an H3C SR6600 router form an IRF fabric with any devices in the same series? A. No. When you set up an IRF fabric, follow these hardware restrictions and guidelines: •...
  • Page 12 A. An H3C SR6600 IRF fabric can have a maximum of two member chassis. Q. What topologies does an H3C SR6600 IRF fabric support? A. An H3C SR6600 IRF fabric only supports the daisy-chain topology. It does not support the ring topology.
  • Page 13 A. When you configure LACP MAD, make sure the intermediate device meets the following requirements: • The intermediate device is a Comware-based H3C device that can process the LACPDUs that convey the ActiveID field for MAD. • If the intermediate device is also an IRF fabric, assign the two IRF fabrics different domain IDs for correct split detection.
  • Page 14 Q. Why doesn't the running configuration on a reunified IRF fabric include the configuration that I made on one chassis after an IRF split? A. When an IRF fabric merges, the chassis in the Recovery-state IRF fabric reboots with the running configuration on the active IRF fabric.
  • Page 15 Q. Does the router support local authentication when the HWTACACS authentication fails? A. The router supports local authentication when the HWTACACS authentication fails because the server is not reachable. The router does not support local authentication when the HWTACACS authentication fails because of an incorrect username or password.
  • Page 16 Q. How do I prevent gateway spoofing when the router acts as a gateway? A. When receiving an ARP packet from the router that acts as a gateway, the router sends a gratuitous ARP packet to modify the spoofed ARP entries. If a large number of attack packets exist, the router detects the incoming interface of the attack packets.
  • Page 17 Q. Does the router support cross-card link aggregation? A. Yes. You can use interfaces on any cards for cross-card link aggregation except an FIP-600 or SAP-4EXP card. IP routing This section contains the most frequently asked questions about IP routing. Q.
  • Page 18 Q. Does the router discard the matching packets when the PBR-based forwarding fails? A. No. If the PBR-based forwarding fails because of nonexistent next hop, the router forwards the matching packets based on the IP routing table. Q. What is the compatibility between routing protocols and the GR, NSR, FRR, and BFD features? A.
  • Page 19 Q. Which IGMP versions are supported by the router? A. The router supports IGMPv1, IGMPv2, and IGMPv3. By default, the router runs IGMPv2. Q. Are static RPs supported by the router? A. Yes. You can use the static-rp rp-address [ acl-number | bidir | preferred ] *command to configure a static RP.
  • Page 20 IGMPv3 IS_EX and IGMPv3 TO_EX reports that do not carry multicast source addresses.  • Among the other optional parameters, only the fragment keyword and the time-range time-range-name option take effect. Q. The RPF check fails after the MSDP peer switchover in inter-domain multicast routing. What are the possible reasons? A.
  • Page 21 Q. Why routing protocols are not recommended to be configured on the interface with Easy IP configured? A. With Easy IP configured, the interface puts all packets into one software queue to the CPU. If routing protocols are configured on the interface, a large number of protocol packets will be generated.
  • Page 22 Q. Does OpenFlow support VLAN interfaces? A. The VLAN interfaces support only MAC-IP flow tables and do not support extensibility flow tables.
