Special MP3, WMA and JPEG Operation…………………………………………………………………16 Special USB Operation Special USB Operation……………………………………………………...……..…………………………17 MP3 Ripping (Audio CD to USB)…..……………………..……………………………………….………18 DATA Transferring (Disc to USB) ……..……..……………..……………………………………….………18 System Setup General Setup…………………………..………………………………..……………………………………19 Speaker Setup…………………………..………………………………..……………………………………19 Audio Setup…………………………..………..………………………..………………….…………………20 Video Setup…………………………..…..……………………………..……….……………………………20 Preference Setup…………………………..………………………………..…………………………………21 Troubles Shooting…………….…………..………………………………..………………………………22 Specifications………………………..………………………………..……………………….……………24 Safety Precautions www.acesonic.com...
Wipe the disc from the center out. Do not use any abrasive materials or solvents such as benzene and alcohol, thinner, commercially available cleaners, or anti-static spray intended for older vinyl records.. www.acesonic.com...
Supported MP3+G Format (Specially MP3 file): The specification of MP3 in MP3+G file must keep the following specifications otherwise the MP3G file will not play properly. Format Bit Rate 80~348kbps Sampling Frequency 44.1khz www.acesonic.com...
S-VIDEO OUTPUT: Connect to the S-Video Input of your TV using S-Video cable for better picture. OPTICAL DIGITAL AUDIO OUT: Connect to Optical Digital Input of the amplifier for best quality surround sound using Optical Cable. SCART OUT: connection mainly used for TV’s in Europe. TV display (4:3) built-in video, RGB out and www.acesonic.com...
Page 6
10. VGA OUT: Connects to the VGA port of TV or monitor 11. AC POWER CORD: Connection to auto-detect AC power supply (AC100V~240V, 50/60Hz) www.acesonic.com...
AAA size batteries with + and – aligned correctly. *Do not expose batteries to heat or flame *Tempo Control: Tempo (playback speed) changes might not work on several situations: 1. VOB file from USB Port 2. sub title will be off on DVD disc www.acesonic.com...
Page 8
3. some special CDG/VCD/DVD format www.acesonic.com...
Connect a VGA cable from the VGA OUT jack on the back panel of the player to the VGA IN jack on your TV or Monitor. ※[NOTE] You must turn On the power of VGA monitor before connecting the VGA cable to the player. Otherwise, the player may not work normally. www.acesonic.com...
< NOTE > The type of audio output from the connector can be selected by the Audio setting. Please turn the volume down when you turn on the Amplifier. Sudden loud sound may cause damage to the speakers and your ears. www.acesonic.com...
The player may not fully support parts of memory card or a multi card reader. Do not insert or pull out the memory card from the card reader when using the card reader. If you use a USB extension cable, the USB device might not be recognized. www.acesonic.com...
Press ‘+’ to raise the sound volume. Press ‘-‘ to lower the sound volume. NUMERIC(0~9): Press Numeric button to select a File/Track number to play. E.g) File Number is 1234, Press 1-2-3-4 in order and press PLAY or ENTER to start playback. www.acesonic.com...
Page 13
DVD/VCD: You can aggrandize the image by pressing the button. (“1.5X Normal”) JPEG: You can select “Zoom On/Off” and you can aggrandize the image by pressing “FR/FF” button. ( 25% 100% 150% 200%) In ZOOM ON mode, if press MENU, you can see digest screen(3*3=9). www.acesonic.com...
Page 14
Screen. N/P: TV Type Selection (NTSC/PAL/Multi) Press the N/P button to switch the video output signal of the DVD player (NTSC/PAL/Multi) SETUP: Press SETUP button to enter the setup mode, press again to close and exit the setup mode. www.acesonic.com...
Press AUDIO to hear the Lead Demonstration Vocal through the right channel of the audio output. Press again to turn off the Lead Demonstration Vocal. NEXT/ PREV: Press NEXT button to skip to the next track or song. Press PREV button to skip back to the previous track or song. www.acesonic.com...
Page 16
You will get a Score and/or comments on the screen after singing a song in MP3+G/CD+G/VCD/DVD Karaoke disc. E.g.) Score 100: Excellent! 90~99: Very Good! 80~89: Good! ect. <NOTE> To use this function, the Karaoke Setup should be set at “Karaoke On” or “Karaoke Scoring On”. www.acesonic.com...
Some MPEG4 files created on a personal computer may not be played back. That is why Codec Type, Version and Higher resolution over the above specification is not supported. This unit supports CD-R/RW written in MPEG4 in accordance with the “ISO9660 format” www.acesonic.com...
PLAYBACK WITH MULTI-ANGLE (JPEG) ▲ ▼ During playback, press Arrow(◀▶ ) buttons to rotate the picture on the TV screen. ◀: rotate the picture anti-clockwise ▶: rotate the picture clockwise ▲ : flip the picture vertically ▼ : flip the picture horizontally www.acesonic.com...
You can create a New Folder in USB only. Press “INFO” and select “New Folder” then input new folder name with On-Screen Keyboard by pressing ARROW(▲▼◀▶) and “ENTER” button Properties( DVD, USB) Press “INFO” and select “PROPERTIES” then you can see the file or folder information. www.acesonic.com...
Please move to USB mode by pressing “USB/DISC” and check the transferred data. <NOTE> If you unplug-out the USB device or turn off the power of the player during transfer, it will cause damage to other files in USB. www.acesonic.com...
You can select central speaker’s delay duration up to 0~5MS. REAR DELAY: REAR SPEAKER DELAY SETTING You can select rear speaker’s delay duration up to 0~15MS. TEST TONE: SPEAKER TEST You can test speaker’s sound output by pressing ON button in the following order: Front(L)-Center-Front(R)-Rear(R)-Rear(L). www.acesonic.com...
S-VIDEO: You have to select S-Video mode to connect with TV via S-Video or Composite port. YPbPr: You have to select YPbPr mode to connect with TV via Component or Composite port. RGB: You have to select RGB mode to connect with Monitor via VGA or Composite port. www.acesonic.com...
8 ADULT: Mature material; should be viewed only by adults due to graphic sexual material, violence or language. PASSWORD: You can set a password. The default password is “0000”. DEFAULTS: You can reset all options and your personal settings to the factory defaults. SMART NAV: You can set this option as NO Menu or With Menu. www.acesonic.com...
If the screen display moves to a bright image from a dark one suddenly, the image can tremble instantaneously. This is not a mechanical malfunction. Distorted picture Sometimes a small amount of picture distortion may appear depending on the disc being played back. This is not a malfunction. www.acesonic.com...
Page 25
Check the USB HDD and Digital Camera whether have the auxiliary Power input or not. If not, you must connect the auxiliary power cord to them for proper operation. How to convert CDG files to MP3G files from my CDG disc Please see page 4 for detail introduction. www.acesonic.com...
Frequency response: 20Hz-20Khz Signal to Noise: 110dB Audio Output Total harmonic distortion: Less than 0.5%(1KHz, 0dB) Digital out(Optical): 0.3Vpp(75 Ω) Digital out(Coaxial): 0.5Vpp(75Ω) Analog output: 2.0Vrms(1Khz, 0dB) MIC input: 2 USB Host interface: v 1.1 Input SCORING input: 1 www.acesonic.com...
