SOR 102 General Instructions Manual

Knurled cap over set
point adjustment
High side process
connection 1/4 NPT(F) PT(F)
[1/2" NPT(F) optional] onal]
Hermetically sealed
switching element
capsule with 18 AWG AWG
wire leads, 18" (45.7
cm) in length
1/2" NPT(M) electrical
conduit connection
3/4" NPT (F) electrical conduit connection
Weathertight switching element housing (terminal block under cover)
These instructions provide information for installation, electrical connection, process con-
nection and calibration of 102 Differential Pressure Switches.
Process pressure is sensed by a piston assembly. The piston responds to differential
pressure and moves a lever connected to a torsionally stiff cross-shaft. One end of the
cross-shaft is connected to a lever that is biased by the range spring. The other end has a
lever that actuates (deactuates) an electrical switching element.
NOTE: If you suspect that a product is defective, contact the factory or the SOR
in your area for a return authorization number (RMA). This product should only be installed by
trained and competent personnel.
Design and
specifications are
subject to change
without notice.
For latest revision, go to
SORInc.com
Form 420 (07.21) ©SOR Inc.
Differential Pressure Switch
Explosion Proof - AD Housing
ATEX/IECEx Certified Ex db IIC - CL Accessory
d
5.7
rical
Installation .......................................2
SIL Installation ..................................2
Process Connection ............................2
Electrical Connection ...........................2
Special Conditions ..............................3
Calibration .......................................4
Dimensions ......................................5
ATEX/IECEx General Information .............6
Declaration of Conformity .....................7
General Instructions
Weathertight - W1 Housing
ATEX/IECEx Certified Ex ia IIC -
under cover)

Table of Contents

Registered Quality System to ISO 9001
102
CL Accessory
® Representative
