The SOR
2210 Side Mounted Level Switch is a horizontally mounted, float-operated
level switch. The 2210 is suitable for plant and OEM applications where open or
closed contacts are required to signal presence or absence of liquid at a discrete level.
When the liquid rises, the float extension arm moves a magnet which repels an
es, the float exte i
internal magnet de-actuating a microswitch. When the liquid level falls, the float
extension arm moves the magnet in the opposite direction, actuating the microswitch.
The 2210 is recommended for use in clean liquids only.
NOTE: If you suspect that a product is defective, contact the factory or the SOR Representative
in your area for a return authorization number (RMA). This product should only be installed by
trained and competent personnel.
Design and
specifications are
subject to change
without notice.
For latest revision, go to
SORInc.com
Form 1428 (05.16) ©SOR Inc.
