MAIN CONTROLLER
REPLACEMENT INSTRUCTIONS FOR:
DUKE KITS
# 600309 - TSC-6/18M
# 600546 - PBC-6/18M
This kit contains:
Main Control Module Assembly For:
•
ELC0017-1 - PCB, TSC, TSCM
OR
•
ELC0017-7 - PCB, TSC, PBC
•
512418 Strap, Disposable Wrist ESD
CAUTION:
Please read this manual completely before attempting
to install, operate or service this equipment
This manual is Copyright © 2019 Duke Manufacturing Co. All rights reserved.
Reproduction without written permission is prohibited. Duke is a registered
trademark of the Duke Manufacturing Co.
INSTALLATION
INSTRUCTIONS
Items required for this installation:
•
#2 Phillips Screw Driver
•
11/32" Nut-driver
•
ESD Wrist Strap (included in kit)
P/N 120107
REV C 05/22/2019
