Spudnik 80 Series Operator's Manual

Planter
Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATORS/ PARTS MANUAL
MODEL 80XX
PLANTER
Part # 290115
For Serial Numbers Beginning
8040-55-32
8060-55-55
8080-55-33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 80 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Spudnik 80 Series

Summary of Contents for Spudnik 80 Series

  • Page 1 OPERATORS/ PARTS MANUAL MODEL 80XX PLANTER Part # 290115 For Serial Numbers Beginning 8040-55-32 8060-55-55 8080-55-33...
  • Page 2 Service Centers Phone: (208)785-0480-Fax: (208)785-1497 E-Mail: spudnik@spudnik.com Web Site : www.spudnik.com BLACKFOOT PASCO GRAFTON 584 West 100 North 5802 North Industrial Way 1410 12th St. West P.O. Box 1045 Pasco, Wa. 99301 Grafton, Nd. 58237 Blackfoot, ID 83221 Phone (509) 543-7166...

  • Page 3: Table Of Contents

    Operators manual MODEL 80XX Planter Table of Contents Description Page # Introduction …………………………………………………………………………………………….. Forward to the operating manual ……………………………………………………………………. Warranty ……………………………………………………………………………………………….. Product Characteristics ………………………………………………………………………………. Dangers, operating errors and exemption from liability .…………………………………….…….. Safety ….……………………………………………………………………………………………….. General safety and accident prevention regulations …………………………….………………… Special safety instructions .……………………………………………………………………………...
  • Page 4 Operators manual MODEL 80XX Planter Table of Contents Description Page # CP600 Control Box …………………………………………………………………………………… 24-61 Maintenance …………………………………………………………………………………………… 62-76 General Safety Instructions ……………………………………………………………………. 62-63 Special Safety Instructions …………………………………………………………………….. Spare Parts Procurement ……………………………………………………………………… Disposing of Replaced Parts ………………………………………………………………….. Cleaning After Every Operation ……………………………………………………………….. Parts to be Cleaned ……………………………………………………………………………..

  • Page 5: Introduction

    Operators manual MODEL 80XX Planter Introduction Welcome to the SPUDNIK line of potato handling equipment. We appreciate your decision to make our equipment a part of your operation, and look forward to a long term partnership. We strive to put the best quality and workmanship into each of our machines, and hope as you use you’re MODEL 80XX PLANTER, that you will find this to be true.

  • Page 6: Forward To The Operating Manual

    Operators manual MODEL 80XX Planter Foreword to the Operating Manual This operating manual is intended to familiarize the user with the 80XX PLANTER and its designated use. This operating manual contains important information on how to operate the machine safely, properly and efficiently.

  • Page 7: Warranty

    (2) Present evidence of the warranty start date. (3) Make the product available to Spudnik or the dealer within a reasonable period of time and (4) return all faulty parts to Spudnik. All warranty request must (1) be approved by Spudnik Equipment WARRANTY SERVICE –...

  • Page 8: Product Characteristics

    Operators manual MODEL 80XX Planter Product Characteristics Manufacturer's address SPUDNIK EQUIPMENT COMPANY LLC 584 W 100 N PO Box 1045 Blackfoot, ID 83221 Phone: (208) 785-0480 Fax: (208) 785-1497 www.spudnik.com E-mail: spudnik@spudnik.com Advice concerning inquiries and orders Please quote the type designation and the machine number when ordering accessories and spare parts.

  • Page 9: Dangers, Operating Errors And Exemption From Liability

    The results produced by the machine must be constantly monitored and checked. SPUDNIK shall not be liable for any damage to agricultural produce and other items which occurs as a result of operating and adjustment errors or other incorrect usage.

  • Page 10: Safety

    •The use of spare parts, accessories and auxiliary equipment not supplied and/or not approved by SPUDNIK can have detrimental effect on the construction of the SPUDNIK machine or on its functions and hence impair the active and./or passive driven an/or operational safety (accident prevention).

  • Page 11: General Safety And Accident Prevention Regulations

    Operators manual MODEL 80XX Planter General safety and accident prevention regulations The safety advice and information given in this operating manual, the valid nation regulations concerning accident prevention and any applicable internal employment, operational and safety regulations of the operator are to be observed. Warning signs and other notices on the machine provide important information for safe operation.

  • Page 12: Special Safety Instructions

    Operators manual MODEL 80XX Planter Special safety instructions Towed machines Risk of injury when hitching up or unhitching machine to/from the tractor! Never allow persons to stand between the tractor and the machine unless the tractor is secured against rolling away by means of the parking brake and/or wheel chocks! Hitch up the machine only in accordance with the instructions and only to the prescribed components! Follow the instruction in the tractor’s manual.
  • Page 13 Operators manual MODEL 80XX Planter Special safety instructions Using a power take-off (PTO) shaft Observe the operating instruction of the PTO shaft manufacturer! An operator’s manual is supplied with every PTO shaft. Only use the PTO shafts specified by the manufacturer! PTO shaft housing and guard cone as well as PTO shaft guard must be fitted and in a proper condition.
  • Page 14 Operators manual MODEL 80XX Planter Special safety instructions Hydraulic system The hydraulic system is under high pressure! Make sure that the hydraulic system is depressurized (tractor and machine) when connecting the hydraulic hoses to the tractor’s hydraulic system. Hydraulic hose lines should be inspected at regular intervals and replaced if damaged or worn! New hose lines must comply with the technical specification of the machine manufacturer! Hoses and hose couplings undergo a natural ageing process, even if stored and used correctly;...

  • Page 15: Warning Symbols And Other Instruction Notices On The Machine

    Operators manual MODEL 80XX Planter Warning symbols and other instruction notices on the machine SIGNAL WORDS: DANGER, WARNING, and CAUTION are signal words with messages: DANGER: An immediate and specific hazard, which WILL result in severe injury or death if proper precautions are not taken. WARNING: A specific hazard or unsafe practice, which COULD result in severe injury or death.
  • Page 16 Operators manual MODEL 80XX Planter Warning symbols and other instruction notices on the machine MOVING MACHINERY Can cause severe injury or death. Do not ride. CRUSHING HAZARD KEEP HANDS AND FEET AWAY FROM MACHINERY WHILE RUNNING. HIGH PRESSURE OIL Can cause serious injury or death.

  • Page 17: Configuration And Functions Of The Machine

    Operators manual MODEL 80XX Planter Configuration and functions of the machine Method of operation of the machine The SPUDNIK planter is designed for planting potatoes. This chapter describes the configurations and function of the individual subassemblies. page 16 of 173...

  • Page 18: Row Spacing

    Operators manual MODEL 80XX Planter Configuration and Functions of the Planter Row Spacing – 32”, 34”, 36”, 38”, 36-40” Move planting unit, hopper, top bin, extension, shoes, also the first and last row unit. Seed Spacing – 6-18” Rear Front page 17 of 173...

  • Page 19: Planting Depth

    Operators manual MODEL 80XX Planter Configuration and Functions of the Planter Planting Depth – Is adjusted with the gage wheel on each pair of shoes. Covering Discs – Are adjustable for angle, depth, and width. Tighten Idlers – Mechanical drive, and chemical box drives. Cup belt shaker –...

  • Page 20: Seed Level In Bowl

    Operators manual MODEL 80XX Planter Configuration and Functions of the Planter Seed Level in Bowl – If there is not adequate seed in the bowl, skips will result. Adjust eh sensor on top of the bowl. The maximum seed level should be one inch below the top edge to the seed weight door at the rear. The bowl level should be observed while planting because the bowl may over fill when stopping or lifting the planter.

  • Page 21: Row Unit Set-Up

    Operators manual MODEL 80XX Planter Configuration and Functions of the Planter Row Unit Set-Up To achieve the highest accuracy while planting it is important to have the row unit properly adjusted. Feed Chain Speed – The speed of the feed chains can be set by adjusting the flow control Needle valve (1) in the front center of the planter.

  • Page 22: Shaker Position

    Operators manual MODEL 80XX Planter Configuration and Functions of the Planter Row Unit Set-Up Shaker Position – The position of the shaker is the most effective adjustment when trying to change the shake for different seed and different conditions. There is a coarse adjustment knob (4) and a fine adjustment knob (5). A good starting point is to loosen the coarse adjustment and with the shaker on let it move to a stabilized point.

  • Page 23: Covering Disks

    Operators manual MODEL 80XX Planter Configuration and Functions of the Planter Row Unit Set-Up Covering Disks – The down pressure on the discs is controlled by tightening the spring with the adjustment knob (10). For a wider gill remove the bolts and slide each disc assembly out from the center. The angel of the discs can also be changed by moving the disc assembly to another hole combination.

  • Page 24: Seed Accuracy

    Operators manual MODEL 80XX Planter Configuration and Functions of the Planter Row Unit Set-Up Seed Accuracy – To achieve more accurate seed spacing it is critical to control seed roll. Adjustable wings (14) have been mounted on the inside of the shoe which move in and out according to soil conditions. The goal is to try to pin the seed as it falls into the furrow.
  • Page 25 Operators manual MODEL 80XX Planter Table of Contents Description Page # Parts Breakdown ……………………………………………………………………………………….. CP600 Buttons and Functions ………………………………………………………………………… Initial and Default Screens …………………………………………………………………………….. Moving Default Screen to Main Menu ………………………………………………………………… Skip Detection …………………………………………………………………………………………... Feed Chain ……………………………………………………………………………………………… 30-33 Fertilizer Valve Calibration …………………………………………………………………………….. 34-37 Seed Spacing ……………………………………………………………………………………………...

  • Page 26: Parts Breakdown

    Operators manual MODEL 80XX Planter Parts Breakdown The following diagram shows how the CP600 Control Box is connected to the MDA Processor. CP600 Control Box MDA Processor Item # Quantity Part # Description 450162 PLATER DISPLAY CP600 B94.01736 BUS-END PLUG M12x1,8p [x] B94.01683 CAN BUS CABLE 80"...

  • Page 27: Cp600 Buttons And Functions

    Scrolls up through options of a specific menu Scroll Down Scrolls down through options of a specific menu Control Dial Use this for changing settings. (Note: Some settings may require contacting a Spudnik technician to be changed) CP600 CONTROL BOX page 13 of 173...

  • Page 28: Initial And Default Screens

    Operators manual MODEL 80XX Planter Initial and Default Screens When power is turned on, this screen will display briefly. After the previous screen, you will see the default screen: •When left on any other screen for approximately 8 seconds, the display will default back to this screen.

  • Page 29: Moving Default Screen To Main Menu

    Operators manual MODEL 80XX Planter Moving from Default Screen to Main Menu Default Screen While in the Default Screen, press the Menu Layers button once to go to the main menu. Main Menu Fertilizer Valve Calibration Skip Detection Seed Spacing Distance Feed Chain Measurements...

  • Page 30: Skip Detection

    Operators manual MODEL 80XX Planter Skip Detection (To change this setting, refer to password section or contact a Spudnik Technician The reload on cups should be 94 for red or green cups and 111 for blue cups This is the alarm...

  • Page 31: Feed Chain

    Operators manual MODEL 80XX Planter Feed Chain After choosing the Feed Chain icon, you will see this display: By pressing the function button directly above If one or more of the seed chains the feed chain icon, you will control whether are OFF, by choosing this icon, that chain is ON or OFF.
  • Page 32 (To change this setting, refer to password section or contact a Spudnik technician.) Press the scroll down button once to view the next display This portion displays the maximum chain pause time.
  • Page 33 This portion displays the amount of time the buzzer will sound for in the event of an alarm. (Default is 2 seconds). (To change this setting, refer to password section or contact a Spudnik Technician) With Feed Chains turned off , an Alarm will sound if the working position of planter is changed (as...
  • Page 34 Operators manual MODEL 80XX Planter Feed Chain Functions The Feed Chains may be switched on or off individually. This allows you to leave a path to the center tower of pivots. 5 6 7 8 Rows may have the feed chain turned off in order to leave a path to the center tower of the pivot.

  • Page 35: Fertilizer Valve Calibration

    Operators manual MODEL 80XX Planter Fertilizer Valve Calibration To set Fertilizer Valves, follow the steps below: To set the fertilizer valves you must make sure that the fertilizer valves are turned OFF and the stop sign symbol says, ‘STOP’. The symbol defaults to ‘GO’.
  • Page 36 Operators manual MODEL 80XX Planter Fertilizer Valve Calibration Shaft speed for calibration suggested # to begin with 2000. If the shaft speed during the calibration is too fast or slow adjust this value up or down. The desired rotations for the calibration. Desired application rate CP600 CONTROL BOX...
  • Page 37 Operators manual MODEL 80XX Planter Fertilizer Valve Calibration Select both A and B buttons to start calibration. Note: Place bucket under one row unit to measure the weight of the fertilizer. Then multiply by the number of row units. i.e. If you have a four row planter and measure the fertilizer weight brought out through the calibration from one row unit, you need to multiply the weight by four.
  • Page 38 Operators manual MODEL 80XX Planter Fertilizer Valve Calibration Select buttons A and B to calculate and make sure that the correct calibration has been set. ‘OK’ means that the calculations are correct and finished. 11) Calculated Factor To adjust (fine tune) press the two buttons below Manual.

  • Page 39: Seed Spacing

    Operators manual MODEL 80XX Planter Seed Spacing The seed spacing is measured off of the wheel speed or the radar speed. (optional) After choosing the seed spacing icon, you will see this display: Wheel Speed Radar Speed This screen displays the current seed spacing.
  • Page 40 Operators manual MODEL 80XX Planter Seed Spacing (Continued from the previous page) If the radar speed is not reading correctly, it will need to have an offset entered. This display allows you to change the offset for the radar. Note: If the difference in the speed of the wheel and the speed of the radar is greater than 20%, then an alarm will be triggered.

  • Page 41: Distance Measurements

    Operators manual MODEL 80XX Planter Distance Measurements The Distance Measurements menu is used for setting up the Chemical boxes and also measuring the tire circumference. After choosing the Distance Measurements icon, you will see this display: This number is the calibration distance. By turning the dial on the lower right hand corner to the CP600, you may change this distance.

  • Page 42: Hydraulic Drive

    Operators manual MODEL 80XX Planter Hydraulic Drive To set up the hydraulic drive configuration requires a password and extreme CAUTION. All machines are set-up at the factory. Make note of factory settings before changing. Note: Manually running the hydraulic drive does not require a password, skip to #3 Select the ‘SERVICE’...
  • Page 43 Operators manual MODEL 80XX Planter Hydraulic Drive After choosing the Hydraulic Drive icon, you will see this display: Press two Buttons to empty Bin This value determines the speed that the row unit seed cups will run at. This test is often run to empty the bin or clean the cups. Press the scroll down button once to view the next display This value is the slowest speed the cups should run at.
  • Page 44 Operators manual MODEL 80XX Planter Hydraulic Drive (Continued from the previous page) This value is the fastest speed the cups should run at. Press the scroll down button once to view the next display The start value is typically about 2000. this is when the valve is about 20% open.
  • Page 45 Operators manual MODEL 80XX Planter Hydraulic Drive (Continued from the previous page) The proportional value is 40-50. On 2006 machines they will be factory set to 50. Press the scroll down button once to view the next display The integration factor value for all machines is 20. CP600 CONTROL BOX page 44 of 173...
  • Page 46 Operators manual MODEL 80XX Planter Fertilizer Hydraulic Drive To set up the hydraulic drive configuration requires a password and extreme CAUTION. All machines are set-up at the factory. Make note of factory settings before changing. Note: Manually running the hydraulic drive does not require a password, skip to #3 Select the ‘SERVICE’...

  • Page 47: Fertilizer Hydraulic Drive

    Operators manual MODEL 80XX Planter Fertilizer Hydraulic Drive After choosing the Fertilizer Hydraulic Drive icon, you will see this display: This value determines the speed that the fertilizer box valves will run at. This test is often run to empty the bin or clean the cups. Press the scroll down button once to view the next display This value is the slowest speed the valves should run at.
  • Page 48 Operators manual MODEL 80XX Planter Fertilizer Hydraulic Drive (Continued from the previous page) Two buttons for test mode This value is the fastest speed the valves should run at. Press the scroll down button once to view the next display The start value is typically about 2000.
  • Page 49 Operators manual MODEL 80XX Planter Fertilizer Hydraulic Drive (Continued from the previous page) The proportional value is 40-50. On 2006 machines they will be factory set to 50. Press the scroll down button once to view the next display The integration factor value for all machines is 20. CP600 CONTROL BOX page 48 of 173...

  • Page 50: Acre Meter

    Operators manual MODEL 80XX Planter Acre Meter After choosing the acre meter icon, you will see this display: Press the function buttons above Acres are measured the resets to reset the value. in 10 acre intervals. This section displays how many This section displays the acres have been planted.
  • Page 51 Operators manual MODEL 80XX Planter Acre Meter (Continued from the previous page) This is the circumference of the tire that the sensor is on. The sensor could be placed on either the front or the rear wheel of the machine. Factory Circumference Settings Tire Nomenclatures Circumference...

  • Page 52: Information

    Operators manual MODEL 80XX Planter Information After choosing the information icon, you will see this screen displayed: This section displays the This section displays the errors software versions in the MDA that have occurred. box, and also the CP600 CP600 CONTROL BOX page 51 of 173...

  • Page 53: Status/Diagnostics

    Operators manual MODEL 80XX Planter Status/ Diagnostics The Status/ Diagnostics section allows you to monitor specific sections of the machine. The following describes each icon’s meaning: This icon indicates an okay, open circuit status. This icon indicates an okay, closed circuit status. This icon indicates a short circuit to ground.
  • Page 54 Operators manual MODEL 80XX Planter Status/ Diagnostics After choosing the Status/ Diagnostics icon, you will see this display: The following screens display the status of the described area of the machine. This section displays the sip detection status. Press the scroll down button once to view the next display This section displays the feed chain status.
  • Page 55 Operators manual MODEL 80XX Planter Status/ Diagnostics (Continued from the previous page) This section displays the feed chain status. Press the scroll down button once to view the next display This section displays the fertilizer valve status. Press the scroll down button once to view the next display (Continued on the next page) CP600 CONTROL BOX...
  • Page 56 Operators manual MODEL 80XX Planter Status/ Diagnostics (Continued from the previous page) This section displays the dry fertilizer box encoder status of the clutch. Press the scroll down button once to view the next display This section displays the chemical box clutch status. Press the scroll down button once to view the next display (Continued on the next page)
  • Page 57 Operators manual MODEL 80XX Planter Status/ Diagnostics (Continued from the previous page) This section displays the hydraulic motor status. Press the scroll down button once to view the next display This section displays the impulses from the belt, wheel, the radar, and the working position sensor status. Press the scroll down button once to view the next display (Continued on the next page)
  • Page 58 Operators manual MODEL 80XX Planter Status/ Diagnostics (Continued from the previous page) Press the scroll down button once to view the next display Press the scroll down button once to view the next display (Continued on the next page) CP600 CONTROL BOX page 57 of 173...
  • Page 59 Operators manual MODEL 80XX Planter Status/ Diagnostics (Continued from the previous page) Press the scroll down button once to view the next display CP600 CONTROL BOX page 58 of 173...

  • Page 60: Storage Of The Cp600

    Operators manual MODEL 80XX Planter Storage The CP600 should be stored in a dry storage place away from moisture and damp areas. Keep the CP600 away from areas with excessive dust. Password The password for changing parameters in the CP600 is 11 Note: To get back out of password mode restart CP600 by turning OFF and back on again.

  • Page 61: Parameter Settings

    Operators manual MODEL 80XX Planter Parameter Settings Use the open boxes below to make NOTE of the default parameter settings before changing. Service Adjustments Spudnik Factory Specs. Service 1 Service 2 Adjustments Name & Date Name & Date Name & Date...
  • Page 62 Operators manual MODEL 80XX Planter Parameter Settings Use the open boxes below to make NOTE of the default parameter settings before changing. Service Adjustments Spudnik Factory Specs. Service 1 Service 2 Adjustments Name & Date Name & Date Name & Date...
  • Page 63 Operators manual MODEL 80XX Planter Maintenance General safety instructions Regular maintenance is a prerequisite for operational reliability. The following safety advice is to be observed during any maintenance, cleaning or repair work. To prevent accidents, all relevant rules and regulations concerning safe and competent working must be observed! •Observe the adjustment, maintenance and inspection activities and intervals specified in this operating manual, including details concerning the replacement of parts, subassemblies and equipment.
  • Page 64 Operators manual MODEL 80XX Planter Maintenance •Clean the machine, especially connections and threaded unions of any traces of oil, fuel or preservatives before carrying out maintenance/repairs. Never use aggressive detergents. Use lint-free cleaning cloths. •Before cleaning the machine with water or steam jets (high-pressure cleaners) or other cleaning agents, cover or tape all openings which –...
  • Page 65 Operators manual MODEL 80XX Planter Maintenance Special safety instructions Safety devices Never stand beneath suspended loads! Never stand or work beneath suspended loads! Engage safety catches! Never stand or work beneath suspended loads. The figures below show special safety devices for supporting loads. Adjustment and maintenance work on these parts of the machine may only be carried out with the safety devices engaged.
  • Page 66 No liability can be taken for consequences resulting from the use of other parts. When replacing electrical or hydraulic parts, ensure that only original SPUDNIK spare parts are used. The use of non-SPUDNIK parts can cause malfunctioning of the machine. Type plate on machine Machine serial number The machine serial no.
  • Page 67 Operators manual MODEL 80XX Planter Maintenance Repairs to the electrical system may only be carried out by authorized dealers. Exercise extreme care when working on engine or hydraulics – risk of serious burns! In order to keep wear down to a minimum, clean the machine thoroughly inside and outside.
  • Page 68 Operators manual MODEL 80XX Planter Maintenance Parts to be cleaned Cleaning with high-pressure cleaning equipment Clean the machine thoroughly, inside and outside. Dirt attracts moisture and leads to corrosion. The following advice should be adhered to when using high-pressure cleaning equipment to wash down the machine: Cleaning instructions: During the first six weeks do not wash down the machine with high-pressure cleaning equipment.
  • Page 69 Make a note of all maintenance work to be carried out before the next season and arrange for this to be carried out in good time. Your SPUDNIK dealer is in a better position to perform maintenance work and any repairs that may be necessary outside the season.
  • Page 70 Operators manual MODEL 80XX Planter Maintenance Screwed connections Screwed connections in general Only carry out adjustments and maintenance work when the engine is switched off! Remove ignition key! Secure the machine against rolling away! The tightening torques given in the table below do NOT apply when a different torque is specified in this manual for a particular screwed connection.
  • Page 71 Operators manual MODEL 80XX Planter Maintenance Drawbar eye for hitch and Piton-Fix couplings The screwed connection shown must be checked for tightness at the following intervals: -Prior to the first use under load, -After the first use under load, -After 50 operating hours, -After 100 operating hours, -Thereafter, every 200 operating hours.
  • Page 72 Operators manual MODEL 80XX Planter Maintenance Chassis Any adjustments or repairs to the chassis which are not shown here may only be carried out by an authorized dealer. Non-compliance with this rule invalidated the guarantee. The adjustments shown here may only be carried out when the engine is switched off! Remove ignition key! Secure machine against rolling away!
  • Page 73 Operators manual MODEL 80XX Planter Maintenance Tires Repair work to the wheels may only be carried out by an authorized dealer. Only work on the wheels when the engine is switched off! Remove ignition key! Secure the machine against rolling away! Maintain the prescribed tire pressures and measure once a week (see technical specifications) Check tire pressure daily (for 11.2-24/4 16 PLY tire –...
  • Page 74 Operators manual MODEL 80XX Planter Maintenance Chain drives Only carry out adjustments and maintenance work when the engine is switched off! Remove ignition key! Secure the machine against rolling away! Mount all guards correctly after completing any adjustments. Periodic maintenance: Check chain tension Carry out a visual inspection for damage.
  • Page 75 Operators manual MODEL 80XX Planter Maintenance Lubrication Only carry out adjustments and maintenance work when the engine is switched off! Remove ignition key! Secure the machine against rolling away! Mount all guards correctly after completing any adjustments. Only use a good quality brand-name grease, e.g. Shell Retinaz A EP2 multipurpose grease. Remove dirt from lubrication nipples prior to applying grease.
  • Page 76 Changing the filter: -Cleanliness is important when changing a filter. -Insert the new filter immediately after removing the old one. -Release filter, unscrew and replace with an original SPUDNIK filter. Insert the new filter as follows: -Moisten the sealing face with oil.
  • Page 77 Operators manual MODEL 80XX Planter Maintenance Hydraulic system Periodic maintenance: -Visual inspection for leads. -Check level Maintenance at the end of the harvesting season: -Change oil as instructed Changing the oil and checking the level: Clean the area around the filling nozzle thoroughly before filling the system with new oil. -Drain the old oil from the tank through the drain plug.
  • Page 78 Operators manual MODEL 80XX Planter Machine Parts Breakdown Description Page # Standard Parts ………………………………………………………………………………………… 79-96 Main Frame ………….……………………………………………………………………………. 79-80 Hopper Group …………………………………………………………………………………….. 81-82 Feed Chains ……………………………………………………………………………………… 83-84 Stone Furrow Openers ………………………………………………………………………….. 85-86 Row Unit Group ………………………………………………………………………………….. 87-92 Hilling Coulter …………………………………………………………………………………….. 93-96 Options ………………………………………………………………………………………………….

  • Page 79: Machine Parts Breakdown

    Operators manual MODEL 80XX Planter Machine Parts Breakdown Description Page # Hopper Extension ………………………………………………………………………………... 143-144 Hopper Tarp ………………………………………………………………………………………. 145-146 Chemical Boxes ………………………………………………………………………………….. 147-148 Chemical Box Drives …………………………………………………………………………….. 149-150 Catwalk ……………………………………………………………………………………………. 151-152 Dual Camera ……………………………………………………………………………………… 153-154 Marker Arms ……………………………………………………………………………………..155-156 Radar Gun ………………………………………………………………………………………… 157-158 Bracket Mount Terminal ………………………………………………………………………….

  • Page 80: Standard Parts

    Operators manual MODEL 80XX Planter Standard Parts Main Frame Group PARTS page 79 of 173...

  • Page 81: Main Frame

    Operators manual MODEL 80XX Planter Standard Parts Main Frame Group 8040 8060 8080 Pos. Quantity Part # Description 193869 MAIN FRAME MODEL 8040 193870 MAIN FRAME MODEL 8060 193871 MAIN FRAME MODEL 8080 192644 CHANNEL LH OR RH MAIN FRAME 80XX 131768 WELD,HITCH PIN 1-7/6x12 PLANTER 571184...

  • Page 82: Hopper Group

    Operators manual MODEL 80XX Planter Standard Parts Hopper Group PARTS page 81 of 173...
  • Page 83 Operators manual MODEL 80XX Planter Standard Parts Hopper Group 8040 8060 8080 Pos. Quantity Part # Description 192009 SIDE PANEL RIGHT MODEL 80XX 192626 HOPPER PANEL FRONT RH MODEL 8040 192019 HOPPER PANEL FRONT RH MODEL 8060 HOPPER PANEL FRONT RH MODEL 8080 192665 192630 HOPPER PANEL FRONT LH MODEL 8040...

  • Page 84: Feed Chains

    Operators manual MODEL 80XX Planter Standard Parts Feed Chains PARTS page 83 of 173...
  • Page 85 Operators manual MODEL 80XX Planter Standard Parts Feed Chains Pos. Quantity Part # Description 352390 CHN,HOOK,7"x1"PITCHx72 PITCHES W/FLITES 502305 BOLT,HEX,HD,5/8"-11UNC x 10" GR 5 501371 WASHER,FLAT,5/8" (SAE) 131807 WELD,IDLER ADJUSTER (SMALL) M00651 SPACER,TAKE-UP,SEED FEED CONVEYOR 351309 STANDOFF,RLR,BLTD,CHN,5/8"x1-1/4" #750 351314 RLR,BLTD,CHN,5/8"x4" RUBBER 171994 TUBE,SPACER SEED FEED CONVEYOR 501814...

  • Page 86: Stone Furrow Openers

    Operators manual MODEL 80XX Planter Standard Parts Stone Furrow Openers PARTS page 85 of 173...
  • Page 87 Operators manual MODEL 80XX Planter Standard Parts Stone Furrow Openers Pos. Quantity Part # Description 132595 STONE FURROW OPENER 80XX 192341 FURROW OPENER LONG MODEL 80XX 192594 BLADE OPENER 80XX 193373 PLATE FURROW OPENER RH MODEL 80XX 193374 PLATE FURROW OPENER LH MODEL 80XX 173462 SHOE,EXTENSION,80XX,2006 173217...

  • Page 88: Row Unit Group

    Operators manual MODEL 80XX Planter Standard Parts Row Unit Group PARTS page 87 of 173...
  • Page 89 Operators manual MODEL 80XX Planter Standard Parts Row Unit Group Pos. Quantity Part # Description 088.00514 LIMITING DISC [5x340] 100.43497 PULLEY [x] B96.00247 SLIDE BEARING BUSH MSM-2532-20 [x] B99.02688 SHIM,40X50X1 B99.02613 SNAPR.,40X1.75, EXT., DIN471 057.03749 BEARING RING [80x8x26] B96.00088 DEEP GROOVE BA BEARING 6008-2 [40-68-15] 088.00724 PULLEY [1x78x41] B99.02434...
  • Page 90 Operators manual MODEL 80XX Planter Standard Parts Row Unit Group PARTS page 89 of 173...
  • Page 91 Operators manual MODEL 80XX Planter Standard Parts Row Unit Group Pos. Quantity Part # Description 088.00527 SECTION RIDGE [8800527] 088.00529 GUIDE BAR R/H [70x100] 088.00528 GUIDE BAR L/H [70x100] 100.43501 INSERT PLATE [x] 089.01155 DECAL 015.31230 BRACKET LH GL34 01 500-1(43) 015.21667 BRACKET TOP OF GL ELEMENT 088.00558...
  • Page 92 Operators manual MODEL 80XX Planter Standard Parts Row Unit Group PARTS page 91 of 173...
  • Page 93 Operators manual MODEL 80XX Planter Standard Parts Row Unit Group Pos. Quantity Part # Description B94.01452 RUBBER BUSHING 015.28205 LEDGE [2x34x600] 193124 SHIELD,BIN SHAKER SPROCKET,80XX,06 173514 PLANTING UNIT ROCK COVER 8011,2006 100.77123 DROP TUBE 173505 BRACKET,ROW UNIT BIN SENSOR 8060 173225 BRACKET BIN SENSOR ROW UNIT 8060 B94.02929...

  • Page 94: Hilling Coulter

    Operators manual MODEL 80XX Planter Standard Parts Hilling Coulter PARTS page 93 of 173...
  • Page 95 Operators manual MODEL 80XX Planter Standard Parts Hilling Coulter Pos. Quantity Part # Description 200.71648 COVERING DISC ASSEMBLY 089.00577 SPACER, 30x10 100.71645 FIXING DEVICE RH B99.01840 HEXAGON NUT M16 DIN936-17H-GAL [m16] B99.03114 M16 CONTACT WASHER(OLD #B99.02 B99.01816 M8 HEX LOCK NUT, DIN985,(OLD#B B99.03095 DISC B8,4 DIN125-GAL [8.4] B99.03047...
  • Page 96 Operators manual MODEL 80XX Planter Standard Parts Hilling Coulter PARTS page 95 of 173...
  • Page 97 Operators manual MODEL 80XX Planter Standard Parts Hilling Coulter Pos. Quantity Part # Description B99.03025 PLAIN WASHER 31X61,5X3 GAL [31] B89.02198 STAR GRIP M16 NR.1731E [x] 100.52350 BRACKET [x] 100.71644 FIXING DEVICE LH 200.48403 DISC HUB [x] PARTS page 96 of 173...

  • Page 98: Options

    Operators manual MODEL 80XX Planter Options Mechanical Shaker PARTS page 97 of 173...
  • Page 99 Operators manual MODEL 80XX Planter Options Mechanical Shaker Pos. Quantity Part # Description B96.00080 DEEP GROOVE BA BEARING 6001-2 [12-28-8] 060.01750 SPACER TUBE [12x1,5x8,5] B99.01912 SET SCREW M10X12 DIN916 [10x12] 088.00531 ROLLER [48] 031.02610 AXLE [26x41] 100.55931 BRACKET [x] PARTS page 98 of 173...

  • Page 100: Hydraulic Shaker

    Operators manual MODEL 80XX Planter Options Hydraulic Shaker PARTS page 99 of 173...
  • Page 101 Operators manual MODEL 80XX Planter Options Hydraulic Shaker 8040 8060 8080 Pos. Quantity Part # Description 602332 FLOW CONTROL VALVE MANUAL 5GPM 3-WAY 602331 FLOW CONTROL VALVE ELECTRIC 5GPM 3-WAY 193679 HYD SHAKER MOUNT 80XX 231157 HOUSING,BRNG,2HOLE,52MM,FLANGETTE PLATED 231070 BRNG,INSERT,1" BORE SPHR OD 050177 SHAKER,SHAFT,80XX,2006 193029...

  • Page 102: Electrical Shaker

    Operators manual MODEL 80XX Planter Options Electrical Shaker PARTS page 101 of 173...
  • Page 103 Operators manual MODEL 80XX Planter Options Electrical Shaker Pos. Quantity Part # Description B99.02638 SNAPRING, INT.,35X1.5 088.00530 SHAKE DISC [120,8-43] B96.00014 6003 2RS 17-35-10 BEARING 037.03154 ECCENTRIC [22x23,2] B99.01936 GRUB SCREW M6X8 DIN916 [6x8] B94.02864 E-MOT,M63x25,12V,2100 U/MIN 100.43633 MOTOR BRACKET [x] B99.01912 SET SCREW M10X12 DIN916 [10x12] 031.02610...

  • Page 104: 2-Wheel Fixed

    Operators manual MODEL 80XX Planter Options 2 Wheel Fixed PARTS page 103 of 173...
  • Page 105 Operators manual MODEL 80XX Planter Options 2 Wheel Fixed Pos. Quantity Part # Description 192963 WALKBEAM,MOUNT,80XX 193115 STATIONARY WHEEL BRACKET,80XX 173329 PLATE,CLAMP,W BEAM 80XX 192973 WALKBEAM,MOUNT,80XX 602530 CYLNDR,TIE,ROD,5X8" SAE 20-1/4"3000PSI 231120 BRNG,4BOLT,FLNG,TCJ 2",ECC LOCK 173503 PIPE, 2.067 ID,3.375 OD, 2.375 LNG 951273 TIRE,&,RIM,11.25x24/12 IMPLMNT 5620/5625 951381...

  • Page 106: 16" Caster Wheel

    Operators manual MODEL 80XX Planter Options 16” Caster Wheel PARTS page 105 of 173...
  • Page 107 Operators manual MODEL 80XX Planter Options 16” Caster Wheel Pos. Quantity Part # Description 132898 CRAZY WHEEL 16" ASSY PLANTER 193046 BRACKET CRAZY WHEEL 16" 80XX 192559 REAR LIFT BRACKET MODEL 80XX 193045 CASTER MOUNT 80XX 193043 ARM, TOP, CASTER, 80XX 193044 ARM, BOTTOM, CASTER, 80XX 602620...

  • Page 108: 24" Caster Wheel

    Operators manual MODEL 80XX Planter Options 24” Caster Wheel PARTS page 107 of 173...
  • Page 109 Operators manual MODEL 80XX Planter Options 24” Caster Wheel Pos. Quantity Part # Description 132604 CRAZY WHEEL 24" ASSY PLANTER 193046 BRACKET,CASTER,80XX 192559 REAR LIFT BRACKET MODEL 80XX 193045 MOUNT,CASTER,80XX 951273 TIRE,&,RIM,11.25x24/12 IMPLMNT 5620/5625 951381 HUB ASSY 8 HOLE 2" BORE 193044 ARM,BOTTOM,CASTER,80XX 193043...

  • Page 110: Drawbar Assembly

    Operators manual MODEL 80XX Planter Options Drawbar Assembly PARTS page 109 of 173...
  • Page 111 Operators manual MODEL 80XX Planter Options Drawbar Assembly Pos. Quantity Part # Description 193108 DRAWBAR,PLANTER,80XX,2006 193336 DRAWBAR,SHORT,80XX,2006 193110 PIN,1-5/8"OD,15"LNG 981263 HITCH,DRAWBAR,200-470HP 173501 SENSOR,BRACKET,DRAWBAR, 80XX,2006 602530 CYLNDR,TIE,ROD,5"x8"x20-1/4" B94.01675 SENSOR,PROXIMITY,M18,NAMUR 050211 PIN,CYLNDR,DRAWBAR 80XX,2006 193107 DRAWBAR,ADJUSTMENT,80XX,2006 502671 NUT,ACME,1-1/2"-4,RH,THREAD 193109 DRAWBAR,MOUNTING,BRACKET,80XX,2006 173502 WRENCH,2.25 INCH 173323 PLATE,CLAMP,DRWBR 80XX-2005 050016...

  • Page 112: 4-Wheel Walking Beam

    Operators manual MODEL 80XX Planter Options 4 Wheel Walking Beam PARTS page 111 of 173...
  • Page 113 Operators manual MODEL 80XX Planter Options 4 Wheel Walking Beam 8040 8060/80 Pos. Quantity Part # Description 192963 WALKBEAM,MOUNT,80XX,2006 192964 WALKBEAM,AXLE CAP,80XX,2006 173329 PLATE,CLAMP,W BEAM 80XX-2005 192973 WALKBEAM,MOUNT,80XX,2006 602530 CYLNDR,TIE,ROD,5X8" SAE 20-1/4" 192621 AXLE,BEAM 8060/80-2005 192682 AXLE,BEAM 8040-2005 192361 MOUNT,WHEEL,WALKBEAM,80XX,2006 192965 PIN,WALKBEAM,80XX,2006 951174...

  • Page 114: Tires

    Operators manual MODEL 80XX Planter Options Tires PARTS page 113 of 173...
  • Page 115 Operators manual MODEL 80XX Planter Options Tires Pos. Quantity Part # Description 951280 TIRE,&,RIM 12.5L16 14PLY SUPPORT WHEEL 951273 TIRE,&,RIM,11.25x24/12 IMPLMNT 5620/5625 951390 TIRE,&,RIM,14.9x24 DIAMOND TREAD PLANTER 951086 RIM,16" 8 HOLE 6" PILOT PILER WHL DRIVE 951211 RIM,24x10,8HOLE,8"BC,6"PILOT 1.12"OFFSET 951388 RIM,24 x 13,8 HOLE,8"...

  • Page 116: Seed Spacing

    Operators manual MODEL 80XX Planter Options Seed Spacing PARTS page 115 of 173...
  • Page 117 Operators manual MODEL 80XX Planter Options Seed Spacing Pos. Quantity Part # Description 881287 SPRCKT,60A12x1-1/4" BORE 2003 MDL 881288 SPRCKT,60A13x1-1/4" BORE 2003 MDL 881289 SPRCKT,60A14x1-1/4" BORE 2003 MDL 881290 SPRCKT,60A15x1-1/4" BORE 2003 MDL 881291 SPRCKT,60A16x1-1/4" BORE 2003 MDL 881292 SPRCKT,60A17x1-1/4" BORE 2003 MDL 881293 SPRCKT,60A18x1-1/4"...

  • Page 118: Red Cups

    Operators manual MODEL 80XX Planter Options Red Cups PARTS page 117 of 173...
  • Page 119 Operators manual MODEL 80XX Planter Options Red Cups Pos. Quantity Part # Description 200.67487 CUP BELT 40 (RED) 088.00937 SLOTTED CUP RED 200.56433 ELEVATORBELT VZ ROTE BECHER 099.00187 ELEVATOR SCREW [m6] B99.03086 PLAIN WASHER 6,5X13X1 GALV (AR [6.5] B99.01806 HEXAGON NUT DIN985-M6-8-GAL [m6] PARTS page 118 of 173...

  • Page 120: Green Cups

    Operators manual MODEL 80XX Planter Options Green Cups PARTS page 119 of 173...
  • Page 121 Operators manual MODEL 80XX Planter Options Green Cups Pos. Quantity Article Description 200.61470 ELV WEB BELT GREEN GATE BREAKER 088.00909 GREEN GRID CUP 200.56437 ELVATORBELT VZ GRÜNE BECHER B99.01806 HEXAGON NUT DIN985-M6-8-GAL [m6] B99.03086 PLAIN WASHER 6,5X13X1 GALV (AR [6.5] 099.00187 ELEVATOR SCREW [m6] PARTS...

  • Page 122: Blue Cups

    Operators manual MODEL 80XX Planter Options Blue Cups PARTS page 121 of 173...
  • Page 123 Operators manual MODEL 80XX Planter Options Blue Cups Pos. Quantity Part # Description 200.56434 ELEVATOR BELT P184 [190x2760] (BLUE) 088.00708 BUCKET BLUE [x] 200.56435 ELV BELT bl BECHER KEIL VZ 099.00187 ELEVATOR SCREW [m6] B99.03086 PLAIN WASHER 6,5X13X1 GALV (AR [6.5] B99.01806 HEXAGON NUT DIN985-M6-8-GAL [m6] PARTS...

  • Page 124: Mechanical Drive

    Operators manual MODEL 80XX Planter Options Mechanical Drive PARTS page 123 of 173...
  • Page 125 Operators manual MODEL 80XX Planter Options Mechanical Drive 8040 8060/80 Pos. Quantity Part # Description 193330 SHIELD,UPPER,DRIVE,RH,80XX,2006 193331 SHIELD,UPPER,DRIVE,LH,80XX,2006 173606 SHIELD,INNER,RH,80XX,2006 173607 SHIELD,INNER,LH,80XX,2006 173269 PLATE SPACER MECH DRIVE 8060 193332 SHIELD,FRONT,MECH,RH,80XX,2006 193333 SHIELD,FRONT,MECH,LH,80XX,2006 192601 WHEEL,DRIVE,SHEILD 193328 PLATE,MECH DRIVE,RH,80XX,2006 193329 PLATE,MECH DRIVE,LH,80XX,2006 352265 CHN,RLR,60, MEC.
  • Page 126 Operators manual MODEL 80XX Planter Options Mechanical Drive PARTS page 125 of 173...
  • Page 127 Operators manual MODEL 80XX Planter Options Mechanical Drive 8040 8060/80 Pos. Quantity Part # Description 050104 SHAFT MODEL 80XX 881114 SPRCKT,H60BS20x1-1/4" BORE 231063 BRNG,PB,1-1/4" BORE,ECC LOCK COLLAR 352222 CHAIN,TALL SIDE DOOR,MODEL 4200 172186 SPACER,IDLER ADJ ROW UNIT 7/8"LNG PARTS page 126 of 173...

  • Page 128: Hydraulic Drive

    Operators manual MODEL 80XX Planter Options Hydraulic Drive PARTS page 127 of 173...
  • Page 129 Operators manual MODEL 80XX Planter Options Hydraulic Drive Pos. Quantity Part # Description 192598 PANEL HYDRAULIC MODEL 80XX 602329 FILTER,HIGH PRESSURE 10M WITH INDICATOR 192645 COVER PANEL MDA MODEL 80XX B94.03009 MDA-MAIN ELECTRONIC 173229 MOUNT PANEL MDA MODEL 80XX 602332 FLOW CONTROL VALVE MANUAL 5GPM 3-WAY B94.04155 SENSOR TURNING ENCODER...

  • Page 130: Depth Wheels

    Operators manual MODEL 80XX Planter Options Depth Wheels PARTS page 129 of 173...
  • Page 131 Operators manual MODEL 80XX Planter Options Depth Wheels Pos. Quantity Part # Description 193022 DEPTH,WHEEL,MOUNT,RH,80XX,2006 193023 DEPTH,WHEEL,MOUNT,LH,80XX,2006 192596 WHEEL FRAME MOUNT MODEL 80XX-2005 951284 JACK,RATCHET HEAVY DUTY #SL1541GT 501952 COLLAR,SHAFT,SET,SCREW,1-1/2" 181731 SHFT,DUMMY,1-1/2"x19" 037.03067 U-BOLT M16 GAL [16x518] 231156 BRNG,PB,2" BORE,ECC LOCK FAFNIR #TAK 2 173453 TUBE,SPACER,2-3/8"x5-15/16",80XX-05 951381...

  • Page 132: Jack Stands

    Operators manual MODEL 80XX Planter Options Jack Stand PARTS page 131 of 173...
  • Page 133 Operators manual MODEL 80XX Planter Options Jack Stand Pos. Quantity Part # Description 132497 JACK STAND ASSY MODEL 80XX 172901 JACK STAND MOUNT MODEL 80XX 191990 JACK STAND MODEL 80XX 050014 JACK STAND PIN MODEL 80XX 037.03067 U-BOLT M16 GAL [16x518] PARTS page 132 of 173...

  • Page 134: Row Unit Switch Off

    Operators manual MODEL 80XX Planter Options Row Unit Switch Off PARTS page 133 of 173...
  • Page 135 Operators manual MODEL 80XX Planter Options Row Unit Switch Off Hydraulic Drive 8040 8060 8080 Pos. Quantity Part # Description B95.01225 CARDAN SHAFT [x] 100.44724 DRIVE SHAFT [x] 100.44724 DRIVE SHAFT [x] 192586 SHAFT ROW UNIT FIRST ROW 80XX 192589 SHAFT ROW UNIT HYD DRV 80XX 200.72721 MANUAL DISCONNECT CLUTCH...

  • Page 136: No Row Unit Switch Off

    Operators manual MODEL 80XX Planter Options No Row Unit Switch Off PARTS page 135 of 173...
  • Page 137 Operators manual MODEL 80XX Planter Options No Row Unit Switch Off Hydraulic Drive 8040 8060 8080 Pos. Quantity Part # Description B95.01225 CARDAN SHAFT [x] 050095 SHAFT 050184 SHAFT,DRIVE,ROWUNIT,80XX,2006 050097 SHAFT Mechanical Drive 8040 8060 8080 Pos. Quantity Part # Description B95.01225 CARDAN SHAFT [x]...

  • Page 138: Attachments

    Operators manual MODEL 80XX Planter Attachments 4-Wheel Caster Locks PARTS page 137 of 173...
  • Page 139 Operators manual MODEL 80XX Planter Attachments 4-Wheel Caster Locks Pos. Quantity Part # Description 132405 ASSY,WHEEL LOCK,2004 502473 SCREW,SET,SQR,HD,3/8-16 x 2" 501809 NUT,HEX,3/8"-16UNC 132404 WHEEL LOCK HOUSING,2004 181716 ROLLER,PLUNGER STOP,WHEEL LOCK, PLANTER 981446 SPRING,COMPRESSION,1-1/4"OD x 4"LONG 181722 PLUNGER,WHEEL LOCK PLANTER 181882 DISK,WHEEL,LOCK PLUNGER 502601...

  • Page 140: Front Toolbar

    Operators manual MODEL 80XX Planter Attachments Front Toolbar PARTS page 139 of 173...
  • Page 141 Operators manual MODEL 80XX Planter Attachments Front Toolbar 8040 8060 8080 Pos. Quantity Part # Description 173508 BAR SOLID 173311 BAR SOLID 173312 BAR SOLID 981421 CLAMP,DIAMOND HITCH,TOOL BAR #107225 192673 TOOLBAR ARM 192674 BRACKET PARTS page 140 of 173...

  • Page 142: Rear Toolbar

    Operators manual MODEL 80XX Planter Attachments Rear Toolbar PARTS page 141 of 173...
  • Page 143 Operators manual MODEL 80XX Planter Attachments Rear Toolbar 8040 8060 8080 Pos. Quantity Part # Description 192359 TOOL BAR BRACKET REAR MDL 8060 981421 CLAMP,DIAMOND HITCH,TOOL BAR #107225 173285 TOOLBAR SQ 4 ROW 2-1/4 x 171-1/16 172856 TOOLBAR,2-1/4"SOLIDx245-7/8" 6-ROW 173308 TOOLBAR SQ 8 ROW 2-1/4 x 158-7/16 PARTS page 142 of 173...

  • Page 144: Hopper Extension

    Operators manual MODEL 80XX Planter Attachments Hopper Extension PARTS page 143 of 173...
  • Page 145 Operators manual MODEL 80XX Planter Attachments Hopper Extension 8040 8060 8080 Pos. Quantity Part # Description 194198 EXTENSION PANEL RIGHT END 80XX 194197 EXTENSION PANEL LEFT END 80XX 173928 EXT PANEL FRONT MDL 8040 173287 EXT PANEL FRONT MDL 8060 194201 EXT PANEL FRONT MDL 8080 173929...

  • Page 146: Hopper Tarp

    Operators manual MODEL 80XX Planter Attachments Hopper Tarp PARTS page 145 of 173...
  • Page 147 Operators manual MODEL 80XX Planter Attachments Hopper Tarp 8040 8060 8080 Pos. Quantity Part # Description 192676 TARP HANDLE 4-ROW 131969 HANDLE,TARP,6-ROW PLANTER 192675 HANDLE,TARP,8-ROW PLANTER 981491 TARP,RED PLANTER 4-ROW 981490 TARP,RED PLANTER 6-ROW 981637 TARP,RED PLANTER 8-ROW 80054 TARP HOLDER 4-ROW 131980 TARP HOLDER 20' BED 80053...

  • Page 148: Chemical Boxes

    Operators manual MODEL 80XX Planter Attachments Chemical Boxes PARTS page 147 of 173...
  • Page 149 Operators manual MODEL 80XX Planter Attachments Chemical Boxes 8040 8060 8080 Pos. Quantity Part # Description 981461 ASSY,HOPPER 2-DROP W/15MM RTRS MICROBAND 172396 CLAMP MICROBAND MODEL 8060 192656 BRACKET BOX SUPPORT MICROBAND 8060 192687 PLATE 172664 HEX,TUBE MICROBAND DRIVE SHAFT X 6' 821718 SHFT,DK,1-1/4"x9-5/16"(2.875-1.25)D3/8"...

  • Page 150: Chemical Box Drives

    Operators manual MODEL 80XX Planter Attachments Chemical Box Drives PARTS page 149 of 173...
  • Page 151 Operators manual MODEL 80XX Planter Attachments Chemical Box Drives Pos. Quantity Part # Description 173367 SHLD,CHEM BOX,HYD DRIVE 193334 SHIELD,CHEM DRIVE 80XX,2006 981250 KNOB,CLAMPING,W/STUD 3/8"-16x1" 5993K41 CHN,RLR,60 881054 SPRCKT,H60BS36 x 1“ BORE 881079 IDLER,60,PITCH,5/8" BORE 15 TOOTH #709 501900 COLLAR,SHAFT,SET,SCREW,5/8" 172064 PLATE IDLER ADJUSTER 231180...

  • Page 152: Catwalk

    Operators manual MODEL 80XX Planter Attachments Catwalk PARTS page 151 of 173...
  • Page 153 Operators manual MODEL 80XX Planter Attachments Catwalk 8040 8060 8080 Pos. Quantity Part # Description 192629 RAILING,CATWALK 8040 192578 RAILING,CATWALK 8060 192671 RAILING MODEL 8080 173230 CATWALK STRUT 8060 FLAT 1/4x1-1/4 173309 BAR RAILING 173231 RAILING CONNECTOR MODEL 80XX 173278 GRIP STRUT 11-3/4x2 84-1/2"...

  • Page 154: Dual Camera

    Operators manual MODEL 80XX Planter Attachments Dual Camera PARTS page 153 of 173...
  • Page 155 Operators manual MODEL 80XX Planter Attachments Dual Camera Pos. Quantity Part # Description 450218 CAMERA AUDIOVOX, 25' CABLE 450259 CAMERA,AUDIOVOX,MONITOR W/CNNCTRS. 450261 CAMERA,AUDIOVOX-VCCS130B 450258 CAMERA, SYSTEM AUDIOVOX-VCCS130B PARTS page 154 of 173...

  • Page 156: Marker Arms

    Operators manual MODEL 80XX Planter Attachments Marker Arms PARTS page 155 of 173...
  • Page 157 Operators manual MODEL 80XX Planter Attachments Marker Arms Pos. Quantity Part # Description 193062 RECEIVER,ARM,MARKER,80XX,2006 193133 MARKER,ARM,EXT,80XX,2006 602613 CYLNDR,TIE,ROD,2"x10" SAE 20-1/4" 037.03067 U-BOLT M16 GAL [16x518] 193065 MARKER,ARM CYLINDER MOUNT,80XX,2006 193066 MARKER,ARM CYLINDER MOUNT,80XX,2006 B92.04279 CHANGE-OVER VALVE EAK 701 B [x] 501357 BOLT,HEX,HD,1"-8UNC x 10"...

  • Page 158: Radar Gun

    Operators manual MODEL 80XX Planter Attachments Radar Gun PARTS page 157 of 173...
  • Page 159 Operators manual MODEL 80XX Planter Attachments Radar Gun Pos. Quantity Part # Description 402770 SENSOR,RADAR,DICKEY JOHN 44.21HZ/MPH 173331 BRACKET,RADAR GUN 8060-2005 502408 U-BOLT,3/4"-11UNC x 6-3/4"W x 8-3/16"L PARTS page 158 of 173...

  • Page 160: Bracket Mount Terminal

    Operators manual MODEL 80XX Planter Attachments Bracket Mount Terminal PARTS page 159 of 173...
  • Page 161 Operators manual MODEL 80XX Planter Attachments Bracket Mount Terminal Pos. Quantity Part # Description 173313 PLATE,CONTROL W-DRV 6400-2005 192678 MOUNT,CONTROL PANEL 6400-2005 173314 TUBE,MOUNT,PANEL 6400-2005 192677 ARM,MOUNT,PANEL 6400-2005 981250 KNOB,CLAMPING,W/STUD 3/8"-16x1" 5993K41 PARTS page 160 of 173...

  • Page 162: Small Depth Wheels

    Operators manual MODEL 80XX Planter Attachments Small Depth Wheels PARTS page 161 of 173...
  • Page 163 Operators manual MODEL 80XX Planter Attachments Small Depth Wheels Pos. Quantity Part # Description 951261 TIRE,20.5/8.0-10/10 LOW PROFILE W/STEM 951260 RIM,10"x8-10,5 HOLE 4.5" BC 173459 GAGE,WHEEL,DPTH,AJST,80XX,2006 501713 NUT,LOCK,HEX,1"-8UNC NYLON INSERT 173457 GAGE,WHEEL,ARM,80XX,2006 171857 SPACER,PIPE,1-1/4" LG. 8" & 12" CRZY WH 171856 SPACER,PIPE,1"LG.
  • Page 164 MACHINE: PLANTER80XX­REV­A Order: Contents: COVERSHEET HYDRAULIC CASTER OPTIONS WALKING BEAM 8040 /47 /60 /80 / MARKER ARM STEERING AXLE / RETURN TO CENTER FEED CHAIN/HYD. SHAKER LOW COST BOX FEED CHAIN /HYD. DRIVE /HYD. SHAKER PROF. CONTROL DRY FERTILIZER / FILL AUGER OVERVIEW ELECTRIC 6 ROW PROF. CONTROL CABLE HARNESS 6 ROW PROF. CONTROL CABLE HARNESS 8 ROW PROF. CONTROL EXT. HARNESS 6 ROW LOW COST HARNESS 6 ROW LOW COST HARNESS 8 ROW LOW COST EXT. HARNESS W­HARNESS­SENSOR/VALVE EXTENSIONS date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC Coversheet User 100N 584W  BLACKFOOT,ID,83221 Proved Sheet Standard Origin Repl. f. Repl. by Status change date name www.spudnik.com...
  • Page 165 601892 601477 602257 602257 601446 601048 601048 602257 602257 601446 601446 601048 601048 602596 2.00"x10" 3.00"x10" 602613 602620 601477 2.00"x10" 602613 date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC HYDRAULIC CASTER OPTIONS User 100N 584W  BLACKFOOT,ID,83221 Proved Sheet Standard Origin Repl. f. Repl. by Status change date name www.spudn k.com...
  • Page 166 602211 601390 601892 601477 601323 601477 602207 602221 601956 601323 601477 601048 602211 601322 601477 601390 601892 601477 602221 602207 601048 date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC WALKING BEAM 8040 /47 /60 /80 / MARKER ARM User 100N 584W  BLACKFOOT,ID,83221 Proved Sheet Standard Origin Repl. f. Repl. by Status change date name www.spudn k.com...
  • Page 167 601390 601446 602207 601390 601048 602061­ FA6411 AUTO RETURN TO CENTER 601213 601577 601446 601323 601048 601577 601446 601323 601048 602414 602414 4"x6" 4"x6" FA6121 STEE WALKING BEAM date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC STEERING AXLE / RETURN TO CENTER User 100N 584W  BLACKFOOT,ID,83221 Proved Sheet Standard Origin Repl. f. Repl. by Status change date name www.spudn k.com...
  • Page 168 ELECTRIC SHAKER W/PROF CONTROL TERMINAL HOSE A HOSE B 4 ROW 602258 602235 6 ROW 601711 601748 8 ROW 601748 601739 601378 601390 601390 601390 601048 601390 HYDRAULIC SHAKER  WITHOUT PROF. CONTROL TERMINAL 601048 date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC FEED CHAIN/HYD. SHAKER LOW COST BOX User 100N 584W  BLACKFOOT,ID,83221 Proved Sheet Standard Origin Repl. f. Repl. by Status change date name www.spudn k.com...
  • Page 169 601030 601030 601030 601030 601030 601030 601637 601637 HOSE A HOSE B 4 ROW 602258 602235 6 ROW 601711 601748 8 ROW 8 ROW 8 ROW 601748 601739 date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC FEED CHAIN /HYD. DRIVE /HYD. SHAKER PROF. CONTROL User 100N 584W  BLACKFOOT,ID,83221 Proved Sheet Standard Origin Repl. f. Repl. by Status change date name www.spudn k.com...
  • Page 170 601390 601406 601048 602696 FLOW CONTROL DRY FERT. 602009 601390 601406 601993 601993 601993 601993 601048 601849 601849 602696 FILL AUGER FERTILIZER CUSTOMER INSTALLATION date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC DRY FERTILIZER / FILL AUGER User 100N 584W  BLACKFOOT,ID,83221 Proved Sheet Standard Origin Repl. f. Repl. by Status change date name www.spudn k.com...
  • Page 171 P4­9 B94.03009M P4­8 P4­7 P4­6 P4­5 P4­4 P4­3 P4­2 P4­1  P4  P1  P3 MCS 3000 MDA II  450152 ROWS OFF  CHEMICAL POWER DELAY SPUDNIK CABLE HARNESS  402760 W­HARNESS,8040/8060­LOW­05­CURRENT 402761 W­HARNESS,8080­EXT­LOW­05­CURRENT Professional Control Terminal LOW COST CONTROL TERMINAL date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC OVERVIEW ELECTRIC User 100N 584W  BLACKFOOT,ID,83221 Proved Sheet Standard Origin Repl. f. Repl. by Status...
  • Page 172 48" 204" 90" 24" 10" 10" 32" /10. 27" 13" 27" 13" 24" 4" 13" 4" REV­1 08/01/06 date 02/02/07 WHEEL / BELT ENCODER WITH M12 CONNECTOR/ LENGTH CHANGED SPUDNIK EQUIPMENT COMPANY LLC 6 ROW PROF. CONTROL CABLE HARNESS 100N 584W  Sheet REV­2 08/04/06 User CHANGED CON A/B to 45° BLACKFOOT,ID,83221 402758 Proved www spudnik com We reserve all rights in this document and in the information  contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden.© SPUDNIK EQUIPMENT Status date name change...
  • Page 173 84" 60" 360" 80" 85" 60" 84" 18" 27" 13" 27" 13" 27" 13" REV­1 08/01/06 date 02/02/07 WHEEL / BELT ENCODER WITH M12 CONNECTOR/ LENGTH CHANGED SPUDNIK EQUIPMENT COMPANY LLC 6 ROW PROF. CONTROL CABLE HARNESS 100N 584W  Sheet REV­2 08/04/06 User CHANGED CON A/B to 45° BLACKFOOT,ID,83221 402758 Proved www spudnik com We reserve all rights in this document and in the information  contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden.© SPUDNIK EQUIPMENT Status date name change...
  • Page 174 SHAKER SHAKER  SENSOR  3 2 1 3 2 1 84" 60" 90" 84" 60" 90" 12" 27" 13" 27" 12" date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC 8 ROW PROF. CONTROL EXT. HARNESS 100N 584W  Sheet User BLACKFOOT,ID,83221 402759 Proved www spudnik com We reserve all rights in this document and in the information  contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden.© SPUDNIK EQUIPMENT Status date name change...
  • Page 175 CHEMICAL CLUTCH 80" 84" 80" 66" 36" 90" /13. 27" 13" 27" 13" 27" 24" 6" 24" ­ 08/01/006 date 02/02/07 ­ SPUDNIK EQUIPMENT COMPANY LLC 6 ROW LOW COST HARNESS 100N 584W  Sheet User BLACKFOOT,ID,83221 402760 Proved www spudnik com We reserve all rights in this document and in the information  contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden.© SPUDNIK EQUIPMENT Status date name change...
  • Page 176 BATTERY POWER 8­ROW  CONNECTION 84" 90" 84" 80" 84" 360" 85" 84" /12. 18" 27" 13" 27" 13" 27" 13" date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC 6 ROW LOW COST HARNESS 100N 584W  Sheet User BLACKFOOT,ID,83221 402760 Proved www spudnik com We reserve all rights in this document and in the information  contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden.© SPUDNIK EQUIPMENT Status date name change...
  • Page 177 FEED  FEED  B N  BIN  CHAIN  CHAIN  SENSOR  SENSOR  M12x1 M12x1 110" 90" 84" 80" 12" 13" 27" 12" date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC 8 ROW LOW COST EXT. HARNESS 100N 584W  Sheet User BLACKFOOT,ID,83221 402761 Proved www spudnik com We reserve all rights in this document and in the information  contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden.© SPUDNIK EQUIPMENT Status date name change...
  • Page 178 +12V / C16 +12VDC(1) ­31 / C34 B(2) ­31 / C34 GND(3) B94.04155 1024 A(4) B94.02240M ENCODER FERTILZER 450194 ­31 / A12 ­31 / A12 25ft 450196 FLOW CONTROL FERT. 402869 EXT. HARNESS DRY FERT. OPTION 450196 HYDRAULIC SHAKER 402870 EXT. HARNESS HYD. SHAKER OPTION date 02/02/07 SPUDNIK EQUIPMENT COMPANY LLC W­HARNESS­SENSOR/VALVE EXTENSIONS 100N 584W  Sheet User BLACKFOOT,ID,83221 Proved www spudnik com We reserve all rights in this document and in the information  contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden.© SPUDNIK EQUIPMENT Status date name change...
  • Page 179 Operators manual MODEL 80XX Planter Notes: page 163 of 173...

This manual is also suitable for:

8040806080808040-55-328060-55-558080-55-33

Table of Contents

Save PDF
