- Page 1 Surge Protector Series User Manual Model : SP006H High Performance 10G Ethernet Surge Protector Smart Cabling & Transmission Corp. V1.0...
- Page 2 User Manual SP006H Introduction SP006H is an in-line RJ45 surge protector designed to protect valuable HDBaseT and network devices from high voltage surges, with network bandwidth up to 10Gbps. Features Supports bandwidth up to 10Gbps Built-in ESD, EFT (impulse noise) protection.
- Page 3 User Manual SP006H Specification ITEM NO. SP006H Support IEC 61000-4-2, IEC 61000-4-5 Compliance Network Bandwidth 10 Gbps (Max) Response Time Less than 1ns ESD Protection 15KV(Air),8 KV (Contact) Lightning Protection 2KA (8/20μs)/6KV (8/20μs) Surge Life 300 times (100A per surge) Normal Resistance Across Coax 10,000 MΩ...
