- Page 1 Surge Protector Series User Manual Model : SP006PH High Performance 1G PoE Surge Protector Smart Cabling & Transmission Corp. V1.0 V1.0...
- Page 2 User Manual SP006PH Introduction SP006PH is an in-line surge protector designed to protect PoE (Power over Ethernet) devices from high voltage surges, with network bandwidth up to 1000Mbps. Features Supports bandwidth up to 1000 Mbps. Supports IEEE 802.3af, 802.3at, 802.3bt PoE standard.
- Page 3 User Manual SP006PH RJ45 Pinout: (TIA/EIA-568-B) (PIN TIA/EIA-568B) Wire Color Orange-white Orange Green-white Blue Blue-white Green Brown-white Brown Application Computer Control Rooms Educational Institutions Server Farms Commercial Offices Manufacturing Facilities Transmitter and Receiver Stations ...
- Page 4 User Manual SP006PH Specification ITEM NO. SP006PH Support Compliance IEEE 802.3af, 802.3at, 802.3bt, IEC 61000-4-2, IEC 61000-4-5 Network Bandwidth 10/100/1000 Mbps Response Time Less than 0.7nS ESD Protection 30KV (Air), 30kV Contact) Lightning Protection 10KA (8/20 us), 20KV (8/20 us) Ports &...
