SC&T SP006PH-10G User Manual

High performance 10g poe surge protector

Advertisement

Quick Links

Surge Protector Series
User Manual
Model :
SP006PH-10G
High Performance 10G PoE Surge Protector
Smart Cabling & Transmission Corp.
V1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the SP006PH-10G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SC&T SP006PH-10G

  • Page 1 Surge Protector Series User Manual Model : SP006PH-10G High Performance 10G PoE Surge Protector Smart Cabling & Transmission Corp. V1.0...
  • Page 2 User Manual SP006PH-10G Introduction SP006PH-10G is an in-line surge protector designed for preventing damage to PoE (Power over Ethernet) devices from high voltage surges. Features Surge current up to 20KA • Supports data rate up to 10Gpbs • Supports Mid-Span and End-Span PoE •...
  • Page 3 User Manual SP006PH-10G Panel view Front Rear Interface Function Input Connector To connect the cable transmission side GND Connection To connect the ground Protected Connector To connect the device to be protected RJ45 Pin Define ( TIA/ EIA-568-B ) Pin Color...
  • Page 4 • Only the port marked “protected” can prevent your PoE device from surges, so we recommend using a SP006PH-10G for each of your PoE device that needs to be protected. • Ensure the input port connects to a network cable as below.
  • Page 5: Specification

    User Manual SP006PH-10G Specification ITEM NO. SP006PH-10G Support IEEE 802.3af PoE IEEE 802.3at PoE+ IEEE 802.3bt PoE++ Compliance Passive PoE Compatible IEC 61000-4-2 Standard IEC 61000-4-5 Standard UL497B Data Rate 10/ 100/ 1000/ 10000Mbps Operation Voltage < 58V Operating Current...
  • Page 6 User Manual SP006PH-10G Installation Guide Accessory Machine Screw Self-drilling Screw Screw Plug Angle Bracket DIN-rail Mounting Plat 1U Rack Installed on a Platform Step 1 Use machine screws to fix angle brackets on both sides of your product...
  • Page 7 User Manual SP006PH-10G Step 2 Use self-drilling screws to fix the product on a platform Step 3 Move the product to get fixed and then lock the screws...
  • Page 8 User Manual SP006PH-10G Installed on Wall Step 1 Same way as “Installed on a Platform”, but need to put screw plugs into the wall before inserting the screws (leave 2mm space from the platform) Installed on a Din-Rail Step 1 Use machine screws to fix a din-rail mounting plat on the side of your product...
  • Page 9 User Manual SP006PH-10G Step 2 Install your product on a DIN-rail as following instruction Installed on a Rack Step 1 Lock machine screws in the rack Step 2 Put your products on the rack...
  • Page 10 User Manual SP006PH-10G Step 3 Push the products to the other side of the rack Step 4 Install the rack in a cabinet...
