- Page 1 Surge Protector Series User Manual Model : SP007 HD-SDI Surge Protector Smart Cabling & Transmission Corp. V1.0...
- Page 2 User Manual SP007 Introduction SP007 is a surge protector designed to protect a valuable SDI device from high voltage surge, with video bandwidth up to 2.97G. Features Supports 3G-SDI, and HD-SDI video formats Supports video bandwidth at 270M, 1.5G, 2.97G.
- Page 3 User Manual SP007 Specification ITEM NO. SP007 Support Video Bandwidth 270M to 2.97Gb/s Insertion Loss 1.1dB@ 2.97Gb/s Max Clamping Voltage Response Time Less than 1ns 8KV (Max) Resist Surge Ports & Interfaces BNC Male (75Ω) Equipment End BNC Female (75Ω)
