Summary of Contents for SC&T SP003
- Page 1 Surge Protector User Manual Model : SP003 HD-TVI/AHD/HDCVI/CVBS & Data Surge Protector (RJ45 Connector) Smart Cabling & Transmission Corp. V1.0...
- Page 2 User Manual SP006 Introduction SP003 is a surge protector designed to protect HD-TVI, AHD, HDCVI, CVBS and data devices from high voltage surges, supporting resolution up to 4K (8MP).. Features Supports HD-TVI, AHD, HDCVI, CVBS and data signals. Use two pairs (Pin 3, 6, 7, 8) for surge protection.
- Page 3 User Manual SP006 Specification ITEM NO. SP003 Support Video Resolution 4K (8MP) Response Time <1ns Max. Surge Voltage 4 kV Surge Life 300 surges/ 100Amps Normal Resistance Across Coax 10,000 MΩ Surge Resistance Approx. 0Ω Band Pass 0~1 GHZ Power Passing Capability...
