- Page 1 Surge Protector Series User Manual Model : SP009T UTP HD-TVI/AHD/HDCVI/CVBS Video Surge Protector Smart Cabling & Transmission Corp. V1.0...
- Page 2 User Manual SP009T Introduction SP009T is a surge protector designed to protect HD-TVI, AHD, HDCVI, CVBS devices from high voltage surges. Features Protects HD-TVI, HDCVI, AHD signals from high voltage surge. Built-in terminal blocks. Response time less than 1 ns.
- Page 3 User Manual SP009T Specification ITEM NO. SP009T Support Compliance IEC 61000-4-5 Response Time Less than 1ns Lightning Protection 2KA (8/20μs)/6KV (8/20μs) Insertion Loss 0.8dB@42MHz Max. Discharge Current 15 KA (Max) Max. Clamping Voltage Starting Voltage Surge Ports & Interfaces Equipment End...
