SC&T SP016N Manual

NETWORK / POE 16 Channel Surge Protection Device

ITEM NO.: SP016N, SP016P
Application for protects equipment from high voltage surges such as lightning strikes. UL grounding
requirements for coaxial cable offer protection from hazardous voltages that may occur on the shielding.
Because of the physical length of ground wires, UL grounding systems may appear as an open circuit to
lightning caused, high frequency surges and provide no protection from these surges getting into a home
and destroying NVR, network , POE camera, POE hub deveices etc.
SP016N 16 Channel Network Surge Protector for NVR in 1U Rack Mounting Panel

16 x RJ45 Jack to 16x RJ45 Jack.

10/100/1000 Base-T CAT5/CAT5e compatible.

Provide protection for NVR, network, PC modem, server or any computer equipment with multiple inputs
protection.
SP016P 16 Channel POE Surge Protector for POE Hub in 1U Rack Mounting Panel

16 x RJ45 Jack to 16x RJ45 Jack

Application for 16 channel POE hub (Power over Ethernet) protection.

10/100/1000 Base-T CAT5/CAT5e compatible.

Support Mid-Span POE and End Span POE.

802.3af POE compatible.
Installation View:
SP016N
SP016P
Note:
For ensuring the unit can
protect equipments, the cable
must be connected to ground.
1
