- Page 1 Surge Protector Series User Manual Model : SP006PHO High Performance Outdoor 1G PoE Surge Protector Smart Cabling & Transmission Corp. V1.0 V1.0...
- Page 2 User Manual SP006PHO Introduction SP006PHO is an in-line surge protector designed to protect a valuable outdoor PoE (Power over Ethernet) device from high voltage surges, with network bandwidth up to 1000Mbps. Features Supports bandwidth up to 1000 Mbps. Supports IEEE 802.3 af, 802.3 at, 802.3bt PoE standard.
- Page 3 User Manual SP006PHO Installation Guide: IP66 Waterproof Accessories Assemble the waterproof connector. Put a network cable and grounding wire through the connector.
- Page 4 User Manual SP006PHO Put the cable set into the waterproof case and use the screw nut (#5) to fix it from inside. Use TIA/ EIA-568-B standard to make a RJ45 connector. Connect the network cables to RJ45 connectors. Fix the grounding wire.
- Page 5 User Manual SP006PHO Put on the cover and screws to firmly fix the waterproof case. Note: Make sure the notch is matched.
- Page 6 User Manual SP006PHO Specification ITEM NO. SP006PHO Support Compliance IEEE 802.3 af, 802.3 at, 802.3bt IEC 61000-4-5, IEC 61000-4-2, EN61000-4-5 Network Bandwidth 10/100/1000 Mbps Response Time Less than 0.7nS ESD Protection 30KV (Air)/ 30KV( Contact) Lightning Protection 10KA (8/20 us), 20KV (8/20 us)
