- Page 1 Surge Protector Series User Manual Model : SP009 UTP HD-TVI/AHD/HDCVI/CVBS Video Surge Protector Smart Cabling & Transmission Corp. V1.0...
- Page 2 User Manual SP009T Introduction SP009 is a surge protector designed to protect HD-TVI, AHD, HDCVI, CVBS devices from high voltage surges. Features Resolution up to 4K (8MP) Built-in BNC connectors. Response time less than 1 ns. Installation View...
- Page 3 User Manual SP009T Specification ITEM NO. SP009 Support Compliance IEC 61000-4-5 Response Time Less than 1ns Lightning Protection 2KA (8/20μs)/6KV (8/20μs) Insertion Loss 0.8db @ 42 MHz Max. Discharge Current 15 KA Ports & Interfaces Equipment End 1 x BNC Male...
