- Page 1 HD-TVI/ AHD/ HD-CVI/ CVBS Amplifier Series User Manual Model : CA101HDP HD-TVI/AHD/HDCVI with Power over one Coax 400M with 24VDC power Smart Cabling & Transmission Corp. V1.0...
- Page 2 CA101HDP Introduction CA101HDP is a video amplifier designed to use an RG59 coaxial cable to send a video signal and power source for a long distance with a transmission distance up to 1000M. Allow to use one power adapter for multiple amplifiers ——...
- Page 3 User Manual CA101HDP Transmission Distance Chart based on Power Input Voltage/Current The output current will be slightly different based on different cable. CA101HDPR Receiver CA101HDPT Transmitter Cable Type Distance Power Input DC12V Output for Camera 370mA 100M 350mA 150M 320mA RG59 DC24V 1.25Amp...
- Page 4 Before sending power, please make sure the voltage polarity and input/output terminal are installed correctly. Package Include CA101HDPT x 1pcs CA101HDPR x 1pcs DC24V 1.25Amp power adapter x 1 or DC40V 1Amp (MODEL NO: CA101HDP-40V) DC plug to Stripping bare wire power cord x 1 Mounting screw pack x 1 Specification ITEM NO.
