UC-M150-UPGRD
Crestron Flex Upgrade Solution for Crestron Mercury® Conference Systems
The Upgrade Solution for Crestron Mercury® Conference Systems
(UC-M150-UPGRD) upgrades a Crestron Mercury conference system to
a Crestron Flex UC-M150-T system. The UC-M150-T delivers a powerful
solution for knowledge workers who want the Microsoft Teams®
software experience in small to midsize meeting and conference rooms.
The UC-M150-UPGRD comes with a UC-BRKT-100-ASSY Wall Bracket
Assembly which contains an HD-CONV-USB-200 HDMI® to USB 3.0
Converter, UC-ENGINE, and required mounting hardware. The solution
also comes with a CCS-CAM-USB-F-400 Huddly IQ™ Collaboration
Camera, a UC-CAM-WMK wall mount kit, and all of the cables required to
complete the installation.
Minimum Requirements
A video display, connected to the UC-ENGINE. The system supports a
l
second display if desired.
A Microsoft Teams or Skype® for Business software account
l
An environment running Microsoft Exchange Server® software (2013
l
SP1 or later for on-premises installation or Microsoft 365® software
for Cloud) for scheduling and/or Skype for Business 2015
(on-premises installation or Microsoft 365 software for Cloud)
View the Crestron Flex Pre-Deployment Checklist
Crestron Flex installation.
Optional
CCS-UCA-SMK Swivel Mount Kit
l
CCS-UCA-MIC KIT Microphone Pods
l
to help plan your
In the Box
UC-BRKT-100-ASSY, UC Engine Bracket Assembly
1 UC-BRKT-100-ASSY (6510636)
1 Power cord
Mounting Hardware
Accessory Box
1 CCS-CAM-USB-F-400, Huddly IQ Collaboration Camera
(6510482)
1 CBL-CAT5E-7, CAT5e cable RJ-45-to-RJ-45, Black,
7 ft (2.1 m) (6509924)
1 CBL-HD-THIN-HS-6, Thin HDMI cable, 6 ft (1.8 m) (6510946)
1 CBL-HD-20, HDMI cable 20 ft (6.1 m) (6503567)
1 CBL-USBC-HD-9, USB 3.0 to HDMI Converter cable,
9 ft (2.7 m) (6510718)
1 CBL-USB-A-EXT-15 USB Extension Cable, Type A
Male-to-Female, 15 ft (4.6 m) (6508260)
1 UC-CAM-WMK, Wall Mount Kit for Crestron Cameras
(6510998)
Quick Start
