Installation and Operating Instruction for
1. Mounting preparations
Work on the 230 V mains supply
may only be carried out by qualified
professionals or by instructed persons
under the direction and supervision of
qualified skilled electrical personnel
in accordance with electrotechnical
regulations.
Disconnect supply before installing!
When in Master/ Slave mode of
operation, the Master-appliance
must always be installed at the
location where there is least
daylight.
Option:
max
max
ON
ON
OFF
OFF
max
ON
OFF
max
ON
Wall bracket for remote control
OFF
IR-PDim
max
ON
OFF
4. Exclude sources of
interference
In case the sensing area of the
LUXOMAT PD9-M-DIM(-GH) is too
®
large or areas are being covered that
should not be monitored, the range
can be reduced or limited through use
of the enclosed masking clips.
B.E.G. -
2a. Installation
The detector has
34 mm
been designed and
developed specifi-
cally for installation in
suspended ceilings.
A circular opening of
diameter min. 34 mm
must be produced in
the ceiling.
Having connected the cables in accordance with the
regulations, connect the power supply via the RJ11
plug. Therefore, open the power supply with the help
of the screws and close it afterwards. After that, put
the power supply through the opening in the ceiling
and mount the sensor onto the ceiling according to
figure.
Unlocking device
Luminance set point for constant light regulation
50
1500
Lux Lux 50
50 1500
Lux
Lux
Lux
50 1500
Lux
Lux
Dimming
max
The following approach will prove useful when setting a
max
command value (example workplace): Place a luxmeter flat
on the desk, then, using the remote control IR-PDim, adjust
ON
the light up or down by pressing the keys max or min until
ON
the desired command value which best suits your require-
OFF
ments has been reached.
OFF
Automatic reading in the current light value
50
as new luminance set point
Lux
50
50
1500
Individual light value 2 - 2500 Lux Lux
Lux Lux
max
Follow-up time
50 1500
max
Lux
max Lux
1 upto 30 min.
ON
Orientation lighting and its follow-up time
ON
ON
OFF button:
No orientation light
20 %
OFF Grey button:
Programming the switch-off delay time
OFF
OFF
On button:
Orientation light is permanently activated.
50 1500
Note: During the orientation light phase, the constant light
Lux
Lux
regulation is also active: if there is sufficient brightness,
dimming occurs < 2 V and, if applicable, the lighting is
switched off.
Preset/ user mode => (see page 2, point 8)
Fully automatic/semi automatic mode => (see page 2, point 7)
Semi automatic: green LED,
Fully automatic: red LED on for ca. 3 sec.
50 1500
Lux
Lux
Resetting when open
All values which have been programmed using the remote
control IR-PDim are deleted, and those values which have
been set by potentiometer are activated.
Lock device
5. Range of Coverage
PD9-M-DIM
2.50 m
2
3
1
PD9-M-DIM(-GH)
®
Occupancy detectors
2b. Connecting
terminals
L L' N
1500
Lux
1500
Lux
1500
Lux
1-10
VDC
max
ON
OFF
PD9-M-DIM-GH
9.00 m
1 quer zum Melder gehen Walking across
2
frontal zum Melder gehen Walking towards
3 Seated
Unterkriechschutz
PD9-Master-DIM (-GH)-FC
2c. Self test cycle
R S
LUXOMAT
The ® PD9-M-DIM
(-GH) enters an initial 60-sec-
ond self-test cycle, when the
supply is first connected. The
occupancy detector is ready for
operation.
Lock device
Test mode
Reset to deactivate
Resetting when closed
The lighting relay is switched off, i.e.
opened and the follow-up times reset.
Permanent protection against sabotage
This function blocks the unit permanently (green LED is
illuminated). This operating mode can only be activated
during the period of 5 seconds after pressing the "lock"
button. This status will only permit actuating the function
"Light on/ Light off".
The procedure for leaving this mode is as follows:
1. Switch off the current
2. Apply current for 31 - 59 seconds
50
1500
Lux
Lux
3. Switch of the current again
4. Apply current
5. Open detector
Light on/ off => (see page 2, point 9)
The light will remain switched on/ off for as long as move-
ments are detected in the areas of coverage. Once the last
movement has been detected, the light will remain on for
the duration of the follow-up time as per setting.
The appliance will then return independently to the mode
selected (Fully or Semi-automatic).
6. Dimensions
PD9-M-DIM
25
45
165 mm
GB
3. Settings carried out
using remote control
(optional)
LUXOMAT
®
IR-PDim Remote Control
1. Check Battery:
Open battery compartment
by pressing the plastic springs
together and removing the
battery-holder.
PD9-M-DIM-GH
25
45
24 mm
24 mm
