B.E.G. LUXOMAT PD9-M-DALI/DSI-FC Installation And Operating Instruction

LUXOMAT
Installation and Operating Instruction for B.E.G. - Occupancy detectors PD9-M-DALI/DSI-FC und PD9-M-DALI/DSI-GH-FC

1a. Features

* For connection of up to 12 lamps
* Suitable for dimmable electronic
ballasts and control modules
* DALI/DSI output
* Constant light control
* Manual switching/dimming
* Semi or completely automatic
operation
* Luminance (brightness) set point,
switch-off delay time for LIGHT and
orientation-light adjustable
* Sensor and power sections in one
housing
* Infrared remote control
Option:
max
ON
max
OFF
ON
Wall bracket for remote control
IR-PD-DALI OFF
max
ON
OFF
4. Exclude sources of
interference
PD9-FC PD9-GH-FC
In case the sensing area of the
PD9-M-DALI/DSI(-GH) is
LUXOMAT
®
too large or areas are being covered
that should not be monitored, the range
can be reduced or limited through use
of the enclosed masking clips.

1b. Mounting preparations

Work on the 230 V mains supply
may only be carried out by quali-
fied professionals or by instructed
persons under the direction and
supervision of qualified skilled
electrical personnel in accordance
with electrotechnical regulations.
Disconnect supply before installing!
When in Master / Slave mode of
operation, the Master-appliance
must always be installed at the
location where there is least
daylight.
Unlocking device
Switching between DSI and DALI program
DSI/
DALI
Factory setting DSI, press 1 x DALI, press 2 x DSI
(Toggle-function)
+ –
Luminance set point for constant light regulation
+
50
+ / – small steps
Lux
50
1500
Lux
Lux
Dimming
max
The following approach will prove useful when setting a
max
command value (example workplace): Place a luxmeter flat
on the desk, then, using the remote control IR-PD-DALI, adjust
ON
the light up or down by pressing the keys max or min until
ON
the desired command value which best suits your require-
ments has been reached.
OFF
OFF
Automatic reading in the current light value
50
as new luminance set point
Lux
50
Individual light value 2 - 2500 Lux
50
1500 Lux
Lux
Lux
max
Follow-up time (relay and channel 1)
50 1500
max
Lux
1 upto 30 min. Lux
max
ON Orientation lighting and its follow-up time
ON
OFF button: No orientation light
ON
20 %
Grey button: Programming the switch-off delay time
50
1500
OFF
Lux Lux
On button: Orientation light is permanently activated.
OFF
OFF
Note: During the orientation light phase, the constant light reg-
ulation is also active: if there is sufficient brightness, dimming
occurs < 2 V and, if applicable, the lighting is switched off.
Preset / user mode => (see page 2, point 8)
Fully automatic/semi automatic mode => (see page 2, point 7)
Semi automatic: green LED,
Fully automatic: red LED on for ca. 3 sec.
50
1500
Resetting when open
Lux
Lux
All values which have been programmed using the remote
control IR-PD-DALI are deleted, and those values which have
been set by potentiometer are activated.
Lock device

5. Dimensions

PD9-M-DALI/DSI PD9-M-DALI/DSI-GH
25
45
165 mm
PD9-M-DALI/DSI(-GH)
®
2a. Installation LUXOMAT ®
DALI/DSI(-GH)-FC
The detector has
min. 34 mm
22 - 30 mm
been designed and
developed specifi-
cally for installation in
suspended ceilings.
A circular opening of
diameter min. 34 mm
must be produced in
the ceiling.
Having connected the cables in accordance with
the regulations, connect the power supply via the
RJ11 plug. Therefore, open the power supply with
the help of the screws and close it afterwards. After
that, put the power supply through the opening in
the ceiling and mount the sensor onto the ceiling
according to figure.
–
1500
/ big steps
Lux
1500
Lux
1500
Lux
max
ON
OFF
25
45
24 mm
24 mm

2b. Self test cycle

PD9-M-
The LUXOMAT
®
DALI/DSI(-GH) enters an
initial 60-second self-test
cycle, when the supply
is first connected. The
occupancy detector is
ready for operation.
Lock device
Test mode
Reset to deactivate
Resetting when closed
The lighting relay is switched off, i.e.
opened and the follow-up times reset.
Permanent protection against sabotage
This function blocks the unit permanently (green LED is
illuminated). This operating mode can only be activated
during the period of 5 seconds after pressing the "lock"
button. This status will only permit actuating the function
"Light on/ Light off".
The procedure for leaving this mode is as follows:
1. Switch off the current
2. Apply current for 31 - 59 seconds
3. Switch of the current again
50
1500
4. Apply current
Lux
Lux
5. Open detector
Light on/ off => (see page 2, point 9)
The light will remain switched on/off for as long as move-
ments are detected in the areas of coverage. Once the last
movement has been detected, the light will remain on for
the duration of the follow-up time as per setting.
The appliance will then return independently to the mode
selected (Fully or Semi-automatic).

6. Range of Coverage

PD9-M-DALI/DSI
1
2.50 m
2
3
3 2
1
PD9-M-DALI/DSI-GH
Overview range in dependence from the mounting
height
Mounting Range (circular detection) T=18°C
height walking across
5.00 m Ø=3.00 m
6.00 m Ø=3.50 m
7.00 m Ø=4.20 m
8.00 m Ø=4.80 m
9.00 m Ø=5.40 m
10.00 m Ø=6.00 m
GB
3. Settings carried out
using remote control
(optional)
Remote control LUXOMAT
®
IR-PD-DALI
Check Battery:
PD9-M-
Open battery compartment
by pressing the plastic
springs together and remo-
ving the battery-holder.
Walking across quer zum Melder gehen
frontal zum Melder gehen Walking towards
Unterkriechschutz
Seated
RJ 9,00 m
