Title:
Part Number:
Print Date:
Revision/Date:
This supplement contains information necessary to ensure the accuracy
of the above Instruction Sheet.
© 2013 - 2021 Fluke Corporation.
All rights reserved.
Supplement
9040 Users
2438546
April 2005
2, 5/11
Supplement Issue: 3
Issue Date:
Page Count:
11/21
8
x
Advertisement
Related Manuals for Fluke 9040
Summary of Contents for Fluke 9040
- Page 1 Supplement Issue: 3 Part Number: 2438546 Issue Date: 11/21 Print Date: April 2005 Page Count: Revision/Date: 2, 5/11 This supplement contains information necessary to ensure the accuracy of the above Instruction Sheet. © 2013 - 2021 Fluke Corporation. All rights reserved.
- Page 2 9040 Users Manual Supplement Change #1, 65800 On page 5, add the following to the Symbols table: Ã Conforms to relevant South Korean EMC Standards. Change #2, 448, 506 On page 3, add the following Warnings: • Read all safety information before you use the Product.
- Page 3 Manual Supplement 9040 Users • Do not keep the Product in operation and unattended at high temperatures. On page 8, add the following Warning: XWWarning To prevent possible electrical shock, fire, or personal injury, do not operate the Product with covers removed or the case open.
- Page 4 9040 Users Manual Supplement On page 5, add the following to the Symbols table: Consult user documentation. » On page 5, replace the CAT II, CAT III and CAT IV in the Symbols table with: Measurement Category II is applicable to test and measuring circuits connected directly to utilization points ¼...
-
Page 5: Specifications
Maximum voltage between any Terminal and Earth Ground: 600 V Power: Supplied by circuit under test. Fuse: (9040 UK model only) 0.5 A, 1000 V, 50 kA, 6.3 mm x 32 mm Determine Rotary Field Direction: Nominal Voltage: 40 to 690 V ac (U... - Page 6 9040 Users Manual Supplement Weight: 200 g Safety: IEC 61010-1: Pollution Degree 2 IEC 61010-2-030: Measurement CAT III 600 V/CAT IV 300 V IEC 60925: IP40 (non-operating) IEC 61557-7: Phase sequence Electromagnetic Compatibility: International: IEC 61326-1: Industrial Electromagnetic Environment CISPR 11: Group 1, Class A...
- Page 7 Manual Supplement 9040 Users Caution: This equipment is not intended for use in residential environments and may not provide adequate protection to radio reception in such environments Emissions that exceed the levels required by CISPR 11 can occur when the equipment is connected to a test object.
- Page 8 9040 Users Manual Supplement Change #3, A212 On page 7, in the Determine the Rotary Field Direction: Delete step 3. 11/21...
