Page 1
QUICK MOUNT VISUAL INSTRUCTION MANUAL LRB24-SA with Pressure Independent Characterized Control Valves 3 seconds until yellow light appears. Flow setting is now loaded in actuator Rotate to desired flow setting.
Page 2
WIRING DIAGRAMS Non-Spring Return Actuator with On/Off and -SR Notes: 24 VAC Transformer 24 VAC Transformer Line Blk (1) Common Meets cULus requirements without the need of an Blk (1) Common Line Volts electrical ground connection Red (2) + Hot Ω...
