Summary of Contents for Rangemaster Classic 100 Induction
- Page 1 Built from experience USER GUIDE & INSTALLATION INSTRUCTIONS Classic, Classic Deluxe and Professional+ 100 Induction U110683-03a...
- Page 2 Terms & Conditions 1. This is my Rangemaster is open to residents of UK mainland only, aged 18 years & over. 2. All entries should be submitted to the advertised e-mail address, or Rangemaster UK Facebook, Instagram or Twitter page using the advertised hashtag &...
-
Page 3: Table Of Contents
Contents Before you start... Cooking Table Personal safety Cleaning your cooker Electrical connection safety Troubleshooting Peculiar smells Ventilation 10. Installation Maintenance Dear Installer Induction care Safety Requirements and Regulations Oven care Provision of Ventilation Hob care Location of Cooker Grill/glide-out grill™ care Positioning the Cooker Cooling fan Moving the Cooker... -
Page 5: Before You Start
Before you start... Electrical connection safety Your cooker should give you many years of trouble-free cooking if installed and operated correctly. It is important The electrical installation must be installed in accordance that you read this section before you start. with all relevant British Standards/Codes of Practice, BS 7671. -
Page 6: Peculiar Smells
Peculiar smells • NEVER leave the hotplate unattended at high heat settings. Pans boiling over can cause smoking, When you first use your cooker it may give off an odour. This and greasy spills may catch on fire. Use a deep fat should stop after use. -
Page 7: Induction Care
Fig. 1.2 Fig. 1.3 to ensure longevity of performance, we recommend the use of AGA Rangemaster Induction Pots and Pans. If you decide to purchase an alternative set ArtNo.312-0001 Not cooking surface of pans for use on your induction cooker, we would strongly recommend that composite aluminium pans with steel inserts, example shown Fig. -
Page 8: Oven Care
• Take care NOT TO PLACE HOT LIDS onto the hob surface (Fig. 1.5). Lids that have been used to cover Fig. 1.5 a hot pan can “stick” or create a “vacuum” effect to the Glass Hob. Should this occur, DO NOT attempt ArtNo.312-0001 Not cooking surface to lift the lid off the glass surface, this may damage the glass. -
Page 9: Hob Care
• Make sure the shelves are pushed firmly to the back Cooker care of the oven. DO NOT close the door against the oven As steam can condense to water droplets on the cool outer shelves. trim of the oven, it may be necessary during cooking to wipe •... -
Page 10: Cooker Overview
2. Cooker Overview Fig. 2.1 The 100 induction cooker (Fig. 2.1) has the following Fig. 2.2 features: 5 induction cooking zones A control panel A separate glide-out grill A fan oven or multifunction oven (depending on model) Tall fan oven The Hob Use only pans that are suitable for induction hobs. - Page 11 The very best pans have bases that are very slightly curved Fig. 2.3 up when cold (Fig. 2.3). If you hold a ruler across the bottom you will see a small gap in the middle. When they heat up the metal expands and lies flat on the cooking surface.
- Page 12 Residual Heat Indicator, H Automatic heat-up time at Power Level 100% (min:sec) After use, a cooking zone will remain hot for a while as heat 0:48 dissipates. When a cooking zone is switched off the residual heat indicator symbol [H ], will appear in the display. This 2:24 shows that the cooking zone temperature is above 60 °C and 3:50...
- Page 13 Low Temperature Setting, L1/L2 Maximum Operating Time Power Level This function should only be used when cooking from cold. 2 hours L1 and L2 Each cooking area is equipped with 2 low temperature 6 hours settings: 6 hours 5 hours •...
-
Page 14: The Glide-Out Grill
Overheat Function Fig. 2.9 This function identifies when the temperature of the pan rises rapidly and works to maintain a safe level of pan temperature. It should not interfere with normal cooking. Cookware with bases that become distorted (Fig. 2.2) when heated may interfere with the operation of the Overheat Classic Function. -
Page 15: The Ovens
The Ovens Fig. 2.14 The clock must be set to the time of day before the ovens will work. See the following section on ‘The Clock’ for instructions on setting the time of day. Multi-function oven References to ‘left-hand’ and ‘right-hand’ ovens apply as viewed from the front of the appliance. - Page 16 Multi-function Oven Functions Fan Assisted Oven This function operates the fan, circulating air heated Rapid Response by the elements at the top and the base of the oven. The Rapid Response setting enables you to preheat The combination of fan and conventional cooking the oven faster than normal.
-
Page 17: Main Oven Light
Defrost Fig. 2.17 This function operates the fan to circulate cold air only. Make sure the temperature control is at 0°C and that no heat is applied. This enables small items such ArtNo.235-0003 - Classic DL MF knobs as desserts, cream cakes and pieces of meat, fish and poultry to be defrosted. -
Page 18: Accessories
Accessories Fig. 2.21 Shelf guard Oven Shelves – Left-hand (Main) Oven The oven shelves (Fig. 2.21) are retained when pulled forward but can be easily removed and refitted. Pull the shelf forward until the back of the shelf is stopped by the shelf stop bumps in the oven sides (Fig. -
Page 19: Button - Rotary Clock
3. 2 Button - rotary clock The clock must be set to the time of day before the oven Fig. 3.1 ArtNo.300-0005 2BC will work. minute minder setting Setting the Clock Once the cooker is connected and switched on, the display will start to flash. - Page 20 To stop the oven at a specific time of day Fig. 3.5 You have set the required temperature and function mode and you would like the oven to automatically stop. TOP TIP Make a note of the current time so you do not forget. Turn the Timer (A) knob to the Stop Time (G) setting.
- Page 21 To start and stop the oven automatically Fig. 3.9 The timer allows you to automatically start and stop by a combination of the length of the cooking time and the stop time. Giving you the flexibility to cook casseroles etc while you are out.
-
Page 22: Button Clock
3 Button clock Using the clock Fig. 4.1 You can use the clock to turn the programmable oven on and off. The clock must be set to the time of day before the oven will work. NOTE: When using the timer functions, first set the clock as ArtNo.306-0001 - 3-button clock required before setting the oven temperature. - Page 23 When the ‘stop time’ is reached an alarm will sound and Fig. 4.7 the oven will stop working. The word ‘AUTO’ will flash on the display (Fig. 4.6). Press any button to stop the alarm and return to manual cooking. If the alarm is not stopped, it will stop ArtNo.306-0001 - 3-button clock automatically after 7 minutes.
-
Page 24: Button Clock
6 Button clock Using the clock Fig. 5.1 You can use the timer (Fig. 5.1) to turn the oven(s) on and off. The clock must be set to the time of day before the oven(s) will work. ArtNo.302-0002 - 6BC annotated Table 5.1 describes the symbols shown on the digital display. - Page 25 Once the ‘cook period’ is reached, the beeper sounds and the Fig. 5.7 Fig. 5.8 [AUTO] symbol flashes. Turn the oven control knob to 0 and then press any button to stop the beep. Press [ ] to return to ...
-
Page 26: Cooking Tips
Cooking tips Using Your Induction Cooker General oven tips If you have not used an induction cooker before please be The wire shelves should always be pushed firmly to the back aware of the following: of the oven. • Make sure that the pans you have or buy are suitable Baking trays with food cooking on them should be placed for use on the induction hob. -
Page 27: Cooking Table
Cooking Table The oven control settings and cooking times given in the table below are intended to be used as a guide only. Individual tastes may require the temperature to be altered to provide a preferred Top (T) result. ArtNo.050-0007 Centre (C) Oven shelf positions Food is cooked at lower temperature in a fan oven than in a conventional oven. -
Page 28: Cleaning Your Cooker
Cleaning your cooker DocNo.040-0004 - Cleaning - 110 ceramic GENERIC Isolate the electricity supply before carrying out any Fig. 8.1 major cleaning. Then allow the cooker to cool. NEVER use paint solvents, washing soda, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt. - Page 29 Grills Fig. 8.2 The grill pan and trivet should be washed in hot soapy water. After grilling meats or any foods that soil, leave to soak for a few minutes immediately after use. Stubborn particles may be removed from the trivet using a nylon brush. Alternatively, the grill pan can be washed in a dishwasher.
- Page 30 Glass fronted door panels Fig. 8.7 The oven door front panels can be taken off so that the glass panels can be cleaned. Move the cooker forward to gain access to the sides (see the ‘Moving the Cooker’ section under ‘Installation’).
- Page 31 Cleaning table Cleaners listed (Table 8.1) are available from supermarkets or electrical retailers as stated. For enamelled surfaces use a cleaner that is approved for use on vitreous enamel. Regular cleaning is recommended. For easier cleaning, wipe up any spillages immediately. Hotplate Part Finish...
-
Page 32: Troubleshooting
Troubleshooting DocNo.050-0001 - Troubleshooting - Induction GENERIC Interference with and repairs to the hob MUST NOT The cooling fan be carried out by unqualified persons. Do not try The induction hob incorporates a cooling fan. This cooling to repair the hob as this may result in injury and fan is active when either the grill or the oven(s) are on. - Page 33 Food is cooking too slowly, too quickly, or burning Fig. 9.1 Cooking times may differ from your previous oven. Check that you are using the recommended temperatures and shelf positions – see the oven cooking guide. Then adjust the ArtNo.324-0005 Oven light bulb settings according to your own individual tastes.
- Page 34 The timed oven is not coming on when turned on manually Is the power on? Is the clock illuminated? If not, there may be something wrong with the power supply. Is the cooker supply on at the isolator switch? Has the time of day been set? The timed oven is not coming on when automatic cooking Has the oven knob been left in the OFF position by mistake?
-
Page 35: Installation
INSTALLATION Check the appliance is electrically safe when you have finished. 10. Installation Dear Installer You will need the following equipment to complete the cooker installation satisfactorily: Before you start your installation, please complete the details • Multimeter (for electrical checks). below, so that, if your customer has a problem relating to your installation, they will be able to contact you easily. -
Page 36: Positioning The Cooker
INSTALLATION Check the appliance is electrically safe when you have finished. Positioning the Cooker Fig. 10.1 Fig. 10.1 and Fig. 10.2 show the minimum recommended 75 mm 75 mm distance from the cooker to nearby surfaces. 650 mm The cooker should not be placed on a base. The hotplate surround should be level with, or above, any adjacent work surface. -
Page 37: Lowering The Two Rear Rollers
INSTALLATION Check the appliance is electrically safe when you have finished. Lowering the Two Rear Rollers Fig. 10.5 To adjust the height of the rear of the cooker, first fit a 13 mm spanner or socket wrench onto the hexagonal adjusting nut (Fig. -
Page 38: Electrical Connection
INSTALLATION Check the appliance is electrically safe when you have finished. Electrical Connection Current Operated Earth Leakage Breakers The cooker must be installed by a qualified electrician, in The combined use of your cooker and other domestic accordance with all relevant British Standards/Codes of appliances may cause nuisance tripping, so we recommend Practice (in particular BS 7671), or with the relevant national that the cooker is protected on an individual RCD (Residual... -
Page 39: Final Fitting
INSTALLATION Check the appliance is electrically safe when you have finished. Final Fitting Fig. 10.12 Fitting the Handles and Handrail (Classic & Classic Deluxe) Remove the 4 mm Allen screws from the doors (Fig. 10.12). Fit the door handles and secure using the 4 mm screws. ArtNo.215-0026 - Handle gaskets fixed The handles should be above the fixings. -
Page 40: Circuit Diagrams
11. Circuit Diagrams Classic Deluxe P095199 P038434 P095199 b b b Legend The connections shown in the circuit diagram are for single-phase. The ratings are for 230 V 50 Hz. Code Description Code Description Code Colour Blue Grill front switch Right-hand fan oven thermostat Brown Grill energy control... - Page 41 Classic & Professional + P095199 P095199 P095199 ArtNo.082-0013 - 90 ceramic (oven) circuit diagram The connections shown in the circuit diagram are for single-phase. The ratings are for 230 V 50 Hz. Code Description Code Description Code Colour Grill energy regulator Blue Cooling fan Grill front switch...
- Page 42 Earth On Terminal Block N(6) On Terminal Block N(4) INDUCTION UNIT DISPLAY L(2) L(3) w/br w/br INTERFACE On Terminal Block BOARD w/br w/br w/br Code Colour Code Description w/br White or brown Left-hand front element Left-hand back element Right-hand back element Right-hand front element Centre element...
-
Page 43: Technical Data
12. Technical Data INSTALLER: Please leave these instructions with the user. DATA BADGE LOCATION: Cooker back, serial number repeater badge below the oven door opening. COUNTRY OF DESTINATION: GB, IE. Connection Electric 230 / 400 V ~ 50 Hz 3N Dimensions Model Classic &... - Page 44 Hotplate Efficiency Data Brand Rangemaster Classic Model Identification Classic Deluxe Professional + Size Type Induction Type of Hob Induction Number of electric zones Zone 1 - Ø cm 18.5 Heating Technology Energy Consumption (ECElectric cooking) - Wh/kg Zone 2 - Ø cm 15.5...
- Page 45 Classic Deluxe Brand Rangemaster Model identification Classic Deluxe Mass Type of oven Electric Number of cavities Left-hand Efficiency Fuel type Electric Cavity type Multifunction Power - conventional Power - forced air convection Volume Litres Energy consumption (electricity) - conventional kWh / cycle 1.08...
- Page 46 Classic & Professional + Brand Rangemaster Model identification Classic & Professional + Mass Type of oven Electric Number of cavities Left-hand Efficiency Fuel type Electric Cavity type Fanned Power - conventional Power - forced air convection Volume Litres Energy consumption (electricity) - conventional...
- Page 47 • Has not been repaired by persons or organisations other than those authorised to act on behalf of AGA Rangemaster. Date of Purchase Exceptions: • Items not included under the free 1 year guarantee Installer’s Name &...
- Page 48 Registered Office: c/o Aga Rangemaster, Meadow Lane, Long Eaton, Nottingham, NG10 2GD Rangemaster continuously seeks improvements in specification, design and production of products and thus, alterations take place periodically. Whilst every effort is made to produce up-to-date literature, this brochure should not be regarded as...
