O-Remington Dining Table
Parts and Hardware List
A.
Table Top
B.
Mounting Plate
C.
Post
D.
Base
E.
Long Allen Head Bolts
F.
Medium Allen Head Bolts
G.
Short Allen Head Bolts
H.
Lock Washers
I.
Flat Washers
J.
Allen Head Wrench
K.
Optional Allen Head Screwdriver Bit
∗ Please make sure that you have all the parts and hardware indicated above before you begin assembly of this item.
∗
This item should be assembled on a soft surface to prevent scratching of the finish during assembly.
∗
This item may require periodic tightening.
∗ Take care not to overtighten bolts if using supplied Allen Head Screwdriver Bit.
Hardware Illustrations
E. Long Allen Head Bolt
G. Short Allen Head Bolt
I. Flat Washer
Page 1 of 2
1 pc
1 pc
1 pc
1 pc
4 pcs
4 pcs
4 pcs
12 pcs
12 pcs
1 pc
1 pc
F. Medium Allen Head Bolt
H. Lock Washer
R1-04-01-05
