USING PSCOPE SOFTWARE
PScope, downloadable from Linear Technology's website http://www.linear.com/, processes data from the DC890B
FastDAACS board and displays FFT and signal analysis information on the computer screen.
The on-board EEPROM U1 should enable automatic board detection and auto-configuration of the software, but if the
user wishes to change the settings, they can easily do so.
From the Configure menu in the toolbar, uncheck "Autodetect Device". The default settings for DC1513 are shown in
Figure 2.
Figure 2. Entering the correct device information for your ADC. Select the correct parameters for the DC1513. Under normal conditions,
PScope should automatically recognize the board and adjust the software settings accordingly.
