- Page 1 Adventure Neo Allroad Quick Start Guide...
- Page 2 Welcome to the Cannondale family. WARNING First up, thank you for buying a new Cannondale electric bike – we’re excited to have you on board and to get you out riding as soon as possible. This is a Quick Start Guide, not an Owner’s manual.
-
Page 3: Table Of Contents
Battery Charging the battery Remove/Insert the battery Pedal Assistance Drive unit remote Turning bike on/off Default display information Adjusting pedal assist Controlling the Lights Controlling the Throttle Using Walk Assistance... -
Page 5: Battery
Battery In this guide are basic battery charging and removal/installation instructions. See the Battery User Manual that came with your bike or located in the Cannondale Help Center for complete battery specifications, operating instructions, and troubleshooting. -
Page 6: Charging The Battery
Charging the battery For your convenience, the battery on the Cannondale Adventure Neo Allroad bikes can be charged on or off the bike. For both methods of charging, start by connecting the battery charger’s power plug directly into a wall outlet. - Page 7 On-bike charging On the left side of the bike (side opposite from the gears), locate the rubber dust-plug and pull it open to obtain access to the charging port Insert the charging plug into the port Charger LED will briefly blink upon connection a.
- Page 8 Off-bike charging If battery is still installed on the bike, see the following section: “Removing the battery” for instructions on how to remove the battery Place battery on a dry surface away from direct heat Locate the round rubber dust-seal on the underside of the battery Pull open the rubber dust-seal and insert the charging plug into the port...
- Page 9 Removing the battery The Cannondale Adventure Neo Allroad comes with an easy to remove semi-integrated battery, which offers the freedom to charge at home, in the office, or wherever you have power. To remove the battery Power off battery pack on the handlebar display by pressing and holding the power button for three seconds.
- Page 10 Installing the battery Insert key into lock core. Turn key clockwise until it stops. Remove the key and store it safely. Place battery into the cradle, bottom first. With your hand on the top part of the battery pack, push downward until you hear a click. Pull upward on the battery to ensure it is locked into the cradle.
- Page 11 Cannondale Adventure Neo Allroad. Below are basic use and operation instructions. See the complete JYT S350 E-bike Intelligent Display Manual that came with your bike or on the Cannondale.com Help Center for all specifications, operations and troubleshooting details.
-
Page 12: Drive Unit Remote
Drive unit remote The e-bike drive unit remote is positioned on the handlebars next to the left brake lever where it can easily be operated by the rider’s left thumb. All e-bike functions are operated using the 3 buttons on the remote. Power button Up button Down button... -
Page 13: Turning Bike On/Off
Turning the bike ON/OFF To turn the device on/off, press and hold the power button for 2 seconds until display comes on/goes off. If bike is not used for 5 minutes, the display will automatically turn off in order to conserve battery. -
Page 14: Default Display Information
Default display information Battery level – Indicated by 5 LED bars on the top of the display. Single flashing LED means battery is low and needs to be recharged. Electric Assist Level – Indicated by 5 LED bars on the lower portion of the display, with Low assist indicated by one LED illuminated and High assist indicated by all 5 LED’s illuminated... -
Page 15: Adjusting Pedal Assist
Adjusting pedal assist The Adventure Neo Allroad has 5 pedal assist levels. Assist is provided up to 20 mph (32 kmh). Use the Up (+) button to increase the pedal assist level Use the Down (-) button to decrease the pedal assist level *Note. -
Page 16: Controlling The Lights
Controlling the lights Your Cannondale Adventure Neo Allroad comes with a headlight and taillight to help make you more visible when riding. The headlight, taillight and display backlight are all controlled together. Lights are on by default whenever the system is powered on. -
Page 17: Controlling The Throttle
Controlling the throttle The Adventure Neo Allroad is equipped with a thumb throttle that allows the bike to be powered by electric power only up to 20 mph, without the need to pedal the bike. The throttle is located on the handlebars next to the riders left thumb. -
Page 18: Using Walk Assistance
Using walk assistance Walk Assistance uses the e-bike drive system to help propel the bike forward at a speed of 2 mph (3 kmh) making it easier to move the bike when it is not being ridden. This is especially helpful when walking the bike up an incline or hill. - Page 19 Register your e-bike Register your Cannondale e-bike to activate your Lifetime Warranty Go to www.cannondale.com/bike-registration/register...
- Page 20 Get the most out of your Cannondale electric bike by downloading the Cannondale App. The Cannondale App automatically logs ride activity, provides all your manuals at your fingertips, has every detail about your bike and can even remind you when it’s time for a tune up.
