Cannondale Adventure Neo Owner's Manual Supplement
  1. Manuals
  2. Brands
  3. Cannondale Manuals
  4. Bicycle
  5. Adventure Neo
  6. Owner's manual supplement

Cannondale Adventure Neo Owner's Manual Supplement

Hide thumbs

Advertisement

Quick Links

Adventure Neo
Owner's Manual Supplement
READ THIS SUPPLEMENT AND YOUR
Cannondale Bicycle Owner's Manual. Both
contain important safety information. Keep both
for future reference.
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the Adventure Neo and is the answer not in the manual?

Questions and answers

Related Manuals for Cannondale Adventure Neo

Summary of Contents for Cannondale Adventure Neo

  • Page 1 English Adventure Neo Owner’s Manual Supplement READ THIS SUPPLEMENT AND YOUR Cannondale Bicycle Owner’s Manual. Both contain important safety information. Keep both for future reference.
  • Page 2 Safety Messages In this supplement, particularly important information is presented in the following ways: Indicates a hazardous situation which, if not avoided, may result in death or serious injury. NOTICE Indicates special precautions that must be taken to avoid damage. Symbols: Symbol Name...

  • Page 3: Table Of Contents

    Replacement Parts ......40 your bike; obtain and read all of them. E-Bike Maintenance ....41-43 Please contact your Authorized Cannondale Dealer immediately if you need a manual or Notes ..........44 supplement, or have a question about your bike.

  • Page 4: Identification

    Identification Parts of Your E-Bike Adventure Neo OMS IDENTIFICATION Parts of Your E-Bike Actual bike appearance will differ. Identification 4. Charge port 7. Rear Light 10. Wheel Sensor . Drive display 5. Key 8. Rear rack 2. Drive unit 6. Headlamp 9.

  • Page 5: Safety Information

    Authorized Cannondale handlebar control unit. At anytime, if you Dealer. stop pedaling, the drive-assist will dis-...
  • Page 6 OBSERVE MINIMUM OPERATOR AGE - Follow any national, state, or local laws for any minimum age restrictions for the operator of the E-Bike. Ask your local Authorized Cannondale Dealer for more information about operating an electrically assisted pedal bicycle in your area.
  • Page 7 Safety Information Operation Operation Always wear an approved bicycle helmet and all other protective gear (e.g., gloves, pads, and cycling shoes). Importance of practice & rider training - before you ride this bike, practice riding in a safe area free from hazards. Take time to learn the bike’s controls and performance. Practice the controls and to gain the experience necessary to avoid the many hazards you will encounter while riding.
  • Page 8 Safety Information Compliance/Regulation Adventure Neo OMS continued from previous page... Wired system control: If the drive system control device is detached from the mount or if the cables are disconnected or damaged, the drive system will automatically shut off. If this happens, you will have to stop the bike, turn the system off, re-attach the computer to the base, and then turn the system back on to resume operation.
  • Page 9 Safety Information Compliance/Regulation Batteries & Chargers REPLACEMENT - Only use the battery pack and charger indicated in the “Specifications” section of this supplement. Do not use other batteries or chargers. Do not use the charger to charge other batteries. PREVENT DAMAGE - Do not drop the battery or charger. Do not open, disassemble, or modify the battery or charger.
  • Page 10 E-Bikes are certainly not speed of the bike are dangerous to the designed to protect you in a crash. Do not rider. Use only specified Cannondale and/ assume the bike or its drive capability will or manufacturer drive-assist service and protect you or keep you from being replacement parts.
  • Page 11 Safety Information Rear Rack Rear Rack Headtube Mounted Accessories This bicycle has integrated mounting points for for attaching compatible accessories. Do not overload a rear rack. Make sure the cargo is secured properly. Observe the rack maximum weight limit found in the “Specifications” section of this Do not mount an accessory (e.g., water supplement.

  • Page 12: Key

    Using the Key Adventure Neo OMS Please Note: After multiple rides and bike-washes, the battery lock can become dry and difficult to use. To maintain, whenever you lubricate your bike chain, place a few drops of chain oil on the key, insert the key and operate the lock, then remove and wipe the key clean.

  • Page 13: Technical Information

    Technical Information Specifications TECHNICAL INFORMATION Specifications Drive System Item Specification Model Adventure EQ 1 Adventure EQ 2 Drive System BOSCH e-Bike Systems (2021) Drive Unit/BOSCH part no. Performance Line Active Line Plus Cruise (20 mph) / (20 mph)/ 0275.007.071 0275.007.049 Drive Display /BOSCH part no.
  • Page 14 Technical Information Specifications Adventure Neo OMS Frame Frame Head Tube UPR: 1-1/8 in LWR: 1-1/2 in Headset Integrated 1-1/8 in - 1-1/2 in Bottom Bracket: Type/Width Bosch Drive Unit Front Derailleur Seat Post: Dia./Binder 31.6 mm / 36.4 mm 75 mm Min.
  • Page 15 Technical Information Geometry Geometry Dimensions = centimeter * = same spec. 75 mm Item Frame Size Wheel Size 27.5“ 27.5“ Seat Tube Length 37.0 46.0 Top Tube Horizontal 59.4 63.5 Top Tube Actual Head Tube Angle 70.0° 70.0° Seat Tube Angle Effective 72.0°...
  • Page 16 Technical Information Drive System Display - BOSCH Purion Adventure Neo OMS Drive System Display - BOSCH Purion English – 4​ Product description and specifications ( ( a a ) ) ( ( b b ) ) ( ( c c ) )
  • Page 17 Technical Information Drive System Display - BOSCH Purion English – ​ 5 Technical data – The speed sensor is connected properly (see drive unit operating instructions). On-board computer Purion Switching the eBike system on/off Product code BUI210 BUI215 The following options are available for switching on the eBike system: Batteries 2 ×...
  • Page 18 Technical Information Drive System Display - BOSCH Purion Adventure Neo OMS English – 6​ bike's battery. It is, however, recommended that you Close the battery compartment again and fasten the replace the internal batteries as soon as possible in on-board computer to your eBike's handlebars using order to avoid damage.
  • Page 19 Technical Information Drive System Display - BOSCH Purion English – ​ 7 The following assistance levels are available as a max- Switching the bike lights on and off has no effect on imum: the backlight of the display. – OFF: Motor assistance is switched off. The eBike Speed and distance indicators can just be moved by pedaling, as with a normal bi- cycle.
  • Page 20 Technical Information Drive System Display - BOSCH Purion Adventure Neo OMS English – 8​ The USB port is reserved for connecting diagnostic systems. The USB port does not have any other func- tion. The USB port must always be completely sealed with the protective cap (8).
  • Page 21 Technical Information Drive System Display - BOSCH Purion English – ​ 9 Troubleshooting The components of the eBike system are continu- continue riding at any time without assistance from ously monitored automatically. If a fault is detected, the drive, but you should have your eBike checked the corresponding fault code will appear on the on- before completing any more journeys.
  • Page 22 Technical Information Drive System Display - BOSCH Purion Adventure Neo OMS English – ​ 1 1 Code Cause Corrective measures Internal battery fault Restart the system. If the problem persists, contact your Bosch eBike dealer. Internal battery fault Restart the system. If the problem persists, contact your Bosch eBike dealer.
  • Page 23 Technical Information Drive System Battery - BOSCH Drive System Battery - BOSCH English – 8 Product features PowerTube ( ( 1 1 2 2 ) ) ( ( 1 1 3 3 ) ) ( ( 6 6 ) ) ( ( 1 1 6 6 ) ) ( ( 5 5 ) ) ( ( 1 1 4 4 ) )
  • Page 24 Technical Information Drive System Battery - BOSCH Adventure Neo OMS English – 9 Intended Use The Bosch eBike batteries are intended exclusively to provide the power supply for your eBike drive unit and must not be used for any other purpose.
  • Page 25 Technical Information Drive System Battery - BOSCH English – 10 Li-ion battery PowerTube 400 PowerTube 500 PowerTube 625 Product code BBP287 horizontal BBP285 horizontal BBP295 horizontal BBP288 vertical BBP286 vertical BBP296 vertical Rated voltage Nominal capacity 13.4 16.7 Energy Operating temperature °F +23 to +104 +23 to +104...
  • Page 26 Technical Information Drive System Battery - BOSCH Adventure Neo OMS English – 11 Charging with Two Battery Packs Inserted CAUTION If two battery packs are mounted on one eBike, both Do not connect the battery pack to the charger battery packs can be charged using the unsealed con- until it has reached the allowable charging tem- nection.
  • Page 27 Technical Information Drive System Battery - BOSCH English – 13 Removing the PowerTube battery ❶ To insert the PowerTube battery (15), place it so that its contacts are in the lower holder of the frame. ❷ Push the battery upwards until it is held by the safety restraint (14).
  • Page 28 Technical Information Drive System Battery - BOSCH Adventure Neo OMS English – 14 Operation Start-up If no power is drawn from the eBike drive for about 10 minutes (e.g. because the eBike is not moving) Use only original Bosch batteries that the manu- and no button is pressed on the on-board computer facturer has approved for your eBike.
  • Page 29 Technical Information Drive System Battery - BOSCH English – 17 Troubleshooting Cause Corrective measures Two LEDs flash on the battery. Contact an authorized bike dealership. Battery defective Three LEDs flash on the battery. Disconnect the battery from the charger until the Battery too warm or too cold charging temperature range has been reached.
  • Page 30 If damage is found, do not ride the bike. that the battery socket engages with the Have any damaged part replaced with lower frame connector (4). a new one. Contact your Cannondale Dealer. 3. Turn the key clockwise to re-engage the upper locking mechanism (6).
  • Page 31 Technical Information Adventure Neo Powertube Battery Remove battery cover before turning the key. Cover is independent from battery Top view Bottom view Identification 1. Battery Cover 6. Battery Latch 2. Battery 7. Battery Release Tab 3. Battery Connector 8. Charge Port 4.
  • Page 32 Technical Information Adventure Neo Powertube Battery Adventure Neo OMS Battery Charging Port The Powertube battery charging port is located on the left side of the bicycle at the headtube. The charging port enables the battery to be charged while installed in the bicycle.
  • Page 33 Technical Information Drive System Charger 2A - BOSCH Drive System Charger 2A - BOSCH English – 7 Product Description and Specifications Product Features (1) Charger (2) Device socket (3) Device connector (4) Charger safety instructions (5) Charging connector Bosch eBike Systems 0 275 U07 XCX | (08.04.2020) WARNING: This page contains selected information only.
  • Page 34 Technical Information Drive System Charger 2A - BOSCH Adventure Neo OMS English – 11 switched off. The charging process is terminated. The Note: If you have charged the battery on the bike, state of charge can be displayed for three seconds by carefully close the charging socket (6) with the cover pressing the on/off button (10) on the eBike battery.
  • Page 35 Do not attempt to work on the cable routing yourself. Due to the complex nature of the parts and the level of disassembly required to gain access, have any repairs or replacements of the battery, cables or hose parts identified here, performed by an authorized Cannondale e-bike service center.

  • Page 36: Replacement Parts

    5 N·m 2-3 N·m Part Number Description Part Number Description KP284/ Derailleur Hanger QR ST SS K76041 Adventure Neo HT Bottle Cage Spacer Kit K32111 Adventure Neo Grommets K34221 Neo Urban Motor Cover K34140 Key Hole Cover w/ Leash K76051...

  • Page 37: E-Bike Maintenance

    Do not ride your bike if it does not operate normally or has broken, damaged, or missing parts. Have any damage inspected and repaired by your Cannondale Dealer before riding again. You can be severely injured, paralyzed or killed in an accident if you ignore this warning.
  • Page 38 This will ensure the quality and Consult with your Authorized safety of the drive-assist system. Cannondale Dealer to create a complete maintenance program for your riding Never attempt to open or remove drive style, components, and conditions of system parts from the frame, or to work use.
  • Page 39 E-Bike Maintenance Cleaning Cleaning When cleaning your bike, use a damp sponge or a soft brush with only a mild soap and water solution. Rinse the sponge often. Do not spray water directly on controls or on drive system components. NOTICE Do not use a pressure washer or dry with compressed air.

  • Page 40: Notes

    Notes Record Adventure Neo OMS NOTES Use NOTES pages to write /record important information about your bike : (e.g. maintenance history, dealer contact information, settings, etc.) 138670 Rev 1 (02/21)
