Input Gearbox Drive - MacDon C Series Operator's Manual

SETUP PROCEDURE AND ADJUSTMENT OF THE CORN HEAD
6.4.

Input Gearbox Drive

The input gearboxes are connected by a double joint coupling drive or shaft (1) depending on
the combine. The gearbox assemblies (2) are selected to provide a nominal snapping unit input
speed of 550 rpm for each combine. Gearboxes can be exchanged as necessary.
See appropriate combine conversion document for complete instructions
1
1
2
Double joint coupling
(all except Claas)
The input gearbox drive does not require any additional adjustment
Shaft-drive
32
(Claas)
1
2
