Double Sided Art Easel Base Model
PDR05
Assembly Guide
Check out our other products online at www.copernicused.com
For assistance, please contact us by telephone at 1-800-267-8494 or email at info@copernicused.com.
Have your packing slip ready for reference.
Please Recycle
PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Copernicus PDR05
Summary of Contents for Copernicus PDR05
- Page 1 Check out our other products online at www.copernicused.com For assistance, please contact us by telephone at 1-800-267-8494 or email at info@copernicused.com. Have your packing slip ready for reference. Please Recycle PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
- Page 2 Please visit www.copernicused.com/warranty and complete the form within 10 business days from Frame Warranty product assembly. By registering your product, you will be entered into a draw to win Copernicus product. Make a Warranty Claim We offer a Lifetime Warranty on almost everything we make. Please call 1-800-267-8494 or email info@copernicused.com to start your warranty claim.
- Page 3 This product is intended for indoor comercial use only. To reduce the risk of fire or electric Indoor Use shock, do not expose this product to rain or moisture. The internal components are not Only sealed from the environment. PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
-
Page 4: Additional Tools Required
Packed inside one pot Paint Tray (each includes seven pots, seven spill-proof caps and seven lids) Holder for High Position Packed inside one pot Art Clip PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc. - Page 5 You will need: (Not to Scale) Actual Size: Side Frame Bottom Stretcher Attach Stretchers to Side Frames Assemble fully but do not tighten. PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
-
Page 6: Install Casters
Press Casters firmly into the Frame. Casters will click into place. If necessary, place a wrench between the wheels & tap in with a rubber mallet. PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc. - Page 7 Board in High Position Use top holes for High position Attach 1 top corner and 2 bottom corners (board shown in lowest position). Repeat on other side. PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
- Page 8 You will need: (Not to Scale) Art Clip Two Clips on the top, and a clip on either side will help to hold the students artwork in place. PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
- Page 9 Holder for Holder for High Low Position Position Install Paint Tray Holders For board in Low Position Install Paint Tray Holder For board in High Position PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
- Page 10 You will need: (Not to Scale) Paint Tray Slide Paint Tray on Holders How to remove Pots from Paint Tray PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
- Page 11 You will need: (Not to Scale) Adjustable wrench 10mm Wrench Rubber Mallet Final Assembly Checks Check entire assembly for loose parts; bolts, screws and nuts PDR05 - Version A - Released November 21, 2022 - Copernicus Educational Products Inc.
