Quick Installation Guide
Rechargeable Li-ion Battery System
Lynx C Series
(LX C 101-10
|
LX C120-10
|
LX C138-10
|
LX C156-10)
V1.0-2022-10-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lynx C Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Goodwe Lynx C Series

  • Page 1 Quick Installation Guide Rechargeable Li-ion Battery System Lynx C Series (LX C 101-10 LX C120-10 LX C138-10 LX C156-10) V1.0-2022-10-12...
  • Page 2: Emergency Measures

    • The Lynx C Series Rechargeable Li-ion Battery System for Commercials and Industries (hereinafter referred to as the Lynx C BMS in short) is a high voltage system. Do not touch or operate it.
  • Page 3: Label Description

    Label Description Symbol Description Symbol Description Potential risks exist. Wear proper Keep the equipment away from PPE before any operations. voltage exists during the Keep the equipment away from equipment's running. children. before any operations. Operate the equipment properly to No extinguishing with water.
  • Page 4: Check Before Power On

    The Lynx C BMS sold in the European market meets the following directives and requirements: • Electromagnetic compatibility Directive 2014/30/EU (EMC) • • Restrictions of Hazardous Substances Directive 2011/65/EU and (EU) 2015/863 (RoHS) • Waste Electrical and Electronic Equipment 2012/19/EU • https://en.goodwe. com.
  • Page 5: Product Introduction

    Product Introduction Battery Cabinet Front View Right View Left View Length Width Height Handle Slot BMS Routing Hole Model Length (mm) Width (mm) Height (mm) LX C101-10 1155 1650 LX C120-10 LX C138-10 1155 2065 LX C156-10 Power Control Unit (PCU)
  • Page 6 Battery Terminal DC Circuit Breaker (Positive) Battery Terminal Main Circuit Breaker Indicator (Negative) Power Input/Output Power Input/Output Port (Negative) Port (Positive) External COM Port Internal COM Port Battery Module Connector for Battery Battery Negative Battery Positive Polarity Communication Polarity Battery Hoisting Hole Battery Fixing Hole 525mm 202mm...
  • Page 7: Installation

    Installation Deliverables Battery Module Battery Cabinet and Accessories...
  • Page 8 Space Requirements 300mm 600mm 600mm 600mm Angle Requirements...
  • Page 9 BMS Installation 30-100mm...
  • Page 10 4.5-6N·m...
  • Page 11: Electrical Connection

    Electrical Connection Cable Type Requirement PE Cable Single-core copper cable Cross-sectional area of conductor S : 8mm • Outer diameter of the cable: Power cable to The power cable shall be 11mm~13mm connect with normal 1000V PV cables. • Cross-sectional area of conductor S: the inverter 35mm Others...
  • Page 12 Connecting Battery Communication Cable...
  • Page 13 Connecting Power Connecting Bar 10-12N·m...
  • Page 14 Connecting Inverter Power Cable 20± 1mm Click Click (Optional) Connecting Single Phase AC Power Cable...
  • Page 15 Power ON and OFF Power ON Power OFF Self-powered: Self-powered: External single External single...
  • Page 16 Commissioning Commissioning via PV Master APP Commissioning via SEMS Portal For more information, please scan the following QR for User Manual. Lynx C Series User Manual...
  • Page 17 GoodWe Technologies Co., Ltd. www.goodwe.com Local Contacts service@goodwe.com...
