Mocka Eclipse Buffet Assembly Instruction Manual page 9

Eclipse
Buffet
15
Door x 4
F
F
G
Tighten the
screws 90%..
N
N
M
Attach 2x hinges (G) to panel [14] using 4x screws (F), and attach 1x
handle (M) to panel [14] and secure with 2x screw (N).
Tighten with a screwdriver.
mocka.co.nz I mocka.com.au I PO BOX 18, Pinkenba QLD 4008
F
F
G
F
F
G
14
16
F
6
O
3
F
14
Attach hinges on panels [14] to panels [3], [4] and [5] and secure with 3
2x screws (F). Tighten with a screwdriver. Attach 4x buffer plates (O)
to panels [6] as shown. Ensure the doors open and close easily.
F
4
F
6
14
O
F
5
14
14 1 4
NOTE: If the doors are
uneven or there is a gap
in the middle, loosen or
tighten the screw on the
door hinge until they are
sitting flush.
