5.4 Gateway link to the heating product
• Connect the two-core cable supplied
in the package to the BUS port of the
gateway, using 1 orange connector
also supplied.
• Connect the other end of the cable
to the BUS port of the heating pro-
duct, using another orange connec-
tor.
38
T B FLOOR
BUS SE TNK SOL TA1 N L
TA2
1
N L
FLAME
220V
BUS BUS
TA1
B T B T
