- Install the Chaffoteaux Multifunctional Kit
- Install the Chaffoteaux Net gateway and link to the heating system through the BUS
connection
fi g.7
THERMOSTAT
TA1
TA2
5.2 Installation Chaffoteaux Expert Control
The following procedure has to be made in order to install the thermoregulation acces-
sory supplied in the Chaffoteaux Net package and to replace an old thermostat that may
be already in the dwelling.
Positioning
The device detects the room temperature, therefore several factors should be taken
into account when choosing an installation position. Keep it away from sources of heat
(radiators, sunlight, fi replaces, etc.) and from draughts, doorways and windows which
could affect the temperature measurement. We recommend to install it approximately
1.50 metres above the fl oor level.
GATEWAY EXPERT
CONTROL
BUS
fi g.8
MULTIFUNCTIONAL
KIT
