Parts List - Arrow GS83-C Series Owner's Manual & Assembly Instructions

QR10
Assembly
Key No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
10

Parts List

Part Part
Number Description
10202 Side Floor Frame
9866 Outer Front Floor Frame
10201 Center Front Floor Frame
9868 Rear Floor Frame
10199 Floor Brace
9870 Right Front Corner Panel
9871 Left Front Corner Panel
9872 Right Rear Corner Panel
9873 Left Rear Corner Panel
9874 Wall Panel
9875 Front Wall Panel
9876 Wall Panel
9877 Wall Panel
9878 Right Roof Panel
9879 Left Roof Panel
9880 Roof Panel
9881 Roof Panel
9927 Rear Wall Channel
9883 Rear Wall Angle
9884 Shelf
9885 Roof Beam
10184 Main Door Header
9947 Outer Door Header
9945 Main Header
9889 Outer Header
9890 Right Gable
9891 Left Gable
9892 Right Door Jamb
9893 Left Door Jamb
9940 Right Door
9941 Left Door
10183 Door Latch Brace
9897 Tool Bar
9898 Right Roof Trim
9899 Left Roof Trim
10200 Floor Channel
9905 Door Brace
10176 Astragal
67734 Foam Board
9944 Vertical Door Brace
Quantity Check
in Carton List
2
2
1
2
2
1
1
1
1
2
2
2
1
1
1
2
1
2
2
4
2
1
1
1
1
1
1
1
1
1
1
1
1
2
2
4
4
1
2
2
