Arrow GS83C Owner's Manual & Assembly Instructions

Hide thumbs Also See for GS83C:

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
ABR01a
Model No.
722830319
Storage Area: 23 Sq. Ft. 122 Cu. Ft.
2,1 m
2
BUILDING DIMENSIONS * Size rounded o to the nearest foot
*Approx.
Size
8' x 3'
96 7/8" x 38"
2,4 m x 0,9 m
246,1 cm x 96,4 cm
GS83
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
3,5 m
3
Exterior Dimensions
Base
(Roof Edge to Roof Edge)
Size
Width
99 3/8"
252,4 cm
GS83EU
C
Depth
Height
39 1/4"
65 5/8"
99,7 cm
166,7 cm
GS83LM
C
GS83SOS
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Width
Depth
Height
94 1/8"
35 3/16" 64 7/16"
239,1 cm
89,4 cm
163,7 cm
C
Door
Opening
Width
Height
50 1/4" 59 3/4"
127,6 cm 151,8 cm

Advertisement

loading

Related Manuals for Arrow GS83C

Summary of Contents for Arrow GS83C

  • Page 1 Owner's Manual & Assembly Instructions ABR01a Model No. GS83 GS83EU GS83LM GS83SOS Missing Parts, Questions on Assembly? Call: 1-800-851-1085 or assist@arrowsheds.com Do not return to dealer, they are not equipped to handle your requests. 722830319 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES Storage Area: 23 Sq.
  • Page 2 GB: Assembly manual in additional languages available online. Scan QR code below to access. FR: Manuel de montage disponible en ligne dans d’autres langues. Pour y accéder, scannez le code QR ci-dessous. SP: Manual de montaje en idiomas adicionales disponible online. Escanee el código QR a continuación para acceder.
  • Page 3 We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available at your local dealer, Arrow's website arrowsheds.com or call Arrow's Customer Service department 1-800-851-1085) or you...
  • Page 4 PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 5 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
  • Page 6 In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation. Contact Arrow as outlined on the Ordering Accessories page to place an order.
  • Page 7 Model No. AT101 Model No. AK100 Heavy-duty galvanized steel bars that New concrete anchor system permits t all 10' (3,0 m) wide Arrow buildings. anchoring any size Arrow building They install quickly and easily to directly to a concrete slab. Each kit...
  • Page 8 We recommend that you purchase accessory items from your local storage building dealer whenever possible; however, because the full line of accessories is not always available from all dealers, Arrow is o ering them to you on a direct basis.
  • Page 9 Anchoring BE09 Anchoring Down The Building It is important that the entire oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) dia.

  • Page 10: Table Of Contents

    Parts List ABR10 Assembly Part Part Quantity Check Key No. Number Description in Carton List 10202 Side Floor Frame 9866 Outer Front Floor Frame 10201 Center Front Floor Frame 9868 Rear Floor Frame 10199 Floor Brace 9870 Right Front Corner Panel 9871 Left Front Corner Panel 9872...
  • Page 11 Assembly by Key No. ABR11...
  • Page 12 Hardware ABR12 66692 65004 65923 65941 #10ABx1" (25 mm) #8Ax5/16" (8 mm) 65103 #8-32x3/8" (10 mm) #6-32 Hex Nut (24) Screw (2) Screw (254) #8-32 Hex Nut (98) Bolt (98) (Packed with Screws) 65958 66714 66646 #6-32x7/16" (11 mm) #8-32x7/8" (22 mm) Washer (257) 66148 Flat Hd Bolt (24)
  • Page 13 Step 1 Parts Needed For 9866 Outer Front Floor Frame (2) 10201 Center Front Floor Frame (1) Floor Frame Assemblies 9868 Rear Floor Frame (2) BE13 The front oor frame is made up of three pieces. The rear oor frame is made up of two pieces.

  • Page 14: Side Floor Frame

    Step 2 Parts Needed For Front Floor Assembly (1) 10202 Side Floor Frame (2) Floor Frame Rear Floor Assembly (1) BE14 Place the oor frame pieces that you assembled on the ground. As- semble the four corners of the oor frame using two screws at each corner as shown.
  • Page 15 Step 3 Parts Needed For 10200 Channel (4) Floor Frame Kit BE15 Snap channels 10200 together as shown. Join the channels by inserting four nuts and bolts. Make two complete assemblies. FRONT...
  • Page 16 Parts Needed For Step 4 Floor Frame Assembly (1) Attaching Floor Floor Frame Kit (1) 10199 Floor Brace (2) BE16 Frame Kit Do not attach decking material at this time! STEP NOTE: FLOOR FR AME MUST BE LE VEL AND SQUARE BEFORE PROCEEDING! factory slot...

  • Page 17: Rear Floor Frame

    Step 5 Finishing Material BE17 Select one of the suggested nishing materials. Be sure Floor Frame Kit lies at on the ground. To prepare the earth bed, remove sod and other organic debris, level the high spots with a at shovel, and tamp the bed down.
  • Page 18 Parts Needed For 10184 Main Door Header (1) Step 7 Header/Door Header 9947 Outer Door Header (1) 9945 Main Header (1) Assembly QR18 9889 Outer Header (1) The header assembly is made up 9889 of two pieces. The door header as- sembly is made up of two pieces.
  • Page 19 Parts Needed For Step 8 Roof Beam/Rear 9885 Roof Beam (2) 9883 Rear Wall Angle (2) Wall Angle Assembly BE19 The main frame pieces reinforce the walls and roof. These pieces will later be installed in the center of the roof and at the top edge of the rear wall.
  • Page 20 Step 9: Right Door Assembly AAV20 You will need for this page: 11046 9905 11045 11047 67236 Horizontal Door Handle Diagonal Door Adhesive Pad Door Panel (QTY: 1) Door Brace Brace Brace (QTY: 12) Start assembly by sliding the Door Handle Place the ends of Diagonal Door Braces Brace into the middle of the Door and securing it with small holes under Horizontal Door...
  • Page 21 Step 9: AAV21 Continued You will need for this page: 10176 66609 66043 66054 Locking (QTY: 2) (QTY: 6) (QTY: 6) Astragal Latch Hinge Handle Attach Hinges to Door using six (6) Flat Head Bolts. Hint: Attach fasteners in order as shown in diagram.
  • Page 22 Step 10: Left Door Assembly AAV22a You will need for this page: 80127 9905 11045 11047 67236 Horizontal Door Handle Diagonal Door Adhesive Pad Door Panel (QTY: 1) Door Brace Brace Brace (QTY: 12) Start assembly by sliding the Door Handle Place the ends of Diagonal Door Braces Brace into the middle of the Door and securing it with small holes under Horizontal Door...
  • Page 23 Step 10: AAV23 Continued You will need for this page: 66609 66684 Top Latch (QTY: 6) (QTY: 6) Hinge Spring 66684 Attach Hinges to Door using six (6) Flat Head Bolts. Hint: Attach fasteners in order as shown in diagram. Attach both Top and Bottom Latch Springs to left side of Door using six (6) Screws.

  • Page 24: Right Front Corner Panel

    9870 Right Front Corner Panel (1) Step 11 9871 Left Front Corner Panel (1) Parts Needed For 9872 Right Rear Corner Panel (1) Corners/Gables 9873 Left Rear Corner Panel (1) 9874 Wall Panel (2) BE22 9890 Right Gable (1) 9891 Left Gable (1) NOTE The remainder of the building assembly requires many hours.
  • Page 25 Step 12 Parts Needed For Rear Wall Angle Assembly (1) Frames Header/Door Header Assembly (1) BE23 The main frame pieces give rigidity to the front and rear walls. Fasten the rear wall angle as- sembly across the top of the rear wall using eight screws.

  • Page 26: Wall Panel

    Step 13 Parts Needed For 9875 Front Wall Panel (2) Wall Panels 9876 Wall Panel (2) BE24 9877 Wall Panel (1) Each wall panel has a crimped rib on one side. The crimped rib should go under the rib of the adjacent panel that follows it.
  • Page 27 Step 14 Parts Needed For 9892 Right Door Jamb (1) Door Jambs 9893 Left Door Jamb (1) BE25 The door jambs reinforce the door opening and provide an attractive trim. Follow these steps for both door jambs. Fasten a right door jamb to the front wall panel with three bolts and nuts as shown.
  • Page 28 Step 15 Parts Needed For Roof Beam Assembly (1) Roof Beam BE26 Bend tab at each end of roof beam assembly upward. Position beam across width of building, down on the ledge of gables at center hole location, but do not fasten at this time. STEP Roof Beam Assembly...

  • Page 29: Right Roof Panel

    Step 16 Parts Needed For 9878 Right Roof Panel (1) Right/Left Roof Panels 9879 Left Roof Panel (1) BE27 Installing the roof panels is best done Note: Tab of roof beam is fastened with a step ladder. Begin installing between roof panel and gable using roof panels at the right side of the the center hole.

  • Page 30: Roof Panel

    Step 17 Parts Needed For 9880 Roof Panel (2) Roof Panels 9881 Roof Panel (1) BE28 Install a wide roof panel 9880, narrow roof panel 9881, and a wide roof panel 9880 in the positions shown. Fasten middle of rib overlap with a bolt and nut.
  • Page 31 Step 18 Parts Needed For 9898 Right Roof Trim (2) Roof Trim 9899 Left Roof Trim (2) BE29 Overlap the right & left roof trim Fasten the roof trim caps to the pieces as shown in the figure and roof trim using a screw. fasten them together with one screw.

  • Page 32: Rear Wall Channel

    Step 19 Parts Needed For 9927 Rear Wall Channel (2) Shelving/Channel/Tool Bar 9884 Shelf (4) 9897 Tool Bar (1) BE30 Overlap the rear wall channel pieces as shown in the gure to the Tool Hooks slide along track to Screw Driver Holder(1) correct overall dimension.

  • Page 33: Right Door

    Step 20 Parts Needed For Right Door Assembly (1) Installing Door Left Door Assembly (1) AAV33 Position doors in corners of door opening as shown and fasten hinges to jambs with 7/16" (11 mm) at hd bolts and #6 hex nuts. Hint: Attach fasteners in order shown Set Screw Set Screw...
  • Page 34 NOTES GZ46...
  • Page 35 NOTES GZ46...
  • Page 36 GS83 GS83EU GS83LM GS83SOS ABR34a ANCHORING Anchor your building at this time. SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
