3-1/4 x 10" Rear Discharge
4. At rear of range hood, remove all screws on pre-
mounted rear rectangular cap and remove cap with
gasket.
6. Remove 2 arch blocks through top opening.
Option 1: (for recessed cabinet base)
Re-install originally pre-mounted round transition
piece at opening with gasket.
INSTALLATION
5. Remove top pre-mounted transition piece. Leave
attached gasket in its original place.
7. Mount Starting Collar (provided) at rear discharge
opening with gasket previously removed.
Cap opening with 6" cap provided OR, use option 2 if
cabinet base is not recessed.
