Installation - Zephyr AK2000 Use, Care And Installation Manual

WARNING
Installation of this product is intended for qualified installers, service technicians, or
persons with similar qualified background. DO NOT attempt to install this appliance
yourself. Injury could result form installing the unit due to lack of appropriate electrical
knowledge and technical background. Improper installation, adjustment, alteration,
service or maintenance can cause injury or property damage and the warranty on the
product automatically becomes void.
Installation of this product must conform with all local codes. All connections must be
electrically grounded and ducting must be properly vented outside in accordance to
codes. Never duct exhaust into attics, within walls, crawlspaces, garages, or anywhere
inside the house which might cause grease fire. All duct joints must be properly
inspected, taped and sealed.
Edges are exposed around the duct opening and once the bottom grease shield is
removed. Be careful when handling the sharp edges. Wearing protective gloves and
appropriate work clothing is recommended.
REQUIREMENTS
Duct Size
Hurricane- 6" Vertical Duct Discharge
Whirlwind- 6" Vertical Duct Discharge
Cyclone- 6" Vertical Duct Discharge
3-1/4 x 10" Vertical Duct Discharge
3-1/4 x 10" Horizontal Rear
Discharge
ACCESSORIES
Hurricane & Whirlwind series
2 residue cups
2 'L' brackets (for direct wall mount
only)
4 screws for 'L' brackets
1 6" starting collar
3 electrical wire connectors & screws
Cyclone series
2 residue cups
2 'L' brackets (for direct wall mount
only)
4 screws for 'L' brackets

INSTALLATION

Tools
Hand Drill with #2 philips
Flat head screwdriver to pry electrical knockout
3/4" Wood Boring Bit
Jigsaw (if cabinet opening modification is
required)
Power Source
115W
1 6" starting collar
3 electrical wire connectors & screws
1 Convertible transition collar
1 6" collar cap
1 3-1/4 x 10" starting collar (packaged
separately)
1 Back-splash
Check all accessories before installation, packaging also
includes 1) Care, Maintenance and installation manual
2) Owner's Warranty Registration Card 3) Serial number
label adhered on top of box.
8
