VIBIA Break Plus Assembly Instructions Manual page 10

Step 4/5
Electrical Connection
4.2B DALI & CASAMBI CONNECTION WITH REMOTE WATERTIGHT BOX
4.3B
1
st
2
nd
+
-
10/12
CLOSED OPENED
- Electric cable
(not supplied)
- Cable eléctrico
(no suministrados)
- Stromkabel
(nicht beiliegend)
- Cavo elettrico
(non incluse)
- Câble électrique
(non fournies)
-
+
N L
100-240V
DA 1 / DA 2
O Min. 4 mm
O Max. 8 mm
2
nd
-
+
10 mm 5 mm
1
st
