- Page 1 APB-D200 R Press Conference Audio Distribution Amplifier Owner’s manual...
- Page 2 • If the power cord or plug becomes frayed or damaged, or if there is a sudden loss of sound during use of the device, or if any unusual smells or smoke should appear to be caused by it, immediately turn off the power switch, disconnect the electric plug from Do not open • Do not open the device or attempt to disassemble the internal parts or modify them in any the outlet, and have the device inspected by qualified AudioPressBox service personnel. way. The device contains no user-serviceable parts. If it should appear to be malfunctioning, • If this device or the AC power adaptor should be dropped or damaged, immediately turn discontinue use immediately and have it inspected by qualified AudioPressBox service off the power switch, disconnect the electric plug from the outlet, and have the device personnel. inspected by qualified AudioPressBox service personnel. Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage to the device or other property.
- Page 3 Use only the adaptor included with this Be sure to unplug the adaptor from the outlet To avoid generating unwanted noise, make AudioPressBox. Use of a different adaptor may when not using AudioPressBox, or when there sure there is 50 cm or more between the result in equipment damage, overheating, or fire.
- Page 4 Dear customer, Thank you for purchasing AudioPressBox® APB-D200 R. This 2 channel drive unit can feed up to 96 Line/MIC Outputs. Each buffered expander output can power 24 Line/MIC outputs. It features the high-pass filter, compressor and limiter and of course gain. With AudioPressBox® you are set in a minute and you can provide the perfect signal to every reporter! APB-D200 R The package contains AudioPressBox unit. Power supply. Manual Test report...
- Page 5 7) Buffered XLR output for expanders than the nominal output level please switch this button APB - D200R You can set the input signal level depending on the Output for connecting the AudioPressBox expanders ON. Function of the compressor and limiter you can see APB - D100R Compressor High Pass Gain connected audio source to reach the optimal output level.
- Page 6 Balanced, XLR Max. input level Line: +32/+2dBu Input Impedance >5kOhm Output section Outputs 4 separately buffered, balanced outputs for AudioPressBox expanders Output connectors Balanced, XLR Nominal Output Level +6dBu Maximum Output Level +20dBu with 48 Outputs in use +16dBu (600kOhm)
- Page 7 Block diagram...
- Page 8 | web: www.audiopressbox.com MediaTech Central Europe, a.s., Drienova 34, 821 02 Bratislava, Slovak Republic (EU) Tel: +421 2 20 999 700...
