JKS ACOS Pro JKS2770 Installation Instructions

For wrangler jk, 2007+

Advertisement

INSTALLATION
INSTRUCTIONS
Welcome
CONGRATULATIONS on your purchase of a new JKS
ACOS Pro™ system! At JKS Manufacturing, we are com-
mitted to providing you with the best products available and
your satisfaction is our first priority.
PLEASE READ these Installation Instructions carefully,
and save them for future reference, as they contain impor-
tant installation and maintenance information.
Before You Begin...
 Familiarize yourself with the supplied parts as il-
lustrated in the column to the far right.
 Thoroughly read all procedures to ensure you
have the tools and experience necessary to com-
plete this installation.
 If you are not completely comfortable with any of
the procedures described on the following pages,
do not attempt this installation. Contact the JKS
Technical Department at 877-533-7557 to locate a
qualified installation specialist in your area.
Important
MOST VEHICLES REQUIRE additional parts or modi-
fications to accommodate the immediate increase in
ride height provided by the ACOS Pro™ system.
REAR CONTROL ARMS MUST BE same length as
original equipment arms to ensure proper bump shock
alignment and coil spring clearance – see section 6 for
details.
DO NOT EXCEED maximum range of adjustment – see
illustration on page 3.
JKS ACOS Pro™ Installation
Product: ACOS Pro™
Part Number: JKS2770
Applications: Wrangler JK, 2007+ (rear only)
517-278-1226 • tech@jksmfg.com • www.jksmfg.com
491 W. Garfield Avenue, Coldwater, MI 49036
JKS2770
Tools Required
 Hydraulic Floor Jack and Jack Stands
 Metric/Standard Socket Wrench Set
 Torque Wrench
 Transfer Punch (or equivalent)
 1/4" and 3/8" Drill Bits
 1/4" Allen Wrench
 Tape Measure
 Spray Lubricant (WD-40 or similar)
 Anti-Seize Lubricant
 Medium Strength Threadlocker
 Satin Black Spray Paint
 Coil Spring Compressor *
 Plasma Cutter *
 Grinding Wheel *
 Welding Equipment *
 Factory Service Manual (recommended)
* Asterisk denotes tools that are not required for some applica-
tions. Thoroughly read instructions first to determine which tools
will be required for your application.
Page 1
