INSTALLATION
INSTRUCTIONS
Welcome
CONGRATULATIONS on purchasing a set of new Con-
trol Arms from JKS Manufacturing. We are committed to
providing you with the best products available and your
satisfaction is our first priority.
PLEASE READ these Installation Instructions carefully,
and save them for future reference, as they contain impor-
tant installation and maintenance information.
Important
SUSPENSION COMPONENTS THAT HAVE RUBBER
BUSHINGS must be tightened with vehicle on level
ground and at normal ride height. The springs must
be supporting weight of vehicle when the hardware is
torqued.
RUBBER BUSHINGS MUST NEVER BE LUBRICATED,
as doing so will impair performance and longevity.
COMPATIBLE WITH original 4-link suspension con-
figuration and vehicle ride height up to 4.5".
REFER TO FACTORY SERVICE MANUAL for informa-
tion and procedures not covered in these instructions.
ATTENTION INSTALLER
Install Control Arms ONE AT A TIME for easiest alignment
of mounting hardware.
JKS Control Arm Installation
Product: Front Adjustable Lower Control Arms
Part Number: JKS1610
Applications: Wrangler JK, 2007+ (front only)
517-278-1226 • tech@jksmfg.com • www.jksmfg.com
491 W. Garfield Avenue, Coldwater, MI 49036
JKS1610
Tools Required
 JKS1695 or equivalent jam nut wrench
 Hydraulic Floor Jack and Jack Stands
 Metric/Standard Socket Wrench Set
 Torque Wrench
 Anti-Seize Lubricant
 Heavy Duty Ratchet Strap *
 Factory Service Manual (recommended)
* Asterisk denotes tools that are not required for some applica-
tions. Thoroughly read instructions first to determine which tools
will be required for your application.
Installation
‰ 1. REMOVE ORIGINAL LOWER
SUSPENSION ARM
 Raise and support the vehicle chassis with jack
stands positioned in rear of the front lower suspen-
sion arm brackets.
 Raise the front axle housing back into position
and support with a hydraulic jack. HINT: The
axle housing should be evenly supported and the
suspension at normal ride height. Do not attempt
removal or installation with the suspension extend-
ed, or the axle drooped, as this will place tension
on suspension arm mounting hardware.
 Remove the lower suspension arm bolt and nut
from the axle housing bracket. Retain the original
mounting hardware.
 Remove the bolt and nut from the chassis rail
bracket. Retain the original mounting hardware.
