INSTALLATION
INSTRUCTIONS
Welcome
CONGRATULATIONS on purchasing a new Adjust-
able Trackbar from JKS Manufacturing. We are com-
mitted to providing you with the best products avail-
able and your satisfaction is our first priority.
PLEASE READ these Installation Instructions careful-
ly, and save them for future reference, as they contain
important installation and maintenance information.
Important
NOT COMPATIBLE WITH frame-mounted track bar
drop brackets.
CHECK TORQUE SPECIFICATIONS regularly.
Tools Required
Hydraulic Floor Jack & Jack Stands
Metric/Standard Socket Wrench Set
Torque Wrench
1-7/8" Open-End Wrench
Tape Measure
Heavy Duty Ratchet Strap *
Anti-Seize Lubricant
Factory Service Manual (recommended)
* Asterisk denotes tools that are not required for some applica-
tions. Thoroughly read instructions first to determine which tools
will be required for your application.
JKS Adjustable Trackbar Installation
Product: Adjustable Track Bar
Part Number: JKSOGS122
Applications: Wrangler JK RHD, 2007-14
Description
A
Male Threaded (Frame) End
B
Female Threaded (Axle) End
C
1-1/4" NF Jam Nut
D
Rubber Bushing
‰ 1. REMOVE FRONT TRACK BAR
Remove the front track bar mounting hardware
from the axle and chassis brackets. Retain origi-
nal hardware.
Remove original track bar from vehicle.
‰ 2. MOUNT ADJUSTABLE TRACKBAR TO
AXLE BRACKET
Apply anti-seize lubricant to bolt threads of original
track bar mounting hardware.
JKSOGS122
Parts
Installation
QTY
1
1
1
2
Page 1
Advertisement
Related Manuals for JKS JKSOGS122
Summary of Contents for JKS JKSOGS122
- Page 1 INSTRUCTIONS Welcome Parts CONGRATULATIONS on purchasing a new Adjust- able Trackbar from JKS Manufacturing. We are com- mitted to providing you with the best products avail- able and your satisfaction is our first priority. PLEASE READ these Installation Instructions careful- ly, and save them for future reference, as they contain important installation and maintenance information.
- Page 2 If the axle housing is not centered, the chassis ‰ 5. POST-INSTALLATION can be laterally shifted using either of the following methods: Take measurements again to ensure axle housing is perfectly centered and make any final adjust- ments if necessary. 2 Page JKSOGS122 JKS Adjustable Trackbar Installation...
- Page 3 Maintenance Check torque specifications regularly. Regular cleaning with pressurized water is recom- mended to maximize reliability. Page 3 JKS Adjustable Trackbar Installation JKSOGS122 Learn more about suspension parts on our website.
