Technical Specifications
Problem
An enrolled finger
cannot be identified.
Status point of the control
panel is not blinking.
Error code "E0"
visible in the display fol-
lowed by the count-down
starting from 45.
Error code "E1"
visible in the display.
Error code "E2"
visible in the display
The LED on the scanner
is signalling a positive iden-
tification, however the relay
is not released
6. TECHNICAL SPECIFICATIONS
• CONNECTIONS
o Connection between scanner and control panel
o 1x Relay 250VAC 5A (3x ekey
o 9VAC with provided external power supply unit
• MEMORY
o 99 fingers possible
o No loss of data after power failure
26
Cause
1. During enrolment, a dif-
ferent area of the finger was
scanned.
2. The enrolment has not
been carried out correctly.
System not connected
to the power supply.
1. Connection between the
scanner and control panel is
not correct.
2. The power supply has been
>
interrupted the system is
starting again.
99 fingers have already been
enrolled. It is not possible to
enrol more fingers.
Incorrect security code has
been entered three times.
Wrong unit coupling.
The finger is not accepted,
as a device has been swapped
® TOCAhome 3 and PC model)
Solution
1. The finger has to be enrolled
again by swiping it consistently
over the sensor.
2. See "I am unable to enrol a
finger" – perfect enrolment en-
sures high identification rates.
1. Ensure power supply
2. Inspect glass tube fuse
1. Check the "4-line"
connection wire.
2. Wait until the system has
initialised again.
Erase some fingers
in order to enrol new ones.
Wait for 30 min, enter
the correct security code.
After swapping
scanner or control panel,
a reset has to be carried out.
