Micropilot FMR62B PROFINET with Ethernet-APL
10.2
Mounting requirements
10.2.1
Internal vessel fittings
Avoid internal fittings (point level switches, temperature sensors, struts, vacuum rings,
heating coils, baffles etc.) inside the signal beam. Pay attention to the beam angle α.
Endress+Hauser
α
Mounting
A0031777
9
