TI01701F/00/EN/01.23-00
71610084
2023-01-02
Products
Technical Information
Micropilot FMR66B
PROFINET with Ethernet-APL
Free space radar
Level measurement in bulk solids
Application
• Continuous, non-contact level measurement of powdered to granular bulk solids
• Process connections: thread or mounting bracket
• Maximum measuring range: 50 m (164 ft)
• Temperature: –40 to +130 °C (–40 to +266 °F)
• Pressure: –1 to +16 bar (–14.5 to +232 psi)
• Accuracy: ±3 mm (±0.12 in)
Your benefits
• PVDF or PTFE Drip-off antenna
• Reliable measurement thanks to very good signal focusing, even with small process
connections
• Easy, guided commissioning with intuitive user interface
• Bluetooth® wireless technology for commissioning, operation and maintenance
Solutions
Services

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Micropilot FMR66B PROFINET with Ethernet-APL and is the answer not in the manual?

Questions and answers

Related Manuals for Endress+Hauser Micropilot FMR66B PROFINET with Ethernet-APL

Summary of Contents for Endress+Hauser Micropilot FMR66B PROFINET with Ethernet-APL

  • Page 1 Products Solutions Services TI01701F/00/EN/01.23-00 71610084 2023-01-02 Technical Information Micropilot FMR66B PROFINET with Ethernet-APL Free space radar Level measurement in bulk solids Application • Continuous, non-contact level measurement of powdered to granular bulk solids • Process connections: thread or mounting bracket • Maximum measuring range: 50 m (164 ft) •...

  • Page 2: Table Of Contents

    Micropilot FMR66B PROFINET with Ethernet-APL Table of contents Important document information ....3 Dielectric constant ......24 Symbols .

  • Page 3: Important Document Information

    Micropilot FMR66B PROFINET with Ethernet-APL Important document information Symbols Safety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury.

  • Page 4: Graphic Conventions

    Micropilot FMR66B PROFINET with Ethernet-APL Graphic conventions • Installation, explosion and electrical connection drawings are presented in simplified format • Devices, assemblies, components and dimensional drawings are presented in reduced-line format • Dimensional drawings are not to-scale representations; the dimensions indicated are rounded off to 2 decimal places •...

  • Page 5: Input

    Micropilot FMR66B PROFINET with Ethernet-APL D = (c ∆t) / 2 where c is the speed of propagation of the wave. In summary, D can be calculated from the measured difference frequency Δf. D is then used to determine the content of the tank or silo.

  • Page 6: Operating Frequency

    Mechanical construction. For the dielectric constants (DC values) of many media commonly used in industry, please refer • Dielectric constant (DC value) Compendium CP01076F • The Endress+Hauser "DC Values app" (available for Android and iOS) Operating frequency Approx. 80 GHz Up to 8 devices can be installed in a tank without the devices mutually influencing one another.

  • Page 7: Power Supply

    Micropilot FMR66B PROFINET with Ethernet-APL Device type ID 0xA1C1 Device description files (GSD, Information and files available at: FDI, DTM, DD) • www.endress.com On the product page for the device: Documents/Software → Device drivers • www.profibus.org Supported connections • 2 x AR (IO Controller AR) •...

  • Page 8: Terminals

    Micropilot FMR66B PROFINET with Ethernet-APL Dual compartment housing A0042803  4 Connection terminals and ground terminal in the connection compartment Positive terminal Negative terminal Internal ground terminal Dual compartment housing, L-form A0045842  5 Connection terminals and ground terminal in the connection compartment...

  • Page 9: Supply Voltage

    Micropilot FMR66B PROFINET with Ethernet-APL Devices with M12 plug A0011175  6 View of the plug-in connection on the device APL signal - APL signal + Shielding Not assigned Various M12 sockets are available as accessories for devices with M12 plugs.

  • Page 10: Cable Entries

    Micropilot FMR66B PROFINET with Ethernet-APL WARNING Explosion Hazard! ‣ Please refer to the separate documentation on applications in hazardous areas for the safety instructions. For optimum electromagnetic compatibility: • Keep the potential matching line as short as possible • Observe a cross-section of at least 2.5 mm...

  • Page 11: Overvoltage Protection

    Micropilot FMR66B PROFINET with Ethernet-APL Overvoltage protection The overvoltage protection can optionally be ordered as a "Mounted accessory" via the product structure Devices without optional overvoltage protection The equipment fulfills the requirements of the product standard IEC / DIN EN 61326-1 (Table 2 Industrial Environment).

  • Page 12: Measured Value Resolution

    Micropilot FMR66B PROFINET with Ethernet-APL Differing values in near-range applications ∆ [mm (in)] 20 (0.79) 3 (0.12) -3 (-0.12) -20 (-0.79) D [m ( )] 1.5 (4.92) A0032637  8 Maximum measured error in near-range applications Δ Maximum measured error...

  • Page 13: Mounting

    Micropilot FMR66B PROFINET with Ethernet-APL Mounting Mounting location A0016883 Recommended distance from wall to nozzle outer edge ~ 1/6 of the vessel diameter. The device should never be mounted closer than 20 cm (7.87 in) to the vessel wall. Use of a weather protection cover; protection from direct sunlight or rain...
  • Page 14 Micropilot FMR66B PROFINET with Ethernet-APL Orientation Internal vessel fittings A0031814 Avoid internal fittings (point level switches, temperature sensors, struts, vacuum rings, heating coils, baffles etc.) inside the signal beam. Pay attention to the beam angle α. Avoiding interference echoes A0031817...

  • Page 15: Installation Instructions

    Micropilot FMR66B PROFINET with Ethernet-APL Metal deflector plates, installed at an angle to scatter the radar signals, help prevent interference echoes. Vertical alignment of antenna axis Align the antenna so that it is perpendicular to the product surface. The maximum reach of the antenna can be reduced, or additional interference signals can occur, if the antenna is not installed perpendicular to the product.

  • Page 16: Beam Angle

    Micropilot FMR66B PROFINET with Ethernet-APL D 100 to 150 mm (4 to 6 in) 1 450 mm (58 in) ≥150 mm (6 in) 2 200 mm (88 in) In the case of longer nozzles, reduced measuring performance must be expected.

  • Page 17: Special Mounting Instructions

    Micropilot FMR66B PROFINET with Ethernet-APL Drip-off, PTFE 50 mm (2 in) antenna, α = 6 ° W = D × 0.10 5 m (16 ft) 0.52 m (1.70 ft) 10 m (33 ft) 1.04 m (3.41 ft) 15 m (49 ft) 1.56 m (5.12 ft) 20 m (66 ft) 2.08 m (6.82 ft)

  • Page 18: Environment

    Micropilot FMR66B PROFINET with Ethernet-APL Environment Ambient temperature range The following values apply up to a process temperature of +85 °C (+185 °F). At higher process temperatures, the permitted ambient temperature is reduced. • Without LCD display: Standard: –40 to +85 °C (–40 to +185 °F) •...
  • Page 19 Micropilot FMR66B PROFINET with Ethernet-APL Restriction to a process temperature of 0 to +80 °C (+32 to +176 °F) with CSA C/US approval and plastic housing A0048826  11 Plastic housing; process temperature 0 to +80 °C (+32 to +176 °F) with CSA C/US approval = T...
  • Page 20 Micropilot FMR66B PROFINET with Ethernet-APL Aluminum housing, coated Aluminum housing; process temperature –40 to +80 °C (–40 to +176 °F) A0032024  14 Aluminum housing, coated; process temperature –40 to +80 °C (–40 to +176 °F) = T : –40 °C (–40 °F) |  T : +79 °C (+174 °F)

  • Page 21: Storage Temperature

    Micropilot FMR66B PROFINET with Ethernet-APL 316L housing; process temperature –40 to +130 °C (–40 to +266 °F) A0032024  17 316L housing; process temperature –40 to +130 °C (–40 to +266 °F) = T : –40 °C (–40 °F) |  T : +77 °C (+171 °F) = T...

  • Page 22: Installation Height As Per Iec61010-1

    Micropilot FMR66B PROFINET with Ethernet-APL Installation height as per Generally up to 5 000 m (16 404 ft) above sea level IEC61010-1 Ed.3 Degree of protection Test as per IEC 60529 and NEMA 250-2014 Housing IP66/68, NEMA TYPE 4X/6P IP68 test condition: 1.83 m under water for 24 hours.
  • Page 23 Micropilot FMR66B PROFINET with Ethernet-APL Encapsulated antenna, PVDF, 40 mm (1.5 in) Process connection thread 1-½" Seal Process pressure range PVDF encapsulated –40 to +80 °C –1 to 3 bar (–14.5 to 43.5 psi) (–40 to +176 °F) PVDF encapsulated –40 to +130 °C...

  • Page 24: Dielectric Constant

    The pressure range may be further restricted in the event of a CRN approval. Dielectric constant For bulk solids ε ≥ 1.6 Contact Endress+Hauser for applications with lower dielectric constants than indicated. Mechanical construction Dimensions The dimensions of the individual components must be added together for the total dimensions. Single compartment housing, plastic 94 (3.7)
  • Page 25 Micropilot FMR66B PROFINET with Ethernet-APL Aluminum single compartment housing 101 (3.98) 45 (1.77) 125 (4.92) A0038380  21 Dimensions of aluminum single compartment housing. Unit of measurement mm (in) Height with cover with glass viewing window (devices for Ex d/XP, Dust-Ex)
  • Page 26 Micropilot FMR66B PROFINET with Ethernet-APL 316L single compartment housing, hygiene 92 (3.62) 123 (4.84) A0050364  22 Dimensions of 316L single compartment housing, hygiene. Unit of measurement mm (in) Height with cover with glass viewing window (dust Ex) Height with cover with plastic viewing window...
  • Page 27 Micropilot FMR66B PROFINET with Ethernet-APL Aluminum dual compartment housing 132 (5.2) 121 (4.76) 115 (4.53) 118 (4.65) 64 (2.52) 54 (2.13) 78 (3.07) 143 (5.63) A0038377  23 Dimensions of dual compartment housing. Unit of measurement mm (in) Height with cover with glass viewing window (devices for Ex d/XP, Dust-Ex)
  • Page 28 Micropilot FMR66B PROFINET with Ethernet-APL Aluminum or 316L dual compartment housing, L-form 110 (4.33) 101 (3.98) 140 (5.51) 138 (5.43) A0038381  24 Dimensions of dual compartment housing, L-form. Unit of measurement mm (in) Height with cover with glass viewing window (devices for Ex d/XP, Dust-Ex)
  • Page 29 Micropilot FMR66B PROFINET with Ethernet-APL Encapsulated antenna, PVDF, 40 mm (1.5 in), process connection UNI flange 50 mm 43.7 (1.72) A0048829  26 Dimensions of encapsulated antenna, PVDF, 40 mm (1.5 in), process connection UNI flange. Unit of measurement mm (in)
  • Page 30 Micropilot FMR66B PROFINET with Ethernet-APL UNI flange 4"/DN100/100A 20 (0.79) A0048848  28 Dimensions of UNI flange 4"/DN100/100A. Unit of measurement mm (in) Suitable for ASME B16.5, 4" 150lbs / EN1092-1; DN100 PN16 / JIS B2220; 10K 100A Material: PP, weight 0.70 kg (1.54 lb) UNI flange 6"/DN150/150A...
  • Page 31 Micropilot FMR66B PROFINET with Ethernet-APL Drip-off antenna 50 mm (2 in), threaded process connection 55 mm 42.5 (1.67) A0052079  30 Dimensions of Drip-off antenna 50 mm (2 in), threaded process connection. Unit of measurement mm (in) Version, process temperature ≤130 °C (266 °F)
  • Page 32 Micropilot FMR66B PROFINET with Ethernet-APL UNI flange 3"/DN80/80A 20 (0.79) A0048847  32 Dimensions of UNI flange 3"/DN80/80A. Unit of measurement mm (in) Suitable for ASME B16.5, 3" 150lbs / EN1092-1; DN80 PN16 / JIS B2220; 10K 80A Material: • PP, weight 0.50 kg (1.10 lb) •...

  • Page 33: Weight

    Micropilot FMR66B PROFINET with Ethernet-APL UNI flange 6"/DN150/150A 20 (0.79) A0048849  34 Dimensions of UNI flange 6"/DN150/150A. Unit of measurement mm (in) Suitable for ASME B16.5, 6" 150lbs / EN1092-1; DN150 PN16 / JIS B2220; 10K 150A Material: • PP, weight 1.00 kg (2.20 lb) •...
  • Page 34 Micropilot FMR66B PROFINET with Ethernet-APL • Seal under potential equalization: EPDM • Plug: PBT-GF30-FR • M20 cable gland: PA • Seal on plug and cable gland: EPDM • Threaded adapter as replacement for cable glands: PA66-GF30 • Nameplate: plastic foil •...
  • Page 35 Micropilot FMR66B PROFINET with Ethernet-APL Materials in contact with the medium Encapsulated antenna, PVDF, 40 mm (1.5 in) A0046602  35 Material; encapsulated antenna, PVDF, 40 mm (1.5 in) Antenna, PVDF Threaded process connection, PVDF Housing adapter, PBT-GF30 (dust ignition-proof: 304/ 1.4301)

  • Page 36: Display And User Interface

    Micropilot FMR66B PROFINET with Ethernet-APL Display and user interface Operating concept Operator-oriented menu structure for user-specific tasks • Guidance • Diagnostics • Application • System Fast and safe commissioning • Interactive wizard with graphical user interface for guided commissioning in FieldCare, DeviceCare or DTM, AMS and PDM-based third-party tools or SmartBlue •...

  • Page 37: Local Display

    Micropilot FMR66B PROFINET with Ethernet-APL Local display Device display (optional) Functions: • Display of measured values and fault and notice messages • Background lighting, which switches from green to red in the event of an error • The device display can be removed for easier operation A0039284 ...

  • Page 38: System Integration

    A0039148 Computer with FieldCare/DeviceCare operating tool Commubox FXA291 Service interface (CDI) of the measuring device (= Endress+Hauser Common Data Interface) Via Web browser Function scope Thanks to the integrated Web server the device can be operated and configured via a Web browser.

  • Page 39: Ce Mark

    Micropilot FMR66B PROFINET with Ethernet-APL CE mark The measuring system meets the legal requirements of the applicable EU directives. These are listed in the corresponding EU Declaration of Conformity together with the standards applied. The manufacturer confirms successful testing of the device by affixing to it the CE mark.

  • Page 40: En 302372 Radio Standard

    Micropilot FMR66B PROFINET with Ethernet-APL Astronomy stations Country Name of the station Latitude Longitude Germany Effelsberg 50° 31'   32" North 06° 53'   00" East Finland Metsähovi 60° 13'   04" North 24° 23'   37" East Tuorla 60° 24'   56" North 24° 26'   31" East France Plateau de Bure 44° 38'  ...

  • Page 41: Certification Profinet With Ethernet-Apl

    Micropilot FMR66B PROFINET with Ethernet-APL This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.

  • Page 42: Calibration

    • Automatic verification of exclusion criteria • Automatic creation of the order code and its breakdown in PDF or Excel output format • Ability to order directly in the Endress+Hauser Online Shop Calibration Factory calibration certificate The calibration points are spread evenly over the measuring range (0 to 100 %).

  • Page 43: Test, Certificate, Declaration

    Condition Monitoring system and the in-situ verification of devices in the application. The application package can be ordered together with the device or can be activated subsequently with an activation code. Detailed information on the order code is available via the Endress+Hauser website www.endress.com...

  • Page 44: Accessories

    Micropilot FMR66B PROFINET with Ethernet-APL Heartbeat Monitoring Foam detection wizard and Build-up detection wizard are available, process windows can be configured. Furthermore, additional monitoring parameters can be displayed and used for predictive maintenance or application optimization. "Foam detection" wizard This wizard configures the automatic foam detection.

  • Page 45: Plastic Weather Protection Cover

    Micropilot FMR66B PROFINET with Ethernet-APL 228.9 (9.01) 136.4 (5.37) 92.5 (3.64) 170.5 (6.71) 81 (3.19) 103 (4.06) A0039231  40 Dimensions. Unit of measurement mm (in) Material • Weather protection cover: 316L • Clamping screw: A4 • Holder: 316L Order number for accessories:...
  • Page 46 Micropilot FMR66B PROFINET with Ethernet-APL ø89 (3.5) ø142 (5.59) A0046695 Technical data • Material: EPDM • Recommended screw size: M14 • Recommended screw length: 100 mm (3.9 in) • Process pressure: –0.1 to 0.1 bar (–1.45 to 1.45 psi) • Process temperature: –40 to +80 °C (–40 to +176 °F) Ordering information •...
  • Page 47 Micropilot FMR66B PROFINET with Ethernet-APL Technical data • Material: EPDM • Recommended screw size: M18 • Recommended screw length: 110 mm (4.3 in) • Process pressure: –0.1 to 0.1 bar (–1.45 to 1.45 psi) • Process temperature: –40 to +80 °C (–40 to +176 °F) Ordering information •...

  • Page 48: Mounting Bracket, Adjustable

    Micropilot FMR66B PROFINET with Ethernet-APL Ordering information • The flange seal can be ordered together with the device via the "Accessory enclosed" product structure. • Order number: 71249072 Seal, adjustable, ASME 6"/ JIS 150A The seal, adjustable, ASME 6"/ JIS 150A is compatible with flanges ASME 6" 150 lbs and JIS 150A 10K ø168 (6.6)

  • Page 49: M12 Socket

    Micropilot FMR66B PROFINET with Ethernet-APL Order number for accessories: 71597288 Dimensions 282 (11.1) 230 (9.06) 35 (1.38) 9 (0.35) 3 (0.12) A0048769  43 Dimensions of mounting bracket. Unit of measurement mm (in) Scope of delivery A0049050  44 Scope of delivery of mounting bracket, adjustable 1 ×...

  • Page 50: Remote Display Fhx50B

    Micropilot FMR66B PROFINET with Ethernet-APL A0051232  46 M12 socket, angled M12 socket, angled • Material: Body: PBT; union nut: nickel-plated die-cast zinc; seal: NBR • Degree of protection (fully locked): IP67 • Pg coupling: Pg7 • Order number: 71114212 A0051233 ...

  • Page 51: Gas-Tight Feedthrough

    Micropilot FMR66B PROFINET with Ethernet-APL A0046692 Plastic single compartment housing, remote display Aluminum single compartment housing, remote display Single compartment housing, 316L hygiene, remote display Device side, plastic single compartment housing prepared for display FHX50B Device side, aluminum single compartment housing prepared for display FHX50B...

  • Page 52: Field Xpert Smt70

    For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. Document function...
  • Page 53 Micropilot FMR66B PROFINET with Ethernet-APL Bluetooth® The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Endress+Hauser is under license. Other trademarks and trade names are those of their respective owners. Apple®...
  • Page 56 *71610084* 71610084 www.addresses.endress.com...
