KA01612F/00/EN/01.23-00
71610091
2023-04-22
advanced physical layer
Products
Brief Operating Instructions
Micropilot FMR62B
PROFINET with Ethernet-APL
Free space radar
These Brief Operating Instructions are not a substitute for the
Operating Instructions pertaining to the device.
Detailed information is provided in the Operating Instructions
and other documentation.
Available for all device versions via:
• Internet:
www.endress.com/deviceviewer
• Smartphone/tablet: Endress+Hauser Operations app
Solutions
Services

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Micropilot FMR62B PROFINET with Ethernet-APL and is the answer not in the manual?

Questions and answers

Related Manuals for Endress+Hauser Micropilot FMR62B PROFINET with Ethernet-APL

Summary of Contents for Endress+Hauser Micropilot FMR62B PROFINET with Ethernet-APL

  • Page 1 These Brief Operating Instructions are not a substitute for the Operating Instructions pertaining to the device. Detailed information is provided in the Operating Instructions and other documentation. Available for all device versions via: • Internet: www.endress.com/deviceviewer • Smartphone/tablet: Endress+Hauser Operations app...
  • Page 2 Micropilot FMR62B PROFINET with Ethernet-APL Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...

  • Page 3: Table Of Contents

    Micropilot FMR62B PROFINET with Ethernet-APL Table of contents Table of contents Symbols ................4 Safety symbols .

  • Page 4: Symbols

    Symbols Micropilot FMR62B PROFINET with Ethernet-APL Symbols Safety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury.

  • Page 5: Requirements For Personnel

    Do not touch or clean device surfaces with pointed or hard objects. Clarification of borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability.

  • Page 6: Workplace Safety

    It meets general safety standards and legal requirements. It also complies with the EC directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device. Incoming acceptance...

  • Page 7: Product Identification

     All the information about the measuring device is displayed. ‣ Endress+Hauser Operations app; manually enter the serial number indicated on the nameplate or scan the 2D matrix code on the nameplate.  All the information about the measuring device is displayed.

  • Page 8: Storage And Transport

    Storage and transport Micropilot FMR62B PROFINET with Ethernet-APL Storage and transport Storage conditions • Use the original packaging • Store the device in clean and dry conditions and protect from damage caused by shocks 9.1.1 Storage temperature range See Technical Information.

  • Page 9: Mounting Requirements

    Micropilot FMR62B PROFINET with Ethernet-APL Mounting 10.2 Mounting requirements 10.2.1 Internal vessel fittings α A0031777 Avoid internal fittings (point level switches, temperature sensors, struts, vacuum rings, heating coils, baffles etc.) inside the signal beam. Pay attention to the beam angle α.
  • Page 10 Mounting Micropilot FMR62B PROFINET with Ethernet-APL 10.2.2 Avoiding interference echoes A0031813 Metal deflector plates, installed at an angle to scatter the radar signals, help prevent interference echoes. 10.2.3 Vertical alignment of antenna axis Align the antenna so that it is perpendicular to the product surface.

  • Page 11: Mounting The Device

    Micropilot FMR62B PROFINET with Ethernet-APL Mounting 10.3 Mounting the device 10.3.1 Horn antenna 65 mm (2.56 in) Information about the mounting nozzle The maximum nozzle length H depends on the nozzle diameter D. Maximum nozzle length H as a function of the nozzle diameter D D...
  • Page 12 Mounting Micropilot FMR62B PROFINET with Ethernet-APL Maximum nozzle length H as a function of the nozzle diameter D D 50 to 80 mm (2 to 3.2 in) 750 mm (30 in) 80 to 100 mm (3.2 to 4 in) 1 150 mm (46 in)
  • Page 13 Micropilot FMR62B PROFINET with Ethernet-APL Mounting Flange size Number of screws Tightening torque 10K 50A 40 to 60 Nm Information about the mounting nozzle The maximum nozzle length H depends on the nozzle diameter D. The maximum length of the nozzle H depends on the nozzle diameter D D...
  • Page 14 Mounting Micropilot FMR62B PROFINET with Ethernet-APL Flange size Number of screws Tightening torque DN80 PN25/40 40 to 55 Nm DN100 PN10/16 40 to 60 Nm DN100 PN25/40 55 to 80 Nm DN150 PN10/16 75 to 105 Nm ASME NPS 3" Cl.150 65 to 95 Nm NPS 3"...
  • Page 15 Micropilot FMR62B PROFINET with Ethernet-APL Mounting The maximum length of the nozzle H depends on the nozzle diameter D D 80 to 100 mm (3.2 to 4 in) 1 750 mm (70 in) 100 to 150 mm (4 to 6 in) 2 200 mm (88 in) ≥...
  • Page 16 Mounting Micropilot FMR62B PROFINET with Ethernet-APL NOTICE The housing cannot be unscrewed fully. ‣ Loosen the external locking screw by a maximum of 1.5 turns. If the screw is unscrewed too much or completely (beyond the screw anchor point), small parts (counter disk) can become loose and fall out.

  • Page 17: Post-Mounting Check

    Micropilot FMR62B PROFINET with Ethernet-APL Electrical connection 10.3.7 Closing the housing covers NOTICE Thread and housing damaged from dirt! ‣ Remove dirt (e.g. sand) on the cover and housing thread. ‣ If you encounter resistance when closing the cover, check the thread for dirt and clean it.
  • Page 18 Electrical connection Micropilot FMR62B PROFINET with Ethernet-APL 0.7 Nm A0039520  1 Cover with securing screw 0.7 Nm A0050983  2 Cover with securing screw; hygiene housing (only for dust explosion protection) 11.1.2 Potential equalization The protective ground on the device must not be connected. If necessary, the potential matching line can be connected to the outer ground terminal of the transmitter before the device is connected.

  • Page 19: Connecting The Device

    Micropilot FMR62B PROFINET with Ethernet-APL Electrical connection WARNING Explosion Hazard! ‣ Please refer to the separate documentation on applications in hazardous areas for the safety instructions. For optimum electromagnetic compatibility: • Keep the potential matching line as short as possible •...
  • Page 20 Electrical connection Micropilot FMR62B PROFINET with Ethernet-APL 11.2.2 Cable specification Rated cross-section • Supply voltage 0.5 to 2.5 mm (20 to 13 AWG) • Protective earth or grounding of the cable shield > 1 mm (17 AWG) • External ground terminal 0.5 to 4 mm...
  • Page 21 Micropilot FMR62B PROFINET with Ethernet-APL Electrical connection 11.2.4 Wiring WARNING Supply voltage might be connected! Risk of electric shock and/or explosion! ‣ If the device is used in hazardous areas, make sure to comply with national standards and the specifications in the Safety Instructions (XAs). The specified cable gland must be used.
  • Page 22 Electrical connection Micropilot FMR62B PROFINET with Ethernet-APL 11.2.5 Terminal assignment Single compartment housing A0042594  3 Connection terminals and ground terminal in the connection compartment Positive terminal Negative terminal Internal ground terminal Endress+Hauser...
  • Page 23 Micropilot FMR62B PROFINET with Ethernet-APL Electrical connection Dual compartment housing A0042803  4 Connection terminals and ground terminal in the connection compartment Positive terminal Negative terminal Internal ground terminal Endress+Hauser...
  • Page 24 Electrical connection Micropilot FMR62B PROFINET with Ethernet-APL Dual compartment housing, L-form A0045842  5 Connection terminals and ground terminal in the connection compartment Positive terminal Negative terminal Internal ground terminal 11.2.6 Cable entries A0046584 Single compartment housing, plastic Single compartment housing, aluminum...

  • Page 25: Ensuring The Degree Of Protection

    Micropilot FMR62B PROFINET with Ethernet-APL Electrical connection The type of cable entry depends on the device version ordered. Always route connecting cables downwards so that moisture cannot penetrate the connection compartment. If necessary, create a drip loop or use a weather protection cover.

  • Page 26: Operation

    Operation Micropilot FMR62B PROFINET with Ethernet-APL  Cover lock tightened correctly? Operation 12.1 Reading off the device locking status Displaying active write protection: • In the Locking status parameter Menu path of local display: at the top operating level Menu path of operating tool: System → Device management •...

  • Page 27: Establishing A Connection Via Fieldcare And Devicecare

    Computer with Web browser or with operating tool (e.g.,, DeviceCare) Automation system Field Xpert SMT70 Mobile handheld terminal Local operation via display module 13.3.2 Via service interface (CDI) A0039148 Computer with FieldCare/DeviceCare operating tool Commubox FXA291 Service interface (CDI) of the measuring device (= Endress+Hauser Common Data Interface) Endress+Hauser...

  • Page 28: Configuring The Operating Language

    Commissioning Micropilot FMR62B PROFINET with Ethernet-APL 13.4 Configuring the operating language 13.4.1 Local display Setting the operating language To set the operating language, the display first needs to be unlocked: Press the  key for at least 2 s.  A dialog box appears.

  • Page 29: Configuring The Device

    Micropilot FMR62B PROFINET with Ethernet-APL Commissioning 13.5 Configuring the device 13.5.1 Level measurement in liquids 100% A0016933  7 Configuration parameters for level measurement in liquids Reference point of measurement Length of antenna + 10 mm (0.4 in) 50 to 80 mm (1.97 to 3.15 in); medium εr < 2...
  • Page 30 Commissioning Micropilot FMR62B PROFINET with Ethernet-APL 13.5.2 Commissioning with the Commissioning wizard In FieldCare, DeviceCare, SmartBlue and on the display, the Commissioning wizard is available to guide the user through the initial commissioning steps. Complete this wizard to commission the device.
  • Page 32 *71610091* 71610091 www.addresses.endress.com...
